Dust extraction set AS 1601

• Versatile range of applications such as drilling, reaming, thread cutting
• Electrically braked motor
• Operating elements with 24V DC electrics and 2-channel safety chain in accordance with DIN EN 12717
• Heavy, solid, high-quality casting
• Wide reach due to horizontally adjustable machine head
• Clearly arranged control panel
• Smooth-running swivel and traversing axles
• Sturdy, torsion-resistant construction of the boom
• Boom height adjustment via powerful motorized drive and lifting spindle
• Gearbox of the drill head runs in an oil bath
• Boom guideways hardened and precision-ground
• Gear wheels made of chrome-nickel steel, hardened and precision-ground for quiet and smooth running
• Drill head and column can be clamped or released together or separately
• Right/left rotation
• Solid, precise drill table, large dimensions
• Hardened and ground clamping table with parallel T-slots
• Machine light
• Overload protection
• Thick-walled cast iron column ensures smooth running and stability
• LED lamp
• Coolant system with coolant tank in the machine base
• Clamping table included in scope of delivery
• Column and headstock mechanically clamped

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Best power transmission through aluminum pulleys
• Digital speed indicator integrated in the housing, speed control by potentiometer
• Emergency stop impact switch
• Drill spindle with precision ball bearings
• High quality OPTIMUM keyless chuck as standard
• Guaranteed concentricity accuracy less than 0.03 mm measured at the drilling spindle
• Height-adjustable feed guard with microswitch
• Dirt and water resistant membrane keypad, easy to clean
• Precision machined drill table with parallel T-slots
• Thick-walled cast-iron column for high power absorption and stability
• Massive base plate, large dimensions, strongly ribbed on the back
• EMC filter class C2

DX 13V

• Height adjustable drill head

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Revolutionary simple, very fast and comfortable operation
• Compact and space-saving
• With practical shelves for all individual segments and bending rails
• Ideal for bending aluminum, copper, steel, stainless steel, etc.
• Precise bend angle adjustment up to 170 °
• Powerful electromagnetic system for optimum bending results
• The clamping across the entire width guarantees a clean bend
• Very high bending capacity
• The main pressure is on the upper cheek, not on the machine
• The unique centerless hinges ensure precise power transmission at the bending point
• Backgauge, segmented upper jaw and foot pedal are standard

With practical shelves for all individual segments and bending rails

Extremely fast and easy operation - in just a few steps you can turn your sheets into the desired shape without great effort

Step 1:

• Place the workpiece on the magnetic conductors and adjust using the bending edge

Step 2:

• Choose the right bending segment, place it on the workpiece and activate the magnet

Step 3:

• At the bend stop you can set the exact bending angle. Perform the bending process

The conversion for further bending operations is done in a few steps.

Note: Do not use the machine with pacemakers
