Metal lathes

Ideaalne kasutamiseks sektorites, mis vajavad mitmekülgsust.
Erakordselt lai spindli ava (Ø52mm) suurte võlli läbimõõtude töötlemiseks.
Elektromagnetiline jalapidur tagab maksimaalse tööohutuse ja vähendab olulisel määral mitteproduktiivset aega.
Eemaldatav sild võimaldab kuni 474 mm läbimõõduga toorikute töötlemist.
Hammasrattad ja spindlid on karastatud.
Kiiruselihtne ja kiire vahetamine.
Suur digitaalne ekraanhõlpsaks kasutamiseks.

• Võimsus: 2100W
• Pinge: 400 V
• Spindli kiirus: 70-1900 p/min
• Spindli ava: 52 mm
• Kelgu käik: 810 mm
• Tsentrite vaheline kaugus: 1000 mm
• Kaal: 630 kg

Ideaalne lukkseppadele, töötubade ja koolide jaoks.
Pöörlemiskiiruse lihtne ja kiire vahetamine hammasratta kaudu. Induktsioonkarastatud ja täppismalmist alus.
Eemaldatav sild võimaldab töödelda suuri detaile.
Karastatud peavõll tagab kõrge jooksutäpsuse.
Kergesti eemaldatavjuhtkruvi.

• Võimsus: 1500W
• Pinge: 400 V
• Spindli kiirus: 65-1810 p/min
• Spindli ava: 38 mm
• Tsentrite vaheline kaugus: 1000 mm
• Kaal: 530 kg

The Optimum OPTIturn TU 2506VB is a precision bench lathe designed for professional metalworking. Compact yet powerful, it offers high accuracy for turning, threading, and fine machining tasks.

Technical Specifications:

• Motor power: 1.1 kW
• Voltage: ~50 Hz
• Center height: 125 mm
• Distance between centers: 550 mm
• Swing over bed: 246 mm
• Bed width: 134 mm
• Spindle speed: 50 – 2500 rpm (2 ranges, electronically adjustable)
• Spindle taper: MT4
• Spindle bore: Ø 26 mm
• Top slide travel: 70 mm
• Cross slide travel: 110 mm
• Longitudinal feed: 0.07 – 0.4 mm/rev
• Thread cutting (metric): 0.2 – 4 mm/rev
• Thread cutting (inch): 56 – 8 TPI
• Tool holder height: 12 mm
• Tailstock taper: MT2
• Tailstock travel: 65 mm
• Dimensions: 1250 × 650 × 420 mm
• Weight: 132 kg

Included Accessories:

• 3-jaw chuck Ø 125 mm
• Fixed tailstock MT2 – MT4
• Chuck guard and chip tray
• HSS turning tools
• 4-position tool post
• Gear set for threading
• Service tools

Applications: Metalworking, precision turning, threading operations.

Compact and precise metal lathe designed for small workpieces and workshop applications. Offers reliable performance and accurate machining in a compact size.

Features:

• Electronically variable speed control
• DC motor for stable performance
• Hardened and ground cast iron prism bed for precision
• Spindle run-out accuracy ≤ 0.015 mm
• Automatic longitudinal feed and threading capability
• 3-jaw chuck included as standard
• Forward/reverse rotation
• Emergency stop and safety switch systems

Technical data:

• Power: 450 W
• Voltage: 230 V
• Speed range: 120–3000 rpm
• Max turning capacity:

between centers: approx. 265 mm

swing diameter: ~150 mm

• Dimensions: approx. 570 × 340 × 300 mm
• Weight: approx. 23 kg

Scope of delivery:

• 3-jaw chuck (Ø 80 mm)
• Change gears set
• Tool holder and accessories

• Hardened and ground Z-axis guideway
• Precisely machined carriage
• DC 24 volt electrics
• Motor protection switch
• Main motor electrically braked
• Guaranteed concentricity of the spindle nose better than 0.015 mm
• Smooth-running feed gear with rounded gears running in an oil bath
• Hardened main spindle mounted in adjustable, precise tapered roller bearings
• Right/left rotation switchable on the bed slide
• Two-channel safety electronics
• Handwheels with adjustable fine scaling 0.04 / 0.02 mm
• Safety handwheels with disengagement function according to EN23125 in the X and Z axis
• Switch rod on the bed slide for selecting longitudinal or face feed
• Switch with life cycle calculation tested in accordance with EN ISO 13849
• Machine base in sturdy steel construction
• Quadruple steel holder
• Emergency stop switch right and left

• Hardened and ground Z-axis Guideway
• Spindle mounting Camlock DIN ISO 702-2 No. 4
• Guaranteed concentricity of the spindle nose better than 0,015 mm
• Smooth-running feed gear with rounded gearwheels running in oil bath
• Emergency-stop pushbutton
• Hardened main spindle mounted in adjustable precision taper roller bearings
• Hand wheels on slide with adjustable fine scaling 0,04 / 0.01 mm
• Heavy ribbed prismatic bed made of grey cast iron, inductively hardened and precision ground
• Circular runout accuracy on lathe chuck better than 0,04 mm
• Quadruple steel holder
• All guides can be readjusted by V-guides
• Hardened spindle nose
• Lead spindle for thread cutting or automatic longitudinal turning
• Lead spindle and feed spindle mounted in two sintered bearings
• Automatic longitudinal / facing feeds
• Riding stock for taper turning ± 5 mm adjustable
• Riding stock sleeve and handwheel with adjustable fine scaling 0,02 mm
• Fast, easy and tool-free adjustment of the tailstock by means of clamping lever

• Hardened and ground Z-axis guideway
• Motor protection switch
• Control cabinet with 24 V DC power supply
• Partial enclosure with included, large dimensioned chip guard
• Chip guard with integrated position indicator, coolant hose and additional control panel
• Two-channel safety electronics
• Safety handwheels with disengaging function in the X- and Z-axis
• Face and top slide spindle is hardened and ground and adjustable via split spindle nut
• Lead and traction spindle cover
• Finely graduated feed and tapping range
• Energy chain for gentle guiding of cables and hoses
• Standard gears for metric thread pitches and modular threads are mounted in the machine. Change gears for inch and D.P threads optionally available
• Switches with life cycle calculation tested according to EN ISO 13849
• Decoupled handwheels tested according to EN 23125
• Reduction of main spindle deceleration time by energy regeneration
• Chip tray can be pulled out to the front
• Coolant device
• Quick-change steel holder SWH 5-B
• Steel holder 25 x 120 type D for square chisel 20 mm
• LED machine lamp for complete illumination of the working area
• Cutting constant VSC

• Precisely manufactured
• Hardened and ground Z-axis guideway
• Guaranteed concentricity of the spindle nose better than 0.009 mm
• Rolled trapezoid spindles
• Leadscrew stored in two sintered bearings
• Two tapered roller bearings in P5 quality
• Precisely crafted sled
• Handwheels with adjustable fine scale 0.04 / 0.01 mm
• Quadruple tool holder
• All guides can be adjusted by wedge strips
• Concentricity - chuck better than 0.05 mm
• Lead screw for thread cutting or automatic longitudinal turning
• Right / left rotation in the control panel switchable
• Tailstock for taper turning ± 5 mm adjustable
• Tailstock quill and handwheel with adjustable fine scale 0.02 mm
• Fast, easy and tool-free adjustment by means of a clamping lever
• Emergency stop impact switch
• thrust bearing
• Extensive accessories
• 3-jaw lathe chuck in the standard scope of delivery
• Stable value

TU 2406V

• Speed change easily adjustable via potentiometer
• Digital speed display
• EMC filter class C1

• Precise processing
• Powerful, maintenance-free engine
• Heavily ribbed prism bed made of gray cast iron, inductively hardened and precision ground
• Smooth-running feed gear with rounded gears running in an oil bath
• Hardened and ground Z-axis guideway
• Guaranteed concentricity of the spindle nose better than 0.009 mm
• Concentricity on the lathe chuck better than 0.04 mm
• Automatic longitudinal / lead screw drive
• Lead screw for thread cutting or automatic longitudinal turning
• Quadruple tool holder
• All guides can be adjusted by wedge strips
• Right / left rotation in the control panel switchable
• Hardened main spindle mounted in adjustable precision tapered roller bearings
• Tapered roller bearings in P5 quality
• Hardened spindle nose with Ø 26 mm spindle bore
• Rolled trapezoid spindles
• Chip protection on the upper slide
• Upper slide on cross slide slidable
• Tailstock for taper turning ± 5 mm adjustable
• Tailstock quill and handwheel with adjustable fine scale 0.02 mm
• Fast, easy and tool-free adjustment by means of a clamping lever
• Leadscrew stored in two sintered bearings
• Change gear set in standard scope of supply for thread cutting
• Handwheels on the carriage with adjustable fine scale 0.04 / 0.01 mm
• thrust bearing
• 3-jaw lathe chuck in the standard scope of delivery
• Emergency stop impact switch
• Fully equipped, allowing the user to be productive immediately after commissioning

TU 2807V

• Quiet, powerful and brushless DC drive with excellent control characteristics
• High precision steel lining for higher speeds
• Speed change easily adjustable via potentiometer
• Digital speed display

• Machine bed made of heavily ribbed cast iron
• One-piece machine base made of steel
• High rigidity of the headstock housing due to heavily ribbed 25GG casting
• Precisely machined slide
• Shafts on needle bearings, all components are lubricated in an oil bath
• Bed guides hardened and precision ground
• All electronic controls can be reached centrally
• All gear wheels of the feed gear made of hardened steel
• Handwheels decoupled and tested in accordance with EN 23125
• Two-channel safety electronics
• Switch with life cycle calculation, tested in accordance with EN ISO 13849
• Complete lead and pull spindle cover
• Complete illumination of the work area
• Service-friendly removable rear panel
• Hardened and ground face spindle ensures enormous accuracy and durability
• High chip removal during roughing is no problem thanks to the high cutting capacity
• Energy chain for gentle cable and hose guidance
• Lockable chip guard moves with the bed slide with integrated position indicator and coolant hose, can be moved manually
• No change wheels necessary
• With safety device to prevent simultaneous operation of tapping and feed mechanism
• Electronic feed switch-off of the Z-axis
• Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning according to DIN
• Electric position switch-off with quadruple position stop
• Three-jaw lathe chuck included as standard
• Quick-change steel holder SWH 7-C
• Steel holder 32 x 130 type D for square chisel 25 mm
• Large spindle bore
•
  Manufacturer
  Optimum Maschinen Germany GmbH
  Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
  info@optimum-maschinen.de



• Machine bed made of heavily ribbed cast iron
• One-piece machine base made of steel
• High rigidity of the headstock housing due to heavily ribbed 25GG casting
• Precisely machined slide
• Shafts on needle bearings, all components are lubricated in an oil bath
• Bed guides hardened and precision ground
• All electronic controls can be reached centrally
• All gear wheels of the feed gear made of hardened steel
• Handwheels decoupled and tested in accordance with EN 23125
• Two-channel safety electronics
• Switch with life cycle calculation, tested in accordance with EN ISO 13849
• Complete lead and pull spindle cover
• Complete illumination of the work area
• Hardened and ground face spindle ensures enormous accuracy and durability
• High chip removal during roughing is no problem thanks to the high cutting capacity
• Lockable chip guard moves with the bed slide with integrated position indicator and coolant hose, can be moved manually
• Service-friendly removable rear panel
• No change wheels necessary
• With safety device to prevent simultaneous operation of tapping and feed mechanism
• Electronically braked motor
• Electronic feed cut-off of the Z-axis
• Electrical position switch-off with quadruple position stop
• Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning in accordance with DIN
• Three-jaw lathe chuck included as standard
• Large spindle bore

• Precise processing
• Heavily ribbed prism bed made of gray cast iron, inductively hardened and precision ground
• Hardened and ground Z-axis guideway
• Smooth-running feed gear with rounded gears running in an oil bath
• Guaranteed concentricity of the spindle nose better than 0.009 mm
• Concentricity on the lathe chuck better than 0.04 mm
• Quadruple tool holder
• All guides can be adjusted by wedge strips
• Right / left rotation in the control panel switchable
• Hardened main spindle mounted in adjustable, precision tapered roller bearings
• Tapered roller bearings in P5 quality
• Hardened spindle nose
• Large spindle bore Ø 38 mm
• Lead screw for thread cutting or automatic longitudinal turning
• Guide and feed shaft stored in two sintered bearings
• Automatic longitudinal / flat feeds
• Lead screw and tension spindle cover
• Tailstock for taper turning ± 5 mm adjustable
• Tailstock quill and handwheel with adjustable fine scale 0.02 mm
• Fast, easy and tool-free adjustment by means of a clamping lever
• Handwheels on the carriage with adjustable fine scale 0.04 / 0.01 mm
• Change wheel set in the standard scope of supply for thread cutting
• Emergency stop impact switch

TU 3008

• fan belt

TU3008G

• transmission

TU 3008V

• V-belt and brushless drive
• Quiet, powerful and brushless DC drive with excellent control characteristics
• High precision steel lining for higher speeds
• Digital speed display
• Power supply 230 V

• Hardened and ground Z-axis guideway
• Guaranteed concentricity of the spindle nose ≤ 0.015 mm
• Spindle holder Camlock DIN ISO 702-2 No. 8
• Lead screw cover
• Precisely machined slide
• All guides can be adjusted using gibs
• Right/left rotation on bed slide switchable via switching spindle
• Two-channel safety electronics
• Central lubrication in the bed slide
• Upper slide adjustment range ± 90
• Main spindle runs in oil bath
• Shafts and wheels running in oil bath
• Gear wheels smooth-running, hardened, ground and mounted with 2 adjustable precision tapered roller bearings
• Switch with life cycle calculation, tested in accordance with EN ISO 13849
• Handwheels with adjustable fine scaling 0.04 / 0.02 mm
• Safety handwheels with disengagement function in accordance with EN23125 in the X and Z axes
• Gear wheels and shafts hardened and ground, running in an oil bath in precision bearings
• Clearly arranged selector lever for switching the feed speeds
• Closed design of the high-speed feed gearbox
• Emergency stop impact switch, motor protection switch, lockable main switch
• Emergency stop device with foot actuation
• Tailstock for taper turning ± 10 mm adjustable
• Tailstock quill and handwheel with adjustable fine scaling 0.025 mm. Quick, easy and tool-free adjustment by means of clamping lever
• Energy chain for gentle cable and hose guidance
• Heavily ribbed prism bed, induction-hardened and precision-ground from gray cast iron
• Coolant device with separate coolant tank with level indicator and oil separator; easy and complete emptying and cleaning in accordance with DIN
• Adjustable scale of the thread gauge
