NEW PRODUCTS

EV WS / EA hood incl. relief valve
F4x1/4" connection
preset to 7.8 to 9.8bar
adjustable up to max. 16bar
at 400V max. 16Ampere
at 500V max. 9Ampere
Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Advantages of DRYPOINT eco control

• Integrated DRYPOINT M Plus solution: filtration and dryer in a compact form, as well as condensate drain integrated
• Filtration on the spot in the treatment chain where the highest efficiency is achieved
• Easy maintenance / replacement of filter element as with a filter
• Application-specific degree of dryness can be selected
• Consistent compressed air quality under fluctuating operating conditions
• Energy saving through minimization of purging air consumption for actual amount of useful air and degree of drying
• Power evaluation via LED, forwarding via current output 4 … 20 mA possible
• User-friendly: Easy to use, test functions, error messages
• Concept based on the fail-safe principle, error message can be picked up via potential-free contact

Functionality of the DRYPOINT® M eco control

Based on the measurement result from the sensor, the control software decides in defined cycles whether and how long the full amount of purge air has to be provided to achieve and stabilize the required degree of dryness. This process is implemented by means of a targeted clocking of a solenoid valve. In each cycle, the duration of the two process sections described below varies in order to keep the degree of drying within the specified tolerance range.

Manufacturer
BEKO Technologies GmbH
Im Taubental 7, 41468 Neuss, Germany
www.beko.de

• Innovative LOGIN control with 4.3" touch screen for easy operation and full control of all functions.
• Rotation direction control for the motor, prevents damage during start-up or after a change of location
• High cooling effect and low noise level due to thermostatically controlled radial fan
• Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
• Aftercooler reduces the effort for drying and filtration of the generated compressed air
• Easy to service: simple removal and installation of all components requiring maintenance

Latest generation IE4 permanent magnet motor for max. energy efficiency

• Larger speed/load range
• Larger delivery volume supply range
• Extremely energy efficient - up to 50% energy consumption savings compared to a "fixed speed" model
• Very quiet operation - only 64 dB

Energy saving through frequency control

• Ideal for frequently changing compressed air consumption
• Compressor delivery rate adjusts to actual consumption
• Electronic control monitors motor and compressor speed and keeps line pressure constant even when consumption fluctuates widely
• Advanced and efficient cutting-edge technology in the smallest possible space

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Ideal in combination with prefabricated solutions
• Permanently sealed without pressing
• Installation even in confined spaces
• Detachable fittings can be reused
• Cost savings through quick assembly

• Permanently sealed without pressing
• Cost savings through quick and easy assembly
• Ideal in combination with prefabricated solutions
• Compatible with other standards-compliant pipes
• No confusion of contours possible
• Installation even in confined spaces
• Extraction forces far beyond the requirements of the standard
• Pipe components can be dismantled and reused
• Numerous national and international approvals
• O-rings included

Manufacturer
Aalberts integrated piping systems B.V.
Oude Amersfoortseweg 99, 1212 NL Hilversum, Netherlands
www.aalberts-ips.com

• Sintered filter with centrifugal principle
• For compressed air and neutral gases
• Inlet pressure 1.5 - 16 bar
• Suitable for temperatures from -10 to +50°C
• Semi-automatic condensate drain
• For vertical installation

• Sintered filter with centrifugal principle
• For compressed air and neutral gases
• Inlet pressure 1.5 - 16 bar
• Suitable for temperatures from -10 to +50°C
• Semi-automatic condensate drain
• For vertical installation

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Cylinders and cylinder heads with long ribs for optimum heat dissipation;
• carefully balanced crankshaft made of cast iron for better concentricity
• Stainless steel valves with high air flow
• Pulley designed as a fan
• Optimized airflow, high fan performance
• Highly efficient air filter with labyrinth intake channel for noise reduction

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• The two-stage compression 2-cylinder high-performance unit enables a very low speed, resulting in a particularly quiet and low-vibration run
• Large fan ensures optimal cooling
• Intercooler and aftercooler ensure a low container inlet temperature and thus reduce condensation
• High quality electric motor with high torque
• Electric motor equipped with motor protection switch
• Fifteen-year rust-through warranty on inside and outside hot-dip galvanized compressed air tank
• Flexible armored hose line with heat protection prevents vibration breakage
• High-quality CONDOR pressure switch as standard
• From 7.5 kW as standard with star-delta switch with operating hours counter
• Ready for connection with all fittings

Additional equipment K-version:

• Refrigerated dryer with integrated automatic steam trap for dry compressed air, longer service life of compressed air tools and avoidance of disturbances in pneumatic controls
• Fine filter for separating condensate and solid impurities with particles up to 1 μ in front of the refrigeration dryer

Equipment

• Automatic steam trap on the compressed air tank
• No unnecessary pressure loss


• Condensate conditioner for oil-water separation
• Important notes on condensate treatment can also be found in the section on compressed air preparation.


• Fine filter for separating condensate and solid impurities with particles up to 1 μm
• Compressed air quality according to ISO 8573-1
• As a pre-filter in front of the refrigeration dryer


• Refrigerated dryer with integrated automatic steam trap
• Pressure dew point at 5 °C, ambient temperature 25 °C, atmospheric dew point at -22 °C

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Innovative LOGIN control with 4.3" touch screen for easy operation and complete control over all functions
• Connection of up to eight compressors possible, no matter if with constant or variable speed
• All information on current operating status at a glance
• Rotation direction control for the motor, prevents damage during start-up or after a change of location
• Low noise emission (only max. 67 dB) during operation, due to extremely low speed of the screw compressor and use of a low-noise radial fan
• Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
• Aftercooler reduces the effort for drying and filtration of the generated compressed air
• Star-delta switching as standard
• Easy to service: simple removal and installation of all components requiring maintenance

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Extremely quiet due to sound-insulated housing and additional silencer on the intake filter
• Two-cylinder high-performance unit made of grey cast iron with low speed guarantee particularly quiet and low-vibration operation -> less wear - longer service life
• Large fan impeller on the compressor and temperature-controlled radial fan on the housing ensure optimum cooling of the entire interior
• Equipped with glycerine pressure gauge, operating hours counter and error display via LED lights

• Extremely quiet due to sound-insulated housing and additional silencer on the intake filter
• Suitable for installation even in noise-sensitive areas and the direct working environment
• Two-cylinder high-performance unit made of grey cast iron with low speed warrantys particularly quiet and low-vibration operation: less wear and longer service life
• Large fan impeller on the compressor and temperature-controlled radial fan on the housing ensure optimum cooling of the entire interior
• Inter- and aftercooler as well as an additional air duct between motor and compressor reduce condensate formation
• High-quality Condor pressure switch
• Equipped with glycerine pressure gauge, hour meter and fault indication via LED lights
• Quality electric motor with motor protection switch and start-up relief
• Integrated phase monitoring
• Facility for easy tensioning of the V-belt
• Service-friendly design
• Ready for connection with all fittings and safety devices
• Models with compressed air tank: Galvanised air reservoir inside and out with 15-year warranty against rusting through

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Two-stage high-performance 2-cylinder engine with gray cast iron cylinder block
• Low speed for quiet, low-vibration operation and long life
• Large fan for optimum performance Cooling
• High-quality electric motors equipped with motor protection switch
• With phase inverter for easy manual reversal of the direction of rotation
• Intermediate and aftercooler reduce condensation
• Maintenance block with two pressure gauges for tank pressure and working pressure and high-quality CONDOR pressure switch
• Fully automatic on-off operation
• Ready for connection with all fittings
• Fifteen-year rust-proofing on inside and out external hot-dip galvanized compressed air tank

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Wired remote control for AIRCRAFT energy saver Art. 2150001 and 2150003
• Including 5 m cable

Note: The electrical connection must be made by a licensed company or by purchasing a new energy saver by factory assembly.
Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Manufacturer
Reliance Worldwide Distribution (Europe) Limited
Ludwig-Erhard-Allee 30, 33719 Bielefeld, Germany
www.johnguest.com

Higher efficiency - lower costs
The innovative and highly efficient ASDB series uses a patented 3-circuit heat exchanger system. In combination with the glycol cycle, a significant energy saving is achieved. The glycol mass acts like a cold-storing medium. The ASD dryers are particularly suitable for partial load operation and for irregular compressed air requirements. By using the ASD dryers, you can noticeably save operating costs.
Operation and advantages of the glycol cycle
The water-glycol mixture is cooled when not all the cooling energy is needed to cool the compressed air. When the refrigeration compressor shuts off during partial load operation, the compressed air is cooled down by the cold stored in the glycol mass. Only when the mass is no longer cool enough, the refrigerant compressor turns on again. Therefore, the ASD dryers show their potential for savings, especially during partial load operation and irregular compressed air requirements. When the air compressor starts again after a pause and releases compressed air into the piping system, the ASD dryers immediately cool this compressed air to dew point because the glycol mass immediately provides the temperature required. Many other systems, in which the refrigeration compressor can cool down to operating temperature only after a start-up period, allow humid air to flow into the supply network during this time, with all the adverse effects.
The advantages at a glance

• Improved energy efficiency thanks to patented 3-circuit heat exchanger system
• Energy saving and longer service life by switching off the refrigeration compressor in partial load operation
• Optimal dew point control with additional temperature sensor for the glycol control
• Condensate drainage without pressure loss through integrated electronic, level-regulated condensate separator
• Optimum performance under all load and ambient conditions thanks to variable fan speed control
• By using quality components longevity and reduction of service costs
• Operating cost reduction with active environmental protection

The operation of the patented 3-circuit heat exchanger system

1. Warm saturated with compressed air compressed air flows into the heat exchanger.
2. Pre-cooling of the inlet air is caused by the countercurrent cold outlet air in the heat exchanger.
3. Input air is brought to dew point temperature by the refrigerant circuit, causing condensate.
4. Condensate is collected and removed in the integrated electronic, level-regulated condensate separator.
5. Glycol circulation stores excess energy and cools the intake air at partial load.
6. The refrigeration compressor switches off at partial load, which can double its service life.
   (Explanation in product description series ASD under " Function and advantages of the glycol cycle " )

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• EasyTRONIC MICRO II electronic control with pressure sensor operation as standard, thus preventing motor overload, reducing wear and extending service life
• With star-delta switch
• High cooling effect and lower noise level due to thermostatically controlled radial fan
• Operating hours counter records load and overrun times, thus ensuring compliance with maintenance intervals - Indication of maintenance requirements via automatic message
• Rotation direction control for the motor avoids possible damage during commissioning or after a change of location
• Screw compressor with wear-resistant Poly V ribbed belt drive and slide clamping system
• Easy maintenance due to easily accessible elements
• Optimum operating temperatures due to thermostatically controlled fan, optimum cooling air flow and generously dimensioned heat exchanger, thus longer service life, lower fluctuations in oil temperature than with thermostat control
• Aftercooler as standard, thus less effort for drying and filtration of the generated compressed air
• Small external dimensions, thus easy transport and installation

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Cylinders and cylinder heads with long ribs for optimum heat dissipation;
• carefully balanced crankshaft made of cast iron for better concentricity
• Stainless steel valves with high air flow
• Pulley designed as a fan
• Optimized airflow, high fan performance
• Highly efficient air filter with labyrinth intake channel for noise reduction

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Extremely quiet due to sound-insulated housing and additional silencer on the intake filter
• Two-cylinder high-performance unit made of grey cast iron with low speed guarantee particularly quiet and low-vibration operation -> less wear - longer service life
• Large fan impeller on the compressor and temperature-controlled radial fan on the housing ensure optimum cooling of the entire interior
• Equipped with glycerine pressure gauge, operating hours counter and error display via LED lights

• Extremely quiet due to sound-insulated housing and additional silencer on the intake filter
• Suitable for installation even in noise-sensitive areas and the direct working environment
• Two-cylinder high-performance unit made of grey cast iron with low speed warrantys particularly quiet and low-vibration operation: less wear and longer service life
• Large fan impeller on the compressor and temperature-controlled radial fan on the housing ensure optimum cooling of the entire interior
• Inter- and aftercooler as well as an additional air duct between motor and compressor reduce condensate formation
• High-quality Condor pressure switch
• Equipped with glycerine pressure gauge, hour meter and fault indication via LED lights
• Quality electric motor with motor protection switch and start-up relief
• Integrated phase monitoring
• Facility for easy tensioning of the V-belt
• Service-friendly design
• Ready for connection with all fittings and safety devices
• Models with compressed air tank: Galvanised air reservoir inside and out with 15-year warranty against rusting through
• Star-delta gearstick as standard

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Absorbed oils are reliably bound in hermetically sealed cartridges - no contact with contaminants
• Easy adjustment to changing compressed air and condensate requirements
• Condensate is actively pressed through the pre-filter and main filter with light blasts of compressed air
• Permanent function monitoring
• Fail-safe mode in the event of a power failure and loss of compressed air: QWIK-PURE continues to work like conventional gravity separators

QWIK-PURE series

• Absorbed oils are reliably bound in hermetically sealed cartridges - no contact with contaminants
• Simple, clean and ergonomic cartridge replacement
• Simple adjustments to changing compressed air and condensate requirements
• Sizing according to service interval or compressor capacity

From QWIK-PURE 15

• Condensate is actively pressed through the pre-filter and main filter with light blasts of compressed air
• Permanent function monitoring
• Integrated FRC control unit: reliable display of the remaining capacity of the cartridges and automatic monitoring of when condensate needs to be pushed through with light blasts of compressed air
• Integrated monitoring optimally utilizes the cartridges
• Remote monitoring possible thanks to network capability
• No overflowing of the system thanks to active operating principle with automatic drainage
• Fail-safe mode in the event of power failure and loss of compressed air: independent initiation of measures and triggering of alarms in the event of problems. For safe operation, QWIK-PURE then continues to work like conventional gravity separators.

Manufacturer
BEKO Technologies GmbH
Im Taubental 7, 41468 Neuss, Germany
www.beko.de

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
