Punching machine PM 10 M

• For precision surface grinding
• Maximum stiffness and stability thanks to tension-free re-heated and hardened cast iron construction
• High-quality spindle with precision cone roller bearings (circular accuracy 2 microns)
• Electromagnetic clamping plate for fixing the workpiece including automatic demagnetization function
• Automatic central lubrication for all slides and spindles
• Hand scraped and Turcite-B-coated V-flat guides guarantee extremely uniform, low-friction movement and highest precision
• Halogen working light dustproof, completely contact-proof and protected against jet water according to IP65
• Second grinding wheel flange included in delivery

Automatic feed control AD 5
The fsM series models are equipped with automatic feed control (AD 5). Different grinding cycles are available: surface loops with delivery at the starting point, groove loops with delivery at the starting point, groove loops with delivery at the start and end points. The delivery of the grinding wheel can be individually designed depending on the workpiece. The total grinding size is divided into coarse and fine delivery, the delivery steps can be freely entered, depending on the application, with a minimum resolution of up to 0.001mm. The possibility to program dead runs after a certain number of delivery steps as well as passages for firing after reaching the grinding measure provides the best grinding results.
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Versatile range of applications such as drilling, reaming, thread cutting
• Electrically braked motor
• Operating elements with 24V DC electrics and 2-channel safety chain in accordance with DIN EN 12717
• Heavy, solid, high-quality casting
• Wide reach due to horizontally adjustable machine head
• Clearly arranged control panel
• Smooth-running swivel and traversing axles
• Sturdy, torsion-resistant construction of the boom
• Boom height adjustment via powerful motorized drive and lifting spindle
• Gearbox of the drill head runs in an oil bath
• Boom guideways hardened and precision-ground
• Gear wheels made of chrome-nickel steel, hardened and precision-ground for quiet and smooth running
• Drill head and column can be clamped or released together or separately
• Right/left rotation
• Solid, precise drill table, large dimensions
• Hardened and ground clamping table with parallel T-slots
• Machine light
• Overload protection
• Thick-walled cast iron column ensures smooth running and stability
• LED lamp
• Coolant system with coolant tank in the machine base
• Clamping table included in scope of delivery
• Column and headstock mechanically clamped

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Industrial motor
• Quiet-running spindle thanks to new spindle design
• Machine operation with safety electrics in 24 V DC voltage
• Guaranteed concentricity ≤ 0.02 mm measured in the drilling spindle
• Clockwise/anticlockwise rotation
• Precision spindle bore
• Control panel with user-friendly, dirt and water-resistant membrane keypad
• Speed display
• Separate emergency stop switch
• Thread cutting function
• Precisely machined, sturdy drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated through 360
• Digital depth gauge
• LED machine light integrated in the drill head
• V-belt cover with safety switch
• Thick-walled steel column for high force absorption and stability
• Massive, large base plate with T-slots
• Heavy-duty design of the entire machine

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Revolutionary simple, very fast and comfortable operation
• Compact and space-saving
• With practical shelves for all individual segments and bending rails
• Ideal for bending aluminum, copper, steel, stainless steel, etc.
• Precise bend angle adjustment up to 170 °
• Powerful electromagnetic system for optimum bending results
• The clamping across the entire width guarantees a clean bend
• Very high bending capacity
• The main pressure is on the upper cheek, not on the machine
• The unique centerless hinges ensure precise power transmission at the bending point
• Backgauge, segmented upper jaw and foot pedal are standard

With practical shelves for all individual segments and bending rails

Extremely fast and easy operation - in just a few steps you can turn your sheets into the desired shape without great effort

Step 1:

• Place the workpiece on the magnetic conductors and adjust using the bending edge

Step 2:

• Choose the right bending segment, place it on the workpiece and activate the magnet

Step 3:

• At the bend stop you can set the exact bending angle. Perform the bending process

The conversion for further bending operations is done in a few steps.

Note: Do not use the machine with pacemakers

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
• Different tool variants available E, S2, HS2 and HSG
• The powerful auxiliary cylinder facilitates bending
• Next passage between top and bottom cheek of up to 25 mm
• Self-lubricating plain bearings
• Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
• Adjustment of material thickness by means of knurled screw
• Adjustable stop for bending angle

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
