- Eyebolts on the frame for lifting
- The design, the puncture-proof PU foam tires and the transport handle allow easy transport to the place of use
- With 1-cylinder / 4-stroke Honda engine for off-grid operation
- Due to its independence from the power grid, it is particularly suitable for gardening and landscaping, mobile tire service and breakdown services as well as agriculture and forestry
- With idling and speed control, thereby adapting to the respective load conditions
- The high-performance gray cast iron unit and the low speed warranty maximum smoothness and a long service life.
- The large fan wheel and a cooling air baffle ensure optimum cooling of the compressor.
- Stable belt guard made of metal
- An aftercooler with large cooling fins ensures a low tank inlet temperature and therefore less moisture in the compressed air
- With all safety devices
- Ten-year rust-through warranty on powder-coated compressed air tank
Room amenities:Freewheel valve for less wear
- The freewheel valve avoids constant switching on and off
- After reaching the set pressure, the valve opens and the compressor runs without pressure
- When the pressure drops, the valve closes and the compressor works again on pressure
Service
- On the filter pressure regulator, you can fix the working pressure infinitely and remove pressure-reduced and filtered compressed air.
- Two pressure gauges show the tank u. Working pressure.
- As standard with quality quick coupling and high quality CONDOR pressure switch
Round protection
- The frame is at the same time a compressed air tank, holder for tool storage as well as all-round protection for all sensitive components
- Optimally protected and transportable with high performance
Eyebolts
- With two lifting eyes on the frame for lifting eg with a crane
Transport handle
- The two-handed grip allows easy transport to the job site
Shock mounts
- Equipped with two large and wide front swinging elements for stable stability
Tool tray
- Practical in everyday use as a storage for tools, plans, etc. and as protection against damage from above
High performance aggregate HOS
- The precisely machined piston is equipped with a high-alloy piston ring, oil scraper ring and oil scraper ring, which seal the piston from the cylinder wall.
- The crankcase is filled with oil, which is sprayed against the cylinder wall with each piston stroke.
- The oil scraper wipes the oil-wetted cylinder wall downwards.
PU foam tires
- The large, stable wheels with puncture-proof PU foam tires ensure easy and comfortable transport even on uneven ground
Control panel Ergonomically favourably positioned, clearly structured and self-explanatory
- manometer to display the tank pressure
- direct compressed air output with one-hand safety coupling from the compressed air tank
- filter pressure reducer to set the working pressure
- manometer to display the set working pressure
- compressed air output one hand Safety coupling for filtered compressed air
- mist lubricator for metered supply of lubricant to the tools
- compressed air outlet one hand safety coupling for filtered and lubricated compressed air
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
