Metallitööpingid

• Vise body made of high quality cast iron
• Guide surfaces hardened and ground
• Hardened and ground jaws, replaceable
• Booster system, little effort, high pressure during clamping
• Protected spindle
• Wide clamping range by locking bolts with different hole distances
• With turntable, 360 ° rotatable
• Protected spindle

• For face and copy milling
• Made of special steel - highly tempered
• High axial and radial run-out accuracy
• Milling body with uneven pitch for particularly smooth running and even cutting
• Base body and clamping shank form a single unit, resulting in a short overhang length and stable clamping
• No additional milling cutter arbor is used
• Special geometry for milling at high speed
• Economical, as the insert can simply be turned further when the cutting edge is blunt (can be used up to twelve times)
• Indexable inserts Ø 10 mm

• Vise body made of high quality cast iron
• Guide surfaces hardened and ground
• Hardened and ground jaws, replaceable
• Booster system, little effort, high pressure during clamping
• Protected spindle
• Wide clamping range by locking bolts with different hole distances
• With turntable, 360 ° rotatable
• Protected spindle

• Robust construction for milling
• Guide surfaces hardened and ground
• Booster system, little force required, high pressure performance during clamping

4-lõualine isetsentreeriv treipingi padrun Ø 125 mm malmist. Tagab töödetaili täpse tsentreerimise, tugeva kinnituse ja töökindla tulemuse professionaalsetel treimistöödel.

• For plan and copy milling
• Made of special steel - highly tempered
• High concentricity and concentricity
• Milling body with uneven pitch for particularly smooth running and uniform cutting
• Body and clamping stem form one unit, thus short overhang length and stable tension
• No additional cutter cotter pin is used
• Special geometry for milling at high speed
• Economical, as with a blunt cutting edge, the plate can be simply further rotated (up to twelve times usable)
• Indexable inserts Ø 10 mm

• Recording 27 mm

• Finely ground to 0.01 mm
• Length 150 mm x width 8.5 mm
• 18 pcs.
• Sizes: 2 x 14mm / 2 x 16mm / 2 x 20mm / 2 x 24mm / 2 x 30mm / 2 x 32mm / 2 x 36mm / 2 x 40mm / 2 x 44mm

• High achievable vacuum
• Short changing times by one-hand operation
• Low weight due to optimized structure
• Safe locking by toggle principle
• Precise guidance through optimized geometry
• Low air consumption

• Robust design for milling
• Guide surfaces hardened and ground
• Booster system, little effort, high pressure during clamping
• Wide clamping range by locking bolts with different hole distances
• Made of high quality stainless steel
• Long life due to high quality
• High clamping force

Pööratav lünett detailidele läbimõõduga kuni 34 mm. Sobib OPTIMUM TU 2304 treipingile ning tagab töödetaili stabiilse toe täpseks ja kvaliteetseks treimiseks.
