Oil-water separator WOS 20

SKU: 52-2058250

Tootjakood: 2058250

EAN: 9006248017122

Thanks to patented technology, regular service is possible in only 30 seconds and without expensive cleaning
Wall and floor mounting possible
Works reliably with any steam trap
Suitable for all common compressor oils
Operating media: condensate (air, water, oil), non-aggressive, not suitable for emulsion
Quick and clean change of the filter cartridge
No settling tank necessary (no bacteria formation)
Easy installation due to compact design and small dimensions
Connection via quick couplings

Function Description:

Multi-stage oil-water separation via an oil-attracting filter and activated carbon
After the end of the service life of the filter element this is unscrewed and disposed of completely
Filter element is tightly closed with plastic cover, so that residual condensate can remain in it
Locked filter element can be disposed of according to current regulations

service interval

after occurrence of one of the following three cases:
4,000 operating hours of the compressor at compressor oil transfer of 2.5 mg / m3
Discoloration of the polypropylene medium - analysis by simple visual inspection
At the latest after 12 months (regardless of the operating hours of the compressor)

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Täishind: 1299,16€

Hind: 1171,92€

Kogus:

i h

Saadavus: Laos

Hankija ladu

Laagri

Tellimisel. Eeldatav tarneaeg 7 päeva

Mustamäe

Tellimisel. Eeldatav tarneaeg 7 päeva

Orienteeruv kuutasu järelmaksuga ostes

Periood

Sissemakse

Kuumakse

Tehnilised andmed
Võta ühendust

Pakendi mõõdud

Kaal

16.5

Tehnilised näitajad

Töötemperatuur

1.5 – 65

Kauba info

Brutokaal

16.5
