Straight connector (brass) 32 mm

• Innovative LOGIN control with 4.3" touch screen for easy operation and full control of all functions.
• Energy-efficient IE4 motor
• Rotation direction control for the motor, prevents damage during start-up or after a change of stand location
• High cooling effect and low noise level due to thermostatically controlled radial fan
• Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled radial fan, optimum cooling air flow and generously dimensioned heat exchangers
• Aftercooler reduces the effort for drying and filtration of the generated compressed air
• Star-delta switching as standard
• Easy to service: simple removal and installation of all components requiring maintenance

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Normal oil lubricator with suction device under pressure
• For pressure inlet max. 16 bar
• Suitable for temperatures from -10 to +50°C
• For vertical installation
• Oil type CL 32 according to DIN 51517-ISO VG 32 - oil refill under pressure up to max. 10 bar possible

• Normal oil lubricator with suction device under pressure
• For pressure inlet max. 16 bar
• Suitable for temperatures from -10 to +50°C
• For vertical installation
• Oil type CL 32 according to DIN 51517-ISO VG 32 - oil refill under pressure up to max. 10 bar possible

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Special

• Drying by partial vapor pressure compensation of water vapor by diffusion in combination with a highly selective membrane
• No change in the compressed air composition - can be used for breathing air treatment

Efficient

• Reaches the required pressure dew point with low energy consumption
• Very fast availability of dried compressed air
• Filtration and drying compact in one device

Robust

• Housing made of seawater-resistant aluminum
• Low-maintenance, currentless technology

System-compatible

• Modularly combinable with CLEARPOINT Filter program
• Can be used anywhere along the compressed air treatment chain - can also be integrated into system technology

• The ultimate membrane dryer technology with integrated nanofilter
• Filtration and drying in one housing (simple filter element change)
• Low purge air requirement (Twist 60 technology)
• Availability of dried compressed air immediately without running-in phase
• Safe drying due to the high partial vapor pressure gradient
• No change in the compressed air temperature and composition
• Proven 100,000 times
• Maintenance-free (except filter element change)
• For diverse applications, including for breathing air treatment
• Also ideal for use directly behind the compressor / aftercooler
• Optionally also for higher loads (assembly potting, 16 bar, 70°C)
• For a reliable function of the DRYPOINT M membrane dryer must meet the following requirements:
1. The incoming compressed air must not contain any liquid condensate
2. Particles larger than 1 μm must be separated before the membrane dryer
3. The oil content of the compressed air must not exceed 0.01 mg/m³.

• DRYPOINT M membrane dryers have been an alternative to existing ones for years Compressed air drying process proven.

Advantages DRYPOINT M PLUS

• Proven process of highest reliability and functional safety
• Immediate availability of dry compressed air, even when working discontinuously
• Low purge air requirement, compressed air drying can be adjusted to the application
• Compact and robust, small space requirement due to low overall height
• Compressed air inlet and outlet on one level (filter version), easy to combine with CLEARPOINT filters
• Maintenance and wear-free as there are no moving parts
• No reduction in the oxygen content, therefore also suitable for breathing air treatment
• No electrical connection, also suitable for Ex areas
• Long service life in case of use of CLEARPOINT filters
• Environmentally friendly, does not require CFCs / CFC-containing refrigerants or adsorbents
• Complete solution: filtration and dryer in a compact form, integration of drain pipe
• Filtration at the point in the treatment chain where the highest efficiency is achieved
• Easy maintenance / replacement of filter element as with a regular filter

Filter element: N (nanofilter)

• The CLEARPOINT filter element type N is used to separate solid particles down to 0.01 micron, water and oil aerosols . The element has a multi-stage structure for efficient and long-lasting filtering. In the first stage, coarse particles are retained by a pre-filter layer. In the second stage, finer particles are absorbed by a depth filter bed made of high-performance borosilicate fiber fabric. Due to the very large cavity volume of the filter medium (96%), a very high dirt holding capacity is achieved. The filter medium is specially impregnated in order to avoid cross-sectional swelling of the individual fibers.

Trap: Float trap

• The basic version includes a float drain.

Size 10 - 40

• This size is for the demand-oriented compressed air drying of medium volume flows configured. Different levels of drying of the compressed air are achieved through different purge air settings.

Manufacturer
BEKO Technologies GmbH
Im Taubental 7, 41468 Neuss, Germany
www.beko.de

• Compressed air filters are used for highly efficient removal of solid particles, water, oil, aerosols, hydrocarbons, odors and vapors from compressed air systems.
• To achieve the required quality of compressed air, filters that gradually remove all types of solid and liquid contaminants from the compressed air must be installed in the compressed air line
• Your advantages through better quality compressed air:
• Safe filtration of both liquids such as water and aerosols as well as particles, dust and gases
• Better working and production conditions
• Optimum protection of connected tools and machines
• Improved product quality through reduction of rejects
• Protection of the compressed air system against contamination
• Increase of productivity by reduction of instant maintenance

• for the separation of oil vapors, odors and flavorings via adsorption and in the second stage of solid particles
• Residual content of oil vapor up to 0.005 mg / m³ at 20 ° C and 1 bar
• Operating temperature 1.5 to 45 ° C
• Compressed air quality according to ISO 8573-1
• For compressed air of the highest quality, eg, for breathing air, in analytical technology or semi-luxury bottling
• Pure compressed air in connection with upstream ultrafine filter
• with filter element and manual drain

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

Maximum tank volume in a minimum of space - the space-saving solution

• Boiler batteries for up to 400 liters of additional air supply
• Available as 2-pack and 4-pack batteries
• All tank batteries also available in 13 bar version with 75 l tanks
• By connecting additional compressed air tanks, the tank volume is increased, whereby a higher air supply can be built up.
• Increased air demand can be covered at short notice
• If required, individual compressed air tanks can be disconnected from the compressed air supply via ball valves, which reduces the tank volume accordingly and thus builds up the pressure more quickly.
• Fifteen-year warranty against rusting through on the inside and outside of hot-dip galvanized air reservoirs.
• All tank batteries can be easily moved with the lift truck
