32cm replacement blade

The Bernardo Basic 2000 Pro is a heavy‑duty professional sliding table saw designed for precise cutting of solid wood and panel materials. It features a 2000 mm aluminium sliding table, a standard scoring unit, and a powerful drive system for continuous professional use.

The machine is equipped with a 315 mm main saw blade and a scoring blade, ensuring clean, chip‑free cuts in laminated and veneered panels. Its rigid steel and grey cast‑iron construction, large cast‑iron worktable, and maintenance‑free sliding carriage on hardened prism guides guarantee vibration‑free, accurate operation.

Key features:

• Power supply: 400 V / 50 Hz
• Motor output S1 (100%): 3.8 kW
• Motor power S6 (40%): 5.3 kW
• Max. blade diameter: 315 mm
• Blade bore: 30 mm
• Max. cutting height at 90° / 45°: 100 / 80 mm
• Main blade speed: 4,000 rpm
• Scoring blade speed: 5,800 rpm
• Sliding table: 2000 × 270 mm
• Max. rip capacity: 1200 mm
• Main table size: 800 × 385 mm
• Table extensions and side table included
• Dust extraction port: Ø 100 mm
• Net weight: approx. 270 kg

Standard delivery:

• 315 mm TCT saw blade (40T)
• Scoring blade 90 mm (12T)
• Blade guard with dust extraction outlet
• 2000 mm sliding table carriage
• Rip fence with fine adjustment
• Mitre fence with eccentric clamp and stop
• Extendable telescopic fence (up to 2260 mm)
• Table extension and enlargement
• Roller support table for large panels
• Push stick and service tools

• Võimsus: s1 - 3000W/ s6 - 4000 W
• Pinge: 400 V
• Ketta kiirus: 4000 p/min
• Saeketas: Ø 315 mm
• Maks. lõikekõrgus 90°/45°: 100/80 mm
• Imemisotsik: Ø 100 mm
• Laua mõõtmed: 800 x 820 mm
• Laua kõrgus: 870 mm
• Laua pikendus: 500x310/800x440 mm
• Liuglaua mõõdud: 2000 x 270 mm
• Kaal: 263 kg
