52-2058240
- Thanks to patented technology, regular service is possible in only 30 seconds and without expensive cleaning
- Wall and floor mounting possible
- Works reliably with any steam trap
- Suitable for all common compressor oils
- Operating media: condensate (air, water, oil), non-aggressive, not suitable for emulsion
- Quick and clean change of the filter cartridge
- No settling tank necessary (no bacteria formation)
- Easy installation due to compact design and small dimensions
- Connection via quick couplings
Function Description:
- Multi-stage oil-water separation via an oil-attracting filter and activated carbon
- After the end of the service life of the filter element this is unscrewed and disposed of completely
- Filter element is tightly closed with plastic cover, so that residual condensate can remain in it
- Locked filter element can be disposed of according to current regulations
service interval
- after occurrence of one of the following three cases:
- 4,000 operating hours of the compressor at compressor oil transfer of 2.5 mg / m3
- Discoloration of the polypropylene medium - analysis by simple visual inspection
- At the latest after 12 months (regardless of the operating hours of the compressor)
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2058210
- Thanks to patented technology, regular service is possible in only 30 seconds and without expensive cleaning
- Wall and floor mounting possible
- Works reliably with any steam trap
- Suitable for all common compressor oils
- Operating media: condensate (air, water, oil), non-aggressive, not suitable for emulsion
- Quick and clean change of the filter cartridge
- No settling tank necessary (no bacteria formation)
- Easy installation due to compact design and small dimensions
- Connection via quick couplings
Function Description:
- Multi-stage oil-water separation via an oil-attracting filter and activated carbon
- After the end of the service life of the filter element this is unscrewed and disposed of completely
- Filter element is tightly closed with plastic cover, so that residual condensate can remain in it
- Locked filter element can be disposed of according to current regulations
service interval
- after occurrence of one of the following three cases:
- 4,000 operating hours of the compressor at compressor oil transfer of 2.5 mg / m3
- Discoloration of the polypropylene medium - analysis by simple visual inspection
- At the latest after 12 months (regardless of the operating hours of the compressor)
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2053440
- Compressed air filters are used for highly efficient removal of solid particles, water, oil, aerosols, hydrocarbons, odors and vapors from compressed air systems.
- To achieve the required quality of compressed air, filters that gradually remove all types of solid and liquid contaminants from the compressed air must be installed in the compressed air line
- Your advantages through better quality compressed air:
- Safe filtration of both liquids such as water and aerosols as well as particles, dust and gases
- Better working and production conditions
- Optimum protection of connected tools and machines
- Improved product quality through reduction of rejects
- Protection of the compressed air system against contamination
- Increase of productivity by reduction of instant maintenance
- for separating solid contaminants up to 0.01μm
- Residual oil aerosol content up to 0.01 mg / m³ at 20 ° C and 1 bar
- Operating temperature 1.5 to 65 ° C
- absolute compressed air quality according to ISO 8573-1
- for safe separation of condensate and particles
- complete with filter element and float valve
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2507612
- For connecting compressors to compressed air tanks or pipe systems with detachable double nipple
- One connection each with internal and external thread
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
