The TOX Thermo Proof M12x300 is a heavy-duty stand-off mounting system for thermally insulated façades (ETICS/WDVS), designed for secure and energy-efficient installation without creating thermal bridges. It is suitable for mounting awnings, railings, air-conditioning units, satellite dishes, and other heavy façade elements on insulated exterior walls.

The threaded rod made of A4 stainless steel ensures long-term durability and prevents the formation of unsightly rust stains. The included Aqua-Stop sealant protects the façade from moisture penetration and reduces the risk of structural damage. The adjustable Iso Spacer insulating sleeve allows precise, stress-free installation while minimizing heat loss.

The system is approved by building authorities and is suitable for both indoor and outdoor use.

Key benefits:

• Suitable for ETICS/WDVS façades, clinker façades, and flat roofs
• Thermal-bridge-free stand-off installation for insulation thicknesses up to 200 mm
• Stainless steel A4 – corrosion-resistant and weatherproof
• Aqua-Stop sealant protects against moisture and façade deterioration
• Minimal energy loss
• Quick and easy installation
• Adjustable Iso Spacer for precise alignment

Applications:

• Awning installation
• Railings and handrails
• Air-conditioning units and heat pumps
• Satellite dishes
• Other heavy façade-mounted components

Suitable base materials:

• Concrete
• Perforated brick
• Solid brick
• Sand-lime brick
• Other masonry materials

Technical data:

• Thread diameter: M12
• Length: 300 mm
• Material: stainless steel A4 / plastic
• Maximum insulation thickness: up to 200 mm

Scope of delivery:

• 2 × stainless steel threaded rods M12x300
• 2 × Iso Spacer insulating sleeves
• 2 × sieve sleeves
• 1 × static mixer extension
• 1 × Aqua-Stop sealant (approx. 80 ml)

The TOX Thermo Proof M12x400 is a heavy‑duty stand‑off mounting system for thermally insulated façades (ETICS/WDVS), designed for secure installation without creating thermal bridges. It is ideal for mounting awnings, railings, air‑conditioning units, heat pumps, satellite dishes, and other heavy façade components – even with thicker insulation layers.

The A4 stainless steel threaded rod ensures long‑term durability and prevents rust stains on the façade. The integrated Aqua‑Stop sealant protects against moisture penetration and reduces the risk of façade deterioration. The adjustable Iso Spacer insulating sleeve allows precise, stress‑free installation and minimizes heat loss.

The system is approved by building authorities and suitable for indoor and outdoor use.

Key benefits:

• Suitable for ETICS/WDVS façades, clinker façades, and flat roofs
• Thermal‑bridge‑free stand‑off installation for insulation thicknesses up to 300 mm
• Stainless steel A4 – corrosion‑resistant and weatherproof
• Aqua‑Stop sealant protects against moisture and façade damage
• Minimal energy loss
• Quick and easy installation
• Adjustable Iso Spacer for precise alignment

Applications:

• Awning installation
• Railings and handrails
• Air‑conditioning units and heat pumps
• Satellite dishes
• Other heavy façade‑mounted elements

Suitable base materials:

• Concrete
• Perforated brick
• Solid brick
• Sand‑lime brick
• Other masonry materials

Technical data:

• Thread diameter: M12
• Length: 400 mm
• Material: stainless steel A4 / plastic
• Maximum insulation thickness: up to 300 mm

Scope of delivery:

• 2 × stainless steel threaded rods M12x400
• 2 × Iso Spacer insulating sleeves
• 2 × sieve sleeves
• 1 × static mixer extension
• 1 × Aqua‑Stop sealant (approx. 80 ml)

The TOX Thermo Proof Plus M16x300 is a heavy‑duty stand‑off mounting system designed for thermally insulated façades (ETICS / WDVS), clinker façades and flat roofs. It is a building‑authority‑approved solution for demanding structural fixings requiring M10 or M12 connections, such as French balconies and awning installations.

The system enables secure installation through thick insulation layers while eliminating thermal bridges and preventing damage to the façade. The A4 stainless steel threaded rod provides excellent corrosion resistance, durability and long service life.

The integrated Aqua‑Stop system effectively protects the façade against moisture ingress and decay.

Key benefits:

• Heavy‑duty stand‑off fixing for insulated façades
• Building‑authority approved for M10/M12 connections
• Standard solution for M10 fixings (e.g. French balconies)
• Up to 250% higher load capacity compared to conventional systems
• Suitable for insulation thicknesses up to 220 mm
• Thermal‑bridge‑free installation
• A4 stainless steel for maximum corrosion resistance
• Aqua‑Stop protects against moisture‑related façade damage
• Precise adjustment without applying pressure to the façade

Typical applications:

• French balconies
• Awnings and canopies
• Heavy brackets and console fixings
• Load‑bearing façade attachments
• Clinker façades and flat roofs

Suitable base materials:

• Cracked and non‑cracked concrete
• Solid and perforated brick
• Lightweight concrete
• Sand‑lime brick
• Masonry

Technical data:

• Thread diameter: M16
• Length: 300 mm
• Connection: M10 or M12
• Max. insulation thickness: up to 220 mm
• Material: A4 stainless steel / plastic
• Application: outdoor use

Scope of delivery (2‑piece set):

• 2 × Iso Spacer insulating sleeves
• 2 × A4 stainless steel threaded rods M16x300
• 2 × A4 screws M10x40
• 2 × A4 screws M12x40
• 2 × sieve sleeves 20×85 mm
• 1 × extension 10×200 mm
• 1 × Aqua‑Stop (80 ml)

The TOX Thermo Proof Plus M16x400 is a heavy‑duty stand‑off mounting system designed for thermally insulated façades (ETICS / WDVS), clinker façades and flat roofs. It is a building‑authority‑approved solution for demanding applications using M10 or M12 connections, such as French balconies, awnings and other high‑load façade fixings. [tox.de]

The system allows secure installation through very thick insulation layers while preventing façade damage and eliminating thermal bridges. The A4 stainless steel threaded rod ensures excellent corrosion resistance, durability and long service life.

The integrated Aqua‑Stop system effectively protects the façade against moisture ingress and structural decay.

Key benefits:

• Heavy‑duty stand‑off fixing for insulated façades
• Building‑authority approved for M10 and M12 connections
• Standard solution for M10 fixings (e.g. French balconies)
• Up to 250% higher load capacity compared to conventional systems
• Suitable for insulation thicknesses and stand‑off installations up to 320 mm
• Thermal‑bridge‑free installation
• A4 stainless steel for maximum corrosion protection
• Aqua‑Stop protects against moisture‑related façade damage
• Precise adjustment without applying pressure to the façade

Typical applications:

• French balconies
• Awnings and canopies
• Heavy brackets and consoles
• Load‑bearing façade attachments
• Clinker façades and flat roofs

Suitable base materials:

• Cracked and non‑cracked concrete
• Solid and perforated brick
• Lightweight concrete
• Sand‑lime brick
• Masonry

Technical data:

• Thread diameter: M16
• Length: 400 mm
• Connection: M10 or M12
• Max. insulation / stand‑off thickness: up to 320 mm
• Material: A4 stainless steel / plastic
• Application: outdoor use

Scope of delivery (2‑piece set):

• 2 × Iso Spacer insulating sleeves
• 2 × A4 stainless steel threaded rods M16x400
• 2 × A4 screws M10x40
• 2 × A4 screws M12x40
• 2 × sieve sleeves 20×85 mm
• 1 × extension 10×250 mm
• 1 × Aqua‑Stop (80 ml)

The TOX Thermo Proof Mini M8x120 is a compact stand‑off mounting system for thermally insulated façades (ETICS/WDVS), designed for light to medium loads without creating thermal bridges. It is especially suitable for soft insulation materials such as mineral wool and enables invisible installation without exerting pressure on the façade.

The threaded rod creates no thermal bridge and results in virtually no energy loss. Thanks to its variable connection options (M10 external thread, M6 internal thread, or screws with a diameter of 3–5 mm), the system is highly versatile. The slim head design ensures a clean, discreet appearance. The system is suitable for both indoor and outdoor use.

Key benefits:

• Designed for soft insulation materials, e.g. mineral wool
• For insulation thicknesses 50–120 mm
• Thermal‑bridge‑free fixing
• No compressive load on the façade
• Variable connection options:



M10 external thread

M6 internal thread

screws Ø 3–5 mm

• Slim head geometry for concealed installation
• Fast and easy installation

Typical applications:

• Downpipes and pipe clamps
• Signs and information boards
• Mailboxes
• Roller shutter and blind guide rails
• Motion detectors, house numbers, outdoor cameras

Suitable base materials:

• Concrete
• Solid brick
• Masonry
• Aerated concrete
• Insulated façade systems

Technical data:

• Thread diameter: M8
• Length: 120 mm
• Suitable insulation thickness: 50–120 mm
• Drill hole diameter: 14 mm
• Minimum drill hole depth: 90 mm
• Material: plastic / steel

Scope of delivery:

• 2 × threaded rods M8x120
• 2 × M6/M10 thread adapters
• 2 × Barracuda expansion plugs 14/70
• 2 × Barracuda expansion plugs 5/25
• 1 × Torx bit (TX)
