- Precise processing
- Powerful, maintenance-free engine
- Heavily ribbed prism bed made of gray cast iron, inductively hardened and precision ground
- Smooth-running feed gear with rounded gears running in an oil bath
- Hardened and ground Z-axis guideway
- Guaranteed concentricity of the spindle nose better than 0.009 mm
- Concentricity on the lathe chuck better than 0.04 mm
- Automatic longitudinal / lead screw drive
- Lead screw for thread cutting or automatic longitudinal turning
- Quadruple tool holder
- All guides can be adjusted by wedge strips
- Right / left rotation in the control panel switchable
- Hardened main spindle mounted in adjustable precision tapered roller bearings
- Tapered roller bearings in P5 quality
- Hardened spindle nose with Ø 26 mm spindle bore
- Rolled trapezoid spindles
- Chip protection on the upper slide
- Upper slide on cross slide slidable
- Tailstock for taper turning ± 5 mm adjustable
- Tailstock quill and handwheel with adjustable fine scale 0.02 mm
- Fast, easy and tool-free adjustment by means of a clamping lever
- Leadscrew stored in two sintered bearings
- Change gear set in standard scope of supply for thread cutting
- Handwheels on the carriage with adjustable fine scale 0.04 / 0.01 mm
- thrust bearing
- 3-jaw lathe chuck in the standard scope of delivery
- Emergency stop impact switch
- Fully equipped, allowing the user to be productive immediately after commissioning
TU 2807V
- Quiet, powerful and brushless DC drive with excellent control characteristics
- High precision steel lining for higher speeds
- Speed change easily adjustable via potentiometer
- Digital speed display
