Saw-mill combination SFK 315/30-2600

The HOLZSTAR TF 50 E is a compact and versatile woodworking router table, ideal for home workshops and demanding DIY applications. It is designed for profiling, grooving, rebating, and shaping various wood materials with high precision.

The machine features a variable‑speed spindle, allowing optimal adjustment for different cutter sizes and materials. The spindle height is precisely adjustable from 0 to 40 mm, ensuring accurate control during routing operations. An aluminium work table with standard table extensions provides stable support for larger workpieces.

Key features:

• Motor power: 1.5 kW
• Supply voltage: 230 V / 50 Hz
• Spindle speed range: 11,500 – 24,000 rpm
• Spindle stroke (height adjustment): 0 – 40 mm
• Max. cutter diameter: 50 mm
• Table size: 610 × 360 mm
• Table material: aluminium
• Dust extraction port: Ø 100 mm
• Net weight: approx. 21 kg

Scope of delivery:

• Table extensions (left & right)
• Aluminium routing fence
• Mitre fence
• Collets Ø 6 mm, 8 mm and 12 mm
• Assembly and adjustment tools

The HOLZSTAR TF 170E is a compact and precise table router (spindle moulder) designed for routing profiles, grooves, joints and mouldings in solid wood and wood‑based panels. Thanks to its rigid construction and smooth sliding table, it is ideal for demanding DIY users as well as small professional workshops.

Key features:

• Table router for woodworking with fixed milling spindle
• Smooth‑running aluminium sliding carriage for precise workpiece guidance
• Milling fence with finely adjustable aluminium stops
• Large, torsion‑free cast‑iron work table
• Quick and easy speed change via belt drive
• Robust cast‑iron milling unit and precise spindle mechanism
• Hold‑down device for safe and accurate machining

Technical specifications:

• Power supply: 400 V / 50 Hz / 3‑phase
• Motor power: 1.5 kW
• Spindle diameter: 30 mm
• Spindle stroke: 105 mm
• Max. tool diameter: 160 mm
• Spindle speeds: 1400 / 4000 / 6000 / 9000 min⁻¹
• Table size: 600 × 400 mm
• Table height: 850 mm
• Sliding carriage length: 1000 mm
• Sliding carriage width: 218 mm
• Dust extraction port diameter: Ø 100 mm
• Net weight: approx. 96 kg

Included in delivery:

• HOLZSTAR TF 170E table router / spindle moulder
• Aluminium milling fence
• Hold‑down device
• Spindle guard
• User manual and CE declaration of conformity

The HOLZMANN FS160L is a compact and versatile spindle shaper designed for shaping, profiling and grooving wood. Featuring a torsion‑resistant cast iron table and an extra‑long aluminium sliding table, it delivers high precision and smooth operation, making it ideal for both hobbyists and small professional workshops.

Key features:

• Compact spindle shaper / wood milling machine
• Torsion‑resistant cast iron working table
• Extra‑long aluminium sliding table (approx. 1000 × 215 mm)
• Interchangeable spindle with router collet for router bits
• Mitre fence adjustable ±60° (left/right)
• Dynamically balanced spindle for smooth and accurate running
• CE‑approved safety hood, micro‑switch and emergency stop button
• Space‑saving design with a wide range of applications

Technical specifications:

• Power supply: 230 V / 50 Hz / single phase
• Motor power:

    S1: 1.5 kW

    S6: 2.1 kW

• Spindle diameter: 30 mm
• Spindle speeds: 1400 / 4000 / 6000 / 9000 min⁻¹
• Spindle stroke: 110 mm
• Max. tool diameter below table: 150 mm
• Max. tool diameter above table: 170 mm
• Table size: 600 × 400 mm
• Table height: 850 mm
• Sliding table dimensions: approx. 1000 × 215 mm
• Dust extraction port: Ø 100 mm
• Net weight: approx. 108 kg

Included in delivery:

• HOLZMANN FS160L spindle shaper
• Safety hood for spindle shaper
• Mitre fence
• Exchangeable spindle with collet
• Fixing and adjustment tools
• User manual and CE declaration of conformity

The HOLZMANN FS160L_400V is a compact yet highly versatile spindle moulder, designed for profiling, grooving, tenoning, and shaping operations in solid wood and wood‑based materials. Thanks to its rigid construction and long sliding table, it is suitable for both advanced hobby users and professional workshops.

The machine features a torsion‑resistant cast iron work table and an integrated aluminium sliding carriage for accurate and safe workpiece feeding. A dynamically balanced spindle ensures smooth operation and excellent surface finish. Four selectable spindle speeds allow optimal adaptation to various cutter sizes and applications.

Key features:

• Motor power (S6): 2.1 kW
• Motor power (S1): 1.5 kW
• Power supply: 400 V / 50 Hz
• Spindle diameter: 30 mm
• Spindle speeds: 1400 / 4000 / 6000 / 9000 rpm
• Spindle stroke (height adjustment): 110 mm
• Max. tool diameter below table: 150 mm
• Max. tool diameter above table: 170 mm
• Table size: 600 × 400 mm
• Sliding table: 1000 × 220 mm
• Working height: approx. 850 mm
• Dust extraction port: Ø 100 mm
• Net weight: approx. 108 kg

Scope of delivery:

• Spindle guard with CE‑approved safety hood
• Tilting mitre fence (±60°)
• Aluminium sliding carriage
• Interchangeable spindle for router tooling
• Clamping device and adjustment tools

The HOLZMANN KF315VF2000 is a professional sliding table saw and spindle moulder combination, integrating a 315 mm circular saw with a 4‑speed spindle moulder in one robust machine. It is designed for accurate cutting of large panels and precise milling of solid wood and profiles, making it ideal for furniture manufacturing and joinery workshops.

Key features:

• Combined sliding table saw and spindle moulder
• Large 2000 mm sliding table for accurate panel sizing
• Tilting and height‑adjustable saw blade with scoring unit
• Heavy‑duty, torsion‑free cast‑iron work table with extensions
• Smooth‑running rip fence with quick‑clamping system
• Max. cutting width at rip fence up to 1330 mm
• 4 spindle moulder speeds covering a wide working range
• Electronic spindle speed indication via LED display
• High‑quality spindle moulder guard with roller guides and fine adjustment
• Dual dust extraction ports Ø 100 mm

Technical specifications:

Motors:

• Motor power (S1): 3800 W / 2800 W
• Motor power (S6): 5100 W / 4000 W
• Power supply: 400 V / 50 Hz / 3‑phase

Circular saw:

• Saw blade diameter: Ø 315 mm
• Scoring blade diameter: Ø 100 mm
• Max. cutting height at 90°: 100 mm
• Max. cutting height at 45°: 80 mm
• Saw blade speed: 4500 min⁻¹
• Scoring unit speed: 8500 min⁻¹
• Max. cutting length: 2200 mm

Spindle moulder:

• Spindle diameter: 30 mm
• Spindle speeds: 1800 / 3000 / 6000 / 9000 min⁻¹
• Spindle stroke: 100 mm
• Max. tool diameter above table: 200 mm
• Max. tool diameter below table: 180 mm

Dimensions & weight:

• Table size: 860 × 890 mm
• Table height: 850 mm
• Sliding table: 2000 × 270 mm
• Outrigger table: 750 × 590 mm
• Net weight: approx. 310 kg
• Gross weight: approx. 425 kg

Included in delivery:

• HOLZMANN KF315VF2000 sliding table saw / spindle moulder
• Scoring unit
• TCT saw blade Ø 315 mm
• TCT scoring blade Ø 100 mm
• Rip fence and telescopic fence
• Mitre fence
• Spindle moulder guard
• User manual and CE declaration of conformity
