52-2507715
- Suitable for compressed air with full free passage
- Temperature resistant from -20 ° C to + 180 ° C
ManufacturerBongas Deutschland GmbH
Raiffeisenstraße 13, 77704 Oberkirch, Germany
www.bongas.de
52-2048336
Advantages of DRYPOINT eco control
- Integrated DRYPOINT M Plus solution: filtration and dryer in a compact form, as well as condensate drain integrated
- Filtration on the spot in the treatment chain where the highest efficiency is achieved
- Easy maintenance / replacement of filter element as with a filter
- Application-specific degree of dryness can be selected
- Consistent compressed air quality under fluctuating operating conditions
- Energy saving through minimization of purging air consumption for actual amount of useful air and degree of drying
- Power evaluation via LED, forwarding via current output 4 … 20 mA possible
- User-friendly: Easy to use, test functions, error messages
- Concept based on the fail-safe principle, error message can be picked up via potential-free contact
Functionality of the DRYPOINT® M eco control
Based on the measurement result from the sensor, the control software decides in defined cycles whether and how long the full amount of purge air has to be provided to achieve and stabilize the required degree of dryness. This process is implemented by means of a targeted clocking of a solenoid valve. In each cycle, the duration of the two process sections described below varies in order to keep the degree of drying within the specified tolerance range.
ManufacturerBEKO Technologies GmbH
Im Taubental 7, 41468 Neuss, Germany
www.beko.de
52-2006530
- Due to its narrow design, it is particularly suitable for use in breakdown vehicles
- With 100 liter compressed air tank
- With 1-cylinder / 4-stroke Honda engine for off-grid operation
- With idling and speed control, thereby adapting to the respective load conditions
- The high-performance gray cast iron unit and the low speed warranty maximum smoothness and a long service life.
- The large fan wheel and a cooling air baffle ensure optimum cooling of the compressor.
- Stable belt guard made of metal
- An aftercooler with large cooling fins ensures a low container inlet temperature and thus less moisture in the compressed air
- With all safety devices
- Ten-year rust-through warranty on powder-coated compressed air tank
Room amenities:Freewheel valve for less wear
- The freewheel valve avoids constant switching on and off.
- After reaching the set pressure, the valve opens and the compressor runs without pressure.
- When the pressure drops, the valve closes and the compressor works again on pressure.
Service
- On the filter pressure regulator, you can fix the working pressure infinitely and remove pressure-reduced and filtered compressed air.
- Two pressure gauges show the tank u. Working pressure.
- As standard with quality quick coupling and high quality CONDOR pressure switch
Shock mounts
- Equipped with two large and wide front swinging elements for stable stability
Tool tray
- Practical in everyday use as a storage for tools, plans, etc. and as protection against damage from above
High performance aggregate HOS
- The precisely machined piston is equipped with a high-alloyed piston ring, oil scraper ring and oil scraper ring, which take over the sealing of the piston to the cylinder wall.
- The crankcase is filled with oil, which is sprayed against the cylinder wall with each piston stroke.
- The oil scraper wipes the oil-wetted cylinder wall downwards.
PU foam tires
- The large, stable wheels with puncture-proof PU foam tires ensure easy and comfortable transport even on uneven ground
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
