Screw compressor A-K-MAX 11-10 (IE3)

Special

• Drying by partial vapor pressure compensation of water vapor by diffusion in combination with a highly selective membrane
• No change in the compressed air composition - can be used for breathing air treatment

Efficient

• Reaches the required pressure dew point with low energy consumption
• Very fast availability of dried compressed air
• Filtration and drying compact in one device

Robust

• Housing made of seawater-resistant aluminum
• Low-maintenance, currentless technology

System-compatible

• Modularly combinable with CLEARPOINT Filter program
• Can be used anywhere along the compressed air treatment chain - can also be integrated into system technology

• The ultimate membrane dryer technology with integrated nanofilter
• Filtration and drying in one housing (simple filter element change)
• Low purge air requirement (Twist 60 technology)
• Availability of dried compressed air immediately without running-in phase
• Safe drying due to the high partial vapor pressure gradient
• No change in the compressed air temperature and composition
• Proven 100,000 times
• Maintenance-free (except filter element change)
• For diverse applications, including for breathing air treatment
• Also ideal for use directly behind the compressor / aftercooler
• Optionally also for higher loads (assembly potting, 16 bar, 70°C)
• For a reliable function of the DRYPOINT M membrane dryer must meet the following requirements:
1. The incoming compressed air must not contain any liquid condensate
2. Particles larger than 1 μm must be separated before the membrane dryer
3. The oil content of the compressed air must not exceed 0.01 mg/m³.

• DRYPOINT M membrane dryers have been an alternative to existing ones for years Compressed air drying process proven.

Advantages DRYPOINT M PLUS

• Proven process of highest reliability and functional safety
• Immediate availability of dry compressed air, even when working discontinuously
• Low purge air requirement, compressed air drying can be adjusted to the application
• Compact and robust, small space requirement due to low overall height
• Compressed air inlet and outlet on one level (filter version), easy to combine with CLEARPOINT filters
• Maintenance and wear-free as there are no moving parts
• No reduction in the oxygen content, therefore also suitable for breathing air treatment
• No electrical connection, also suitable for Ex areas
• Long service life in case of use of CLEARPOINT filters
• Environmentally friendly, does not require CFCs / CFC-containing refrigerants or adsorbents
• Complete solution: filtration and dryer in a compact form, integration of drain pipe
• Filtration at the point in the treatment chain where the highest efficiency is achieved
• Easy maintenance / replacement of filter element as with a regular filter

Filter element: N (nanofilter)

• The CLEARPOINT filter element type N is used to separate solid particles down to 0.01 micron, water and oil aerosols . The element has a multi-stage structure for efficient and long-lasting filtering. In the first stage, coarse particles are retained by a pre-filter layer. In the second stage, finer particles are absorbed by a depth filter bed made of high-performance borosilicate fiber fabric. Due to the very large cavity volume of the filter medium (96%), a very high dirt holding capacity is achieved. The filter medium is specially impregnated in order to avoid cross-sectional swelling of the individual fibers.

Trap: Float trap

• The basic version includes a float drain.

Size 10 - 40

• This size is for the demand-oriented compressed air drying of medium volume flows configured. Different levels of drying of the compressed air are achieved through different purge air settings.

• Normal oil lubricator with suction device under pressure
• For pressure inlet max. 16 bar
• Suitable for temperatures from -10 to +50°C
• For vertical installation
• Oil type CL 32 according to DIN 51517-ISO VG 32 - oil refill under pressure up to max. 10 bar possible

• Normal oil lubricator with suction device under pressure
• For pressure inlet max. 16 bar
• Suitable for temperatures from -10 to +50°C
• For vertical installation
• Oil type CL 32 according to DIN 51517-ISO VG 32 - oil refill under pressure up to max. 10 bar possible

• Absolutely Low maintenance drive with maximum energy efficiency thanks to directly coupled coaxial screw compressor
• EasyTronic IV control as standard prevents motor overload, reduces wear and ensures a longer service life
• High cooling effect and Lower noise level thanks to the thermostatically controlled radial fan
• Longer service life of the device and less fluctuations in the oil temperature thanks to the thermostatically controlled fan, optimal cooling air flow and generously sized heat exchanger
• Less effort for drying and filtering the generated compressed air Integrated aftercooler
• Guaranteed compliance with the maintenance intervals by recording the load and run-on times via the operating hours counter
• Display of the maintenance requirement via automatic notification
• Avoiding damage during commissioning or after changing location through integrated direction of rotation control for the motor
• Service-friendly due to optimal accessibility and simple assembly / disassembly of all components to be serviced
• Easy transport and assembly due to small external dimensions
• Monitoring as standard the engine and compressor speed through SpeedTronic Control control
• Fifteen-year guarantee against rusting through on the inside and outside of hot-dip galvanized compressed air tanks

Based on the frequency converter technology, the delivery quantity of the compressor adapts to the actual consumption. The electronic control monitors the engine and compressor speed and keeps the network pressure constant. The user receives advanced cutting-edge technology in the smallest of spaces.

• Active energy saving
• Ideal for frequently changing compressed air consumption
• The speed-controlled compressor achieves maximum efficiency and keeps the network pressure constant, even when consumption fluctuates greatly.

• Compact and smooth-running
• Oil-free and low maintenance
• Air outlet via a one-hand quick coupling
• Pressure gauges for tank and working pressure
• Robust with motor protection and secure transport design

• Small, compact design
• Very smooth operation
• Oil-free piston compressor, thus no oil change necessary and no oil in the condensate
• Air sampling over a one-hand quick couplings
• Pressure regulator for stepless adjustment of the desired working pressure
• Based on a pressure gauge for display of the container and work pressure
• Electric motor equipped with motor protection switch
• Vibration damping rubber feet
• Rubberized handle to prevent it slipping off during transport
• Compressed air tank powder coated
