Screw compressor A-K-MAX 38-10 VS (PM)

Key Features:

• Compact and portable design
• Very quiet operation – noise level approx. 62 dB(A)
• Oil-free piston compressor – no oil changes required, no oil in condensate
• Maximum pressure: 10 bar
• Tank capacity: 8 liters
• Motor power: 1.3 kW
• Voltage: 230 V / 50 Hz
• Suction capacity: 240 l/min
• Effective air output: 115 l/min
• Number of cylinders: 2
• Compression stages: 1
• Speed: 2850 rpm

Additional Features:

• One-hand quick coupling for compressed air withdrawal
• Stepless pressure adjustment via pressure reducer
• Two pressure gauges (tank and working pressure)
• Motor protection switch
• Vibration-damping suction feet
• Rubberized handle for secure transport
• Powder-coated air tank

Dimensions & Weight:

• Size: approx. 490 × 420 × 390 mm
• Weight: approx. 19.5 kg

Technical Specifications:

• Model: AIRBOY 186 OF E
• Type: Oil-free portable piston compressor
• Tank Capacity: 6 liters
• Voltage: 230 V
• Motor Power: 1.1 kW
• Max Pressure: 8 bar
• Working Pressure: 6 bar
• Intake Capacity: 180 l/min
• Free Air Delivery (FAD): 90 l/min
• Cylinders / Stages: 1 / 1
• Speed: 3400 rpm
• Lubrication System: WDS (oil-free)
• Weight: approx. 9.2 kg
• Dimensions (L × W × H): 315 × 355 × 370 mm
• Noise Level: 97 dB(A)

Key Features:

• Oil-free operation – no oil changes, clean air output
• Compact and lightweight – easy to carry and store
• Fully automatic start/stop function
• Motor protection switch – prevents overheating
• Pressure regulator – adjustable output pressure
• Dual pressure gauges – for tank and working pressure
• Quick-release coupling – for fast tool connection
• Shock-absorbing feet – stable and quiet operation
• Powder-coated tank – corrosion-resistant

Ideal For:

• Home and hobby use
• Inflating tires, sports equipment, air mattresses
• Light-duty pneumatic tools

• Model: MOBILBOY 185 OF E
• Type: Oil-free piston compressor
• Tank Capacity: 5 liters
• Voltage: 230 V
• Power: 1.1 kW
• Suction Capacity: approx. 185 l/min
• Max Pressure: 10 bar
• Noise Level: 97 dB(A)
• Dimensions: approx. 32 × 38 × 46.7 cm
• Weight: approx. 11.1 kg
• Air Outlet: One-hand quick coupling
• Pressure Regulation: Stepless via regulator
• Manometer: For working pressure
• Condensate Drain Valve: On the compressed air tank
• Mobility Features:

       Sturdy plastic wheels

       Extendable handle

       Compact and portable design

       Integrated storage compartment for power cable

Key Features:

• Oil-Free Operation: No oil changes required, clean air output
• Compact & Mobile: Ideal for portable use in workshops or on-site
• User-Friendly Design: Easy to transport and operate
• Durable Build: High-quality components for long service life
• Applications: Suitable for air brushing, blow cleaning, bolting, cutting, drilling, grinding, nailing, sanding, spraying, tire inflation

Technical Specifications:

• Model: COMPACT-AIR 361/20 E
• Type: Mobile piston compressor
• Tank Capacity: 20 liters
• Voltage: 230 V / 50 Hz
• Motor Power: 2.2 kW
• Max Pressure: 10 bar
• Suction Capacity (Intake): 356 l/min
• Free Air Delivery (FAD): 215 l/min
• Cylinders / Stages: 2 / 1 (V-cylinder, single-stage compression)
• Speed: 2850 rpm
• Lubrication System: HOS (oil-lubricated)
• Weight: approx. 37 kg
• Dimensions (L × W × H): 470 × 490 × 720 mm
• Noise Level: 97 dB(A)

Key Features:

• Compact and mobile design – ideal for construction sites and assembly work
• High-quality electric motor – with thermal protection against overheating
• Fully automatic start/stop operation
• Infinitely adjustable pressure regulator – from 0 to 10 bar
• Two quick-release couplings – for easy tool connection
• Dual pressure gauges – for tank and working pressure
• Aluminum compressed air pipes
• Strong protective frame – shields all components
• Rubberized carrying handle – for safe transport

Technical Specifications:

• Motor power: 1.5 HP / 1.1 kW
• Voltage: 230 V / 50 Hz / single-phase
• Max pressure: 8 bar
• Working pressure: 6 bar
• Intake capacity: 215 l/min
• Free air delivery: 120 l/min (7.2 m³/h)
• Tank capacity: 24 liters
• Pump speed: 2850 rpm
• Noise level:

       0 m: 97 dB(A)

       4 m: 77 dB(A)

       7 m: 72 dB(A)

• Dimensions: 580 × 255 × 580 mm
• Weight: 21 kg
• Cylinders: 1
• Stages: 1
• Drive type: Direct drive (1:1)
• Start type: Direct start
• Oil-free: Yes
• Main air connection: ¼" universal fitting
• Duty cycle: 20% run / 80% rest

Features:

• Oil-free operation – clean air output, no oil changes required
• Compact and portable – easy to move with handle and wheels
• Protective housing – enhances safety during use
• Ideal for: inflating tires, mattresses, balls, pools, and cleaning leaves or water systems
• Low maintenance – no need to monitor oil levels
