51-5901500
The HOLZSTAR KSO 1500 F is a heavy‑duty professional belt sanding machine designed for precise and continuous sanding of edges, surfaces, bevels, and radii in woodworking applications. The machine features an oscillating sanding belt driven by a separate oscillation motor, ensuring a cleaner sanding pattern and extended belt service life.
A rigid welded‑steel machine frame guarantees vibration‑free operation, even when machining large workpieces. The sanding unit can be swivelled up to 45°, work tables are height‑adjustable, and an additional table with extraction enables accurate radius sanding. Belt oscillation can be switched on or off as required.
Key features:
- Oscillating sanding belt with separate oscillation motor for superior sanding results
- Swivelling sanding unit (0–45°) for straight and bevelled edges
- Height‑adjustable longitudinal table for full utilisation of the belt width
- Height‑adjustable additional table with extraction for radius sanding
- Graphite‑coated sanding sole to reduce friction and increase belt life
- Automatic spring‑loaded belt tensioning
- Rigid welded‑steel machine stand for vibration‑free operation
Technical specifications:
- Power supply: 400 V / 50 Hz (three‑phase)
- Motor output power: 2.3 kW
- Input power: 3.0 kW
- Oscillation motor power: 0.25 kW
- Sanding belt size: 2600 × 150 mm
- Sanding surface: approx. 850 × 200 mm
- Belt speed: 20 m/s
- Longitudinal table size: 750 × 300 mm
- Longitudinal table height adjustment: 180 mm
- Minimum cross table height: 740 mm
- Dust extraction port: Ø 120 mm
- Dimensions (L × W × H): approx. 1720 × 700 × 1030 mm
- Weight: approx. 180 kg
