Sorkkarauta 1000mm

The HOLZSTAR TF 200 SE is a professional‑grade spindle moulder designed for precise and demanding woodworking applications. With its tilting spindle, rigid construction, and heavy cast‑iron work table, it is ideal for small production workshops and professional users.

The machine features a torsion‑free cast‑iron table ensuring vibration‑free operation and excellent machining accuracy. The tilting spindle (‑5° to +45°) allows advanced profiling and angled milling operations. Four selectable spindle speeds combined with a powerful motor provide flexibility for a wide range of cutters and materials.

Key features:

• Rated motor power: approx. 2.8 kW
• Power supply: 400 V / 50 Hz
• Spindle diameter: 30 mm
• Spindle tilt range: ‑5° to +45°
• Spindle speeds: 1400 / 4000 / 6000 / 9000 rpm
• Max. cutter diameter above table: up to 180 mm
• Max. cutter diameter below table: up to 160 mm
• Spindle stroke (height adjustment): approx. 115 mm
• Work table material: cast iron
• Table size: approx. 700 × 550 mm
• Working height: approx. 900 mm
• Dust extraction port: Ø 120 mm
• Net weight: approx. 230 kg

Scope of delivery:

• Tilting spindle Ø 30 mm
• CE‑approved spindle guard and safety hood
• Adjustable milling fence with fine adjustment
• Mitre fence
• Adjustment and service tools
