Teemantlõikeketas 200mm;25,4mm CERAMIC

The BERNARDO BDS 75 is a versatile and heavy‑duty belt and disc sanding machine, designed for deburring, surface, contour and cylindrical grinding of metal and other materials. It is ideally suited for professional workshops as well as demanding advanced users.

Thanks to its high belt speed of 11 m/s, the machine delivers excellent sanding performance. A graphite‑coated sanding belt support improves belt glide and reduces wear. The BDS 75 features tilting sanding tables for both the belt and disc unit and a rigid, torsion‑free machine housing, ensuring smooth and low‑vibration operation. The sanding belt is easy to change, and the Velcro‑mounted sanding disc allows quick grit replacement.

Key Features:

• Combined belt and disc sander for universal applications
• Powerful motor up to 1.5 kW (S6)
• High belt speed of 11 m/s
• Graphite‑coated belt backing for improved sliding performance
• Tilting sanding tables:



    belt 0°–90°

    disc 0°–45°

• Rigid and torsion‑free housing for smooth running
• Dust extraction port Ø 50 mm
• Velcro sanding disc system for fast grit changes

Technical Specifications:

• Power supply: 400 V / 50 Hz
• Motor power:

    S1 (100%): 1.1 kW

    S6 (40%): 1.5 kW

• Sanding belt size: 75 × 1180 mm
• Belt speed: 11 m/s
• Belt table size: 280 × 80 mm
• Sanding disc diameter: 150 mm
• Disc table size: 150 × 130 mm
• Dust extraction outlet: Ø 50 mm
• Dimensions (L × W × H): 470 × 720 × 520 mm
• Weight: approx. 65 kg
