51-3384033
Details- LED display
- Higher working accuracy
- Significant reduction of production times
- Error rate is reduced
- Included sensor for recording spindle speeds
- Switchable from turning to milling machines
- Ergonomic membrane keyboard, protected against dust and splash water
Especially for lathes- Diameter or radius display
- Display of Z0 and Z1 axes with addition function, separately or together possible especially for milling machines
- Trigonomic function (sin, cos, tan)
- Pitch circle calculation with single coordinate indication
Application- for precise, fast and safe production
- Fast setup through exact positioning for mounting on lathes, milling machines, drilling machines, etc. for measuring traverse paths
- No parallax or reading errors
- Absolute repeatability
Possible functions- Calculator
- Speed display,
- Axis coupling (sum Z)
- Sub D connector sockets
- Absolute/incremental operation
- Conversion inch/metric thread
- Bolt circle calculator (chain dimension)
- Coordinates in circle (pitch circle)
- Holes in circle (pitch circle)
- Measured values radius/diameter switchable
- Zero reset data preset
- Self-diagnosis
- Reference point
- Linear error compensation
- 99 tool memories
suitable for- OPTIMUM lathes
- OPTIMUM milling machines
NoteWhen retrofitting position indicators and measuring bars for lathes and milling machines, holes and threads must be provided on the machine by the customer.
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3385060
- Dimensions L x W x H: 630 x 400 x 100 mm
- Acceptance 7 μ
- granite
- Thermally and dynamically stable
- Compressive strength 250 - 260 N / mm2
- DIN 876/0
- corrosion-free
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3336090
- Heavy, solid design made from high-quality, vibration-absorbing gray cast iron
- Solid and generously dimensioned cross table, precisely surface-finished with T-slots and adjustable keyways
- Automatic quill feed (drilling) activated via the quill feed lever or manual quill feed with the fine feed handwheel
- Right/left rotation
- Coolant device
- X-axis moves either with the handwheel or via the table feed device
- Height-adjustable protective screen with microswitch, against flying chips and parts, for maximum protection of the user
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3384029
Details- LED display
- Higher working accuracy
- Significant reduction of production times
- Error rate is reduced
- Included sensor for recording spindle speeds
- Switchable from turning to milling machines
- Ergonomic membrane keyboard, protected against dust and splash water
Especially for lathes- Diameter or radius display
- Display of Z0 and Z1 axes with addition function, separately or together possible especially for milling machines
- Trigonomic function (sin, cos, tan)
- Pitch circle calculation with single coordinate indication
Application- for precise, fast and safe production
- Fast setup through exact positioning for mounting on lathes, milling machines, drilling machines, etc. for measuring traverse paths
- No parallax or reading errors
- Absolute repeatability
Possible functions- Calculator
- Speed display,
- Axis coupling (sum Z)
- Sub D connector sockets
- Absolute/incremental operation
- Conversion inch/metric thread
- Bolt circle calculator (chain dimension)
- Coordinates in circle (pitch circle)
- Holes in circle (pitch circle)
- Measured values radius/diameter switchable
- Zero reset data preset
- Self-diagnosis
- Reference point
- Linear error compensation
- 99 tool memories
suitable for- OPTIMUM lathes
- OPTIMUM milling machines
NoteWhen retrofitting position indicators and measuring bars for lathes and milling machines, holes and threads must be provided on the machine by the customer.
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3384040
