• Smooth and powerful industrial electric motor
• Separate emergency stop impact switch
• Stable casting column
• Measurement scale for drilling depth
• Precisely machined drill table with diagonal T-slots and circumferential cooling water channel
• Drilling table 360 ​​° rotatable
• V-belt cover with safety switch
• V-belt quick-clamping device
• Long, ergonomic cast aluminum sleeve lever cast in one piece (B 16H / B 24H with softgrip handles)
• Massive, large base plate with grooves, strongly ribbed on the back
• By swinging away the drilling table, base plate can be used as a work surface for particularly high workpieces
• Guaranteed concentricity measured better than 0.015 mm in the drill quill
• Drill spindle with precision ball bearings
• High-quality OPTIMUM keyless chuck in the standard scope of delivery
• Large, height-adjustable protective screen with safety switch

from B 24H

• machine light

from B 24H / 400V

• Forward / reverse operation

from B 28H

• Easy tool change through integrated expeller
• Quillons made of steel

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• For all repair and assembly work, eg: straightening axles, girders, shafts, etc .; Pressing and pressing bearings, bolts and bushings; Pressing and squeezing work; Load tests and welding sample tests; and much more.
• Stable welded construction
• Robust frame with perforation for the adjustment of the work table
• Reliable, particularly precise hydraulic from European production
• Pressure build-up by hand or foot operation of the pump lever
• By foot pump both hands free for fixation of the workpiece
• Pressing pressure readable via manometer
• With automatic return of the piston
• With safety valve to protect against overload
• Quality Made in Europe

Note:

• For processing flat material, pressing in bearings, bolts and the like, be sure to use the optional perforated plates.

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Feed roller conveyor without length stop and without measuring system
• Roller and guideway system on which lighter wood, metal or plastic profiles can be precisely sawed, drilled or milled
• Substructure made of solid 3 mm steel profiles, painted and with adjustable feet
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• standard design
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• For sawing hollow profiles and solid materials made of steel, stainless steel, tool steel, non-ferrous metals and plastic
• Hydraulically controlled sawing functions
• Saw blade drive with low-maintenance, oil-lubricated worm gearbox
• With robust three-phase motor with overload protection
• Bearing-mounted turntable
• After starting the cutting cycle, the vice clamps automatically - after completion of the process, it returns to the starting position (HA-DG)
• Saw arm tilted by 25°, thus extending the service life of the saw blade
• Swivel saw arm from +60° to -45
• With chip clearing brush for optimum cleaning and maintenance of the saw blade
• With frequency converter: allows infinitely variable adjustment of the saw blade speed from 20 - 100 m/min.
• BRP - saw blade monitoring
• Hydraulic vice with manual quick clamp for lateral adjustment
• Limit switches control the upper and lower position of the saw arm
• No adjustment of the upper end point necessary
• Cut sensing function with integrated button
• HM saw blade guides
• Pivoting control panel
• Saw blade guides with integrated cooling system

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the rear of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Stopper with reading magnifying glass facilitates reading on the mm scale
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• Quality Made in Germany

Please specify when ordering mounting side and height!

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Impressively quiet!
• Highest life
• Infinitely 30-80 m / min
• Use of coolant on all models possible

• Ideal for sawing steel, aluminum, copper, PVC and Teflon
• Stepless, electronic speed control from 30 - 80 m / min
• Particularly quiet - up to 60% quieter than comparable band saws
• Low vibration and wear thanks to special gearbox with two large gears made of hardened steel
• Guaranteed cutting accuracy of max. 0.3 mm course over 100 mm cutting length
• Each machine individually tested for precision in Italy
• Low-speed DC drive motor with carbon brushes for up to 10 times longer life
• Electronic temperature and ampere recording monitoring against overload
• Cast strip wheels with ground running surface without rubber pads, therefore suitable for dry and wet cutting
• Massive saw bar made of die-cast aluminum (readjustable from MBS 125) and with sturdy transport lock
• Two movable, adjustable saw band guides with chip scraper made of metal
• Particularly stable base plate with non-slip feet
• Very service-friendly, as components are easily accessible

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
• Different tool variants available E, S2, HS2 and HSG
• The powerful auxiliary cylinder facilitates bending
• Next passage between top and bottom cheek of up to 25 mm
• Self-lubricating plain bearings
• Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
• Adjustment of material thickness by means of knurled screw
• Adjustable stop for bending angle

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Precisely built
• High concentricity due to tapered roller bearings ≤ 0.015 mm measured in the quill
• Motor with two-stage gear ratio for powerful transmission of motor power
• Manual quill feed with fine feed
• Powerful DC motor with permanent current monitoring
• Safety electronics in 24 Volt version
• Control electronics with integrated relay control
• Clear control panel with user-friendly membrane keyboard
• Easy-to-read digital display for speed and drilling depth
• Solid and large dimensioned cross table, precisely finished with T-slots and adjustable wedge strips
• Adjustable end stops
• Stable dovetail guide with adjustable wedge strips
• Emergency stop impact switch
• Drilling and milling head can be tilted by ± 60°
• Fine milling feed
• Forward/reverse rotation
• Machine lamp
• Double-row angular contact ball bearings in the axes, adjustable without play
• Height-adjustable protective screen with microswitch, against flying chips and parts, for the greatest possible protection of the user
• X, Y and Z axes with prepared groove for the subsequent assembly of magnetic tapes
• With digital position indicator DRO 5

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Suitable for intensive use in industry
• Heavy industrial grinding machine absorbs the already low vibrations due to high self-weight
• Suitable even with very strong shear forces on the grinding wheels
• Maintenance-free, long-lasting induction motor with smooth running
• Cast iron housing
• Spark protection
• Stable, movable workpiece support
• Grinding wheels not included in the standard scope of delivery

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• For use in the metalworking industry for grinding, structuring and polishing tasks, especially in the stainless steel sector
• 225 mm balanced belt rollers ensure optimum and low-vibration drive
• Infinitely variable belt speed of 4.5 - 27 m/s thanks to frequency shaper
• With electric table height adjustment
• With split table that can be opened, drawer sanding unit and integrated work table lighting
• Smooth-running sanding table even under load
• Easy adjustment of the sanding belt
• Profile roller sanding pad, resulting in less tarnishing during the sanding process
• Right-left rotation as standard

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• For sawing hollow profiles and solid materials made of steel, stainless steel, tool steel, non-ferrous metals and plastic
• Saw blade guide with adjustable carbide plates for a precise cut
• Hydraulically controlled system for both vices and the up and down movement of the saw arm
• Precise material feed via recirculating ball screw
• Frequency converter as standard for infinitely variable adjustment of the saw blade speed from 20 - 100 m/min
• BRP - saw blade monitoring
• The jaws of the two clamping vices are equipped with long-stroke hydraulic cylinders as standard, eliminating the need to preset them to the material cross-section to be sawn
• Digital angle display
• Swivel control panel
• Mechanical band clamping device
• Automatic band guide adjustment
• Chip clearing brush for optimum cleaning and maintenance of the saw blade
• Saw band guides with integrated cooling system

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Suitable for cutting steel and non-ferrous metals
• Sheet support arms for large workpieces
• Cutting line lighting and slotted holes in the upper cover plate for an optimum view of the cutting edge for cutting on a tear
• Manual backgauge 630 mm with millimeter-precise adjustment option

• Suitable for cutting steel and non-ferrous metals
• Heavy, stress-free welded steel construction
• High quality knife
• Sheet metal support arms for large workpieces
• Cut line illumination and long holes in the upper cover plate for an optimal view of the cutting edge for cutting on scratches
• Manual back gauge 630 mm with millimeter precision adjustment
• Photocell for the backgauge area
• The foot control leaves both hands free for the material supply

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• For sawing hollow profiles and solid materials made of steel, stainless steel, tool steel, non-ferrous metals and plastic
• Saw blade drive with low-maintenance, oil-lubricated worm gearbox
• With robust three-phase motor with overload protection
• Saw blade guide with adjustable carbide plates for a precise cut
• With mechanical saw blade tensioning and monitoring via microswitch
• Saw blade guides with integrated cooling system
• With frequency converter as standard for infinitely variable adjustment of the saw blade speed from 20 - 100 m/min
• With BRP saw blade monitoring as standard
• Chip clearing brush for optimum cleaning and maintenance of the saw blade
• Digital angle display
• Swivel control panel

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Silent run
• Stable cast execution
• Lowering of the saw arm via hydraulic cylinder with throttle valve infinitely adjustable
• Micro switch for automatic limit switch
• Easy to read scale for angle adjustment
• As standard with high-quality bi-metal saw band
• Saw band tension adjustable on the front side via handwheel
• Ball bearing saw band guide
• Robust machine base with large wheels and handy transport handle for easy location change of the machine
• Adjustable material stop for serial work
• Circuit breaker for the saw band cover
• Fully equipped, allowing the user to be productive immediately after commissioning

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Miter adjustment from -45° to +60° user-friendly adjustment from the front for better handling, especially with attached roller conveyor
• Robust band guides with adjustable carbide plates for a precise cut
• Saw blade guides with integrated cooling system
• Electromechanical monitoring of the saw blade tension via microswitch
• With chip clearing brush for optimum cleaning and maintenance of the saw blade
• Saw arm inclined by 25°, thus extending the service life of the saw blade
• The saw blade stops automatically at the end of the cutting process
• Hydraulically controlled lowering pressure of the saw arm
• Turntable with pivoting cutting gap prevents cutting into the saw table
• Ergonomic operating concept
• Vice with quick clamping device

Functionality of the semi-automatic machine:

• Automatic workpiece clamping after the start of the cutting cycle
• Execution of the saw cut at the selected belt speed
• Automatic stop of the lowering movement and the saw blade in the lower end position
• Automatic return of the saw arm to its upper end position
• Vice opens automatically
• Operator only has to move the material

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Heavy, durable industrial design with maintenance-free motor
• Housing made of extruded aluminum
• Long service life and smooth running due to balanced rotor with quality ball bearings
• Spark protection on each grinding wheel reduces flying sparks
• Sight glasses made of shatterproof material
• Vibration damping rubber feet
• Coarse and fine grinding wheel (K36/K80) as standard

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Quiet running
• Sturdy cast design
• Infinitely adjustable lowering of the saw arm via hydraulic cylinder with throttle valve
• Microswitch for automatic limit stop
• Easy-to-read scale for angle adjustment
• With high-quality bi-metal saw blade as standard
• Saw blade tension adjustable at the front via handwheel
• Ball bearing saw blade guide
• Robust machine base with large wheels and handy transport bracket for easy relocation of the machine
• Adjustable material stop for series production
• Safety switch for the saw blade cover
• Fully equipped, allowing the user to work productively immediately after commissioning

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Heavy-duty version
• Highly quiet running thanks to new spindle design
• Industrial motor
• Separate emergency-stop pushbutton
• Digital depth gauge
• LED machine light integrated in drill head
• Precisely machined, Stable drilling table with diagonally running T-slots with circulating cooling water channel
• Drilling table inclinable ± 45° and rotatable 360°
• V-belt cover with safety switch
• Precision spindle bore
• Machine operation Safety electrics in 24 V DC voltage
• Guaranteed concentricity ≤ 0.02 mm measured in the drilling spindle
• Thick-walled steel column for high force absorption and stability
• Massive, large dimensioned base plate with T-slots

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

Available on request

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

Quality Made in Europe

Note on technical data
For bending stainless steel, optional hardening of the tools is required
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Versatile range of applications such as drilling, reaming, thread cutting
• Electrically braked motor
• Operating elements with 24V DC electrics and 2-channel safety chain in accordance with DIN EN 12717
• Heavy, solid, high-quality casting
• Wide reach due to horizontally adjustable machine head
• Clearly arranged control panel
• Smooth-running swivel and traversing axles
• Sturdy, torsion-resistant construction of the boom
• Boom height adjustment via powerful motorized drive and lifting spindle
• Gearbox of the drill head runs in an oil bath
• Boom guideways hardened and precision-ground
• Gear wheels made of chrome-nickel steel, hardened and precision-ground for quiet and smooth running
• Drill head and column can be clamped or released together or separately
• Right/left rotation
• Solid, precise drill table, large dimensions
• Hardened and ground clamping table with parallel T-slots
• Machine light
• Overload protection
• Thick-walled cast iron column ensures smooth running and stability
• LED lamp
• Coolant system with coolant tank in the machine base
• Clamping table included in scope of delivery
• Column and headstock mechanically clamped

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
