51-3936015
- For precision surface grinding
- Maximum stiffness and stability thanks to tension-free re-heated and hardened cast iron construction
- High-quality spindle with precision cone roller bearings (circular accuracy 2 microns)
- Electromagnetic clamping plate for fixing the workpiece including automatic demagnetization function
- Automatic central lubrication for all slides and spindles
- Hand scraped and Turcite-B-coated V-flat guides guarantee extremely uniform, low-friction movement and highest precision
- Halogen working light dustproof, completely contact-proof and protected against jet water according to IP65
- Second grinding wheel flange included in delivery
Automatic feed control AD 5The fsM series models are equipped with automatic feed control (AD 5). Different grinding cycles are available: surface loops with delivery at the starting point, groove loops with delivery at the starting point, groove loops with delivery at the start and end points. The delivery of the grinding wheel can be individually designed depending on the workpiece. The total grinding size is divided into coarse and fine delivery, the delivery steps can be freely entered, depending on the application, with a minimum resolution of up to 0.001mm. The possibility to program dead runs after a certain number of delivery steps as well as passages for firing after reaching the grinding measure provides the best grinding results.
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3940408
- 10" touchscreen NC control G1 for Y and Z axis
- Spindle bearing class P4 from NSK guaranteed concentricity of 0.002 mm
- Robust V flat guide with Turcite-B coating in the X and Z axes for grinding heavy workpieces
- Backlash-free ball screws in the Y and Z axes
- Optional extras: NC-controlled parallel puller and compensator on the grinding head, semi or fully automatic balancing device, full encapsulation of the grinding area, and much more
Standard equipment- 10" touchscreen NC control G1 for Y and Z axes
- Grinding modes: flat grinding, plunge grinding, cross grinding
- Spindle bearing class P4 from NSK guaranteed concentricity of 0.002 mm Turcite-B coating in the X and Z axes for grinding heavy workpieces
- Backlash-free ball screws in the Y and Z axes
- NC-controlled parallel pull-off and compensation device above the machine table
- Coolant device with magnetic separator
- Partial encapsulation of the work table with monitored door
- Infinitely variable speed of the grinding spindle thanks to an inverter
- Automatic, hydraulic X-axis feed
- Stepless adjustment of the X-axis speed via hydraulic reg elventil
- Automatic, motorized Z-axis feed driven by servo motor
- Adjustment of the end positions in X and Z-axis via joystick
- Automatic, motorized Y-axis feed with servo motor
- electronic handwheel for the Y and Z axes
- automatic central lubrication of all axes/guides
optional special equipment- NC controlled parallel pulling and compensating device on the grinding head
- Automatic balancing device
- Full encapsulation of the grinding area with two sliding doors
- Additional grinding wheel flanges
- Increased motor performance
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3772125
- The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
- Different tool variants available E, S2, HS2 and HSG
- The powerful auxiliary cylinder facilitates bending
- Next passage between top and bottom cheek of up to 25 mm
- Self-lubricating plain bearings
- Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
- Adjustment of material thickness by means of knurled screw
- Adjustable stop for bending angle
Equipment details:FSBM 1270-20 E
- With segmented sharp-bending tools, continuous bending strip and continuous bed support
FSBM 1020-20 S2
- With segmented sharpening tools, segmented bending strip and continuous bed support
FSBM 1020-20 HSG
- With segmented gooseneck tools, segmented bending bar and segmented bed support
- Segments have a hardness of HRC24-26
Note on technical data:- Sheet thickness max.: Performance data based on material with tensile strength 400 N/mm²
- Bending capacity VA: factor 0.75
- Bending capacity aluminum: factor 1.2
- Hardened top tools are required to bend VA
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-4001015
- For all repair and assembly work, e.g.: alignment of axles, beams, shafts, etc .; pressing and pressing bearings, bolts and bushings; pressing and squeezing work; load tests and welding sample tests; and much more
- Stable welded construction
- Robust frame with perforation for the adjustment of the press table
- Reliable, very precise hydraulic from European production
- With chrome-plated cylinder pistons
- Pressing pressure readable via manometer
- With automatic return of the piston with safety valve to protect against overload
- For processing flat material, pressing in bearings, bolts and the like, it is essential to use the optional perforated plates
- Quality made in Europe
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3990100
- For machining stainless steel, cast iron, aluminum, non-ferrous metals, plastics, etc.
- Heavy duty motor with soft start and overload protection
- With constant electronics for constant speed even under load
- Optimal adaptation to the workpiece through stepless adjustment of the speed
- Rotational speeds can be conveniently controlled via the thumb wheel on the rubberized handle
- Very robust gearbox
- Fatigue-free working thanks to ergonomic two-hand operation
- As standard with Velcro fleece for reworking already mounted stainless steel railings
