51-3191045
- Separate emergency stop stop switch
- Measurement scale for drilling depth
- Precisely machined, stable drilling table with diagonally running T-slots and circumferential cooling water trough
- Drilling table ± 45° inclinable and 360° rotatable
- One-piece die-cast aluminium quill lever with soft-grip handles
- Prezision spindle drilling
- Safety electrics in 24 V DC voltage
- Guaranteed concentricity accuracy of less than 0.03 mm measured in the drilling sleeve
- Drilling spindle with preprecision ball bearings
- High-quality quick-action drill chuck
- GATES quality belt
- Largely dimensioned base plate with T-slots, heavily ribbed on the rear side
- Largely dimensioned, height-adjustable protective screen with
- Right/left rotation
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3191044
- Separate emergency stop stop switch
- Drill depth stop
- Precisely machined, stable drilling table with diagonally running T-slots and circumferential cooling water trough
- Drilling table ± 45° inclinable and 360° rotatable
- One-piece die-cast aluminium quill lever with soft-grip handles
- Prezision spindle drilling
- Safety electrics in 24 V DC voltage
- Guaranteed concentricity accuracy of less than 0.03 mm measured in the drilling sleeve
- Drilling spindle with preprecision ball bearings
- High-quality quick-action drill chuck
- GATES quality belt
- Largely dimensioned base plate with T-slots, heavily ribbed on the rear side
- Largely dimensioned, height-adjustable protective screen with
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-4320076
- NC control for setting the bending angle and the correction
- counter for high repeatability
- Mobile control panel with controls and pedals
- Fast tool change
- Powerful motor with inverter and reduction gear produces high torque
- NC control for setting the bending angle and the correction
- counter for high repeatability
- Mobile control panel with controls and pedals
- Fast tool change
- All shafts hardened and ground
- Material clamping is done manually
- Very good price / performance ratio
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3020285
- Smooth and powerful brushless drive
- Separate emergency stop impact switch
- Large, height-adjustable protective screen with safety switch for the utmost protection of the user
- Long, ergonomic aluminum die-cast quill lever
One piece cast (B 24HV with softgrip handles) - Measurement scale for drilling depth
- Belt cover with safety switch
- Forward / reverse operation
- Machine light
From OPTIdrill B 28HV
- Quillons made of steel
- Coolant system
- Chip filter according to the Machinery Directive
- Easy tool change through integrated expeller
OPTIdrill B 34HV
- Quill stroke 160 mm
- Tapping function
- Digital depth gauge
Special feature of the OPTIdrill B 34 HV- Operating mode "auto"
- Engine starts automatically after lever movement
- Stops again in the starting position
- Pushbutton Start and Stop does not have to be pressed during repetitive drilling tasks
- Operating mode "tapping"
- Engine is activated by moving the handle down
- The direction of rotation is changed by limit switches on the adjustable drilling depth stop
EquipmentdetailsPowerful brushless drive- Especially quiet running
- High performance
- Approximately constant torque over the entire speed range
Belt drive- Best power transmission through aluminum pulleys in conjunction with toothed GATES quality V-belt
- Smooth running thanks to ground multi-tooth driver
Digital speed display- integrated in the housing
Speed control- by means of potentiometer
Concentricity- Guaranteed ; 0.015 mm measured in the quill
Spindle- Precision ball bearings
- High quality OPTIMUM keyless chuck as standard
V-belt tensioning deviceMachine light- Integrated in the drill head
- Halogen lamp
Drilling- Precisely worked
- Diagonal T-slots
- 360° rotatable
- Circulating cooling water channel
baseplate - Solid
- Large dimensions
- Heavily ribbed on the reverse side
cast column- Thick-walled
- High power and stability
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-3779100
- Foot operated
- Heavy, compact welded construction
- Powerful drive by Lenzemotors
- With continuous sharp bending bar
- In series with manual adjustment of the bending angle
- Especially low-maintenance
- The workpiece is clamped by a motorized mechanism
- S-models with segmented upper tools
- SH-models with high, segmented casting foot tools
Available on request - Other models
- Standard tools hardened
- Hardened sharp bending bar and bending bar
- Segmented tools and hardened bending bar
- Segmented casting foot tools and bending bar hardened
Quality Made in Europe
Note on technical data For bending stainless steel, optional hardening of the tools is required
