Combination grinding machine OPTIgrind GU 18B

• Grinding wheels for double grinders

• Grinding wheels for double grinders

• Stable substructure
• Cyclone extraction integrated in the substructure, therefore less space required
• For GU and GU-S machines
• Soundproofed
• Lamp holder for LED 3-500
• Without drill holes - must be drilled individually

• When the double grinder is switched on, the extraction system starts automatically with a delay of 2-3 seconds. There is no need to additionally switch on the suction unit
• The extraction system continues to run for 2-3 seconds after the double grinder is switched off
• The residual dust is extracted after the machine is switched off in accordance with the Hazardous Substances Ordinance

• Heavy industrial combination grinding machine absorbs the low vibrations due to its high weight
• Also suitable for very strong pushing forces on the grinding wheel and brush
• Maintenance-free, durable induction motor with smooth running
• Housing made of cast iron
• Stable, adjustable workpiece support
• Grinding wheel and brush not included in the standard delivery

Multipurpose wire brush

• High strength steel wire available in accessories in various thicknesses

Brush Housing

• swiveling
• Extraction nozzle for connecting a suction device

• Direct magnetic belt measuring system
• Delivery of direct magnetic belt measuring system including display unit Z58
• Independent stop carriage and length measuring drives
• Dimension is displayed via display unit Z58
• Sensor head mounted directly on the stop carriage
• Dimensional and repetition accuracy ± 0.1 mm per metre
• Cable and air ducting via energy drag chain

• Heavy-duty version
• Highly quiet running thanks to new spindle design
• Industrial motor
• Separate emergency-stop pushbutton
• Digital depth gauge
• LED machine light integrated in drill head
• Precisely machined, Stable drilling table with diagonally running T-slots with circulating cooling water channel
• Drilling table inclinable ± 45° and rotatable 360°
• V-belt cover with safety switch
• Precision spindle bore
• Machine operation Safety electrics in 24 V DC voltage
• Guaranteed concentricity ≤ 0.02 mm measured in the drilling spindle
• Thick-walled steel column for high force absorption and stability
• Massive, large dimensioned base plate with T-slots
