52-2098412
- Maintenance-free direct drive
- Low space requirements and energy costs
- Low noise level
- Generously dimensioned cooler
- Easy installation and accessibility of all maintenance positions
Coaxial screw-type compressor with maintenance-free drive and maximum energy efficiency in all pressure ranges. Low compressor speeds and low load on the bearings of the patented direct drive ensure a very long service life.
EasyTRONIC Micro II electronic control for reliability and efficiency- Prevents motor overload, reduces wear and makes for a longer service life
- Monitoring of operating hours, temperature and motor overload
- Phase sequence relays control the direction of rotation of the motor, thereby avoiding possible damage during commissioning or after relocation
Optimized cooling system- Low-noise centrifugal fan guarantees optimal operating temperatures even under unfavourable conditions
- Thermostatically and electronically controlled fan and generously sized heat exchanger result in a longer service life and less fluctuation in oil temperature
User-friendly in all details- Low noise, suitable for deployment in any work environment
- Small footprint facilitates transport and deployment
- Service-friendly thanks to optimum accessibility and easy removal and installation of all components that require maintenance
- All air and oil lines are made of heat-resistant rubber
- Equipped with a star delta circuitry as factory standard
- Ready to connect with all fittings and safety equipment
K models with Integrated refrigeration dryer- More reliable compressed air system without costly downtimes and production delays while simultaneously ensuring product quality
- Fully integrated into the housing
- Ready for use without installation overhead
- Equipped with control panel and time-controlled condensate drain
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2097304.2
- Innovative LOGIN control with 4.3" touch screen for easy operation and full control of all functions.
- Rotation direction control for the motor, prevents damage during start-up or after a change of location
- High cooling effect and low noise level due to thermostatically controlled radial fan
- Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
- Aftercooler reduces the effort for drying and filtration of the generated compressed air
- Easy to service: simple removal and installation of all components requiring maintenance
Latest generation IE4 permanent magnet motor for max. energy efficiency
- Larger speed/load range
- Larger delivery volume supply range
- Extremely energy efficient - up to 50% energy consumption savings compared to a "fixed speed" model
- Very quiet operation - only 64 dB
Energy saving through frequency control
- Ideal for frequently changing compressed air consumption
- Compressor delivery rate adjusts to actual consumption
- Electronic control monitors motor and compressor speed and keeps line pressure constant even when consumption fluctuates widely
- Advanced and efficient cutting-edge technology in the smallest possible space
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2317100
- Sintered filter with centrifugal principle and diaphragm pressure regulator with secondary venting
- For compressed air, neutral gases
- Inlet pressure 1.5 - 12 bar
- Suitable for temperatures from -10 to +50°C
- Semi-automatic condensate drain
- For vertical installation
- Sintered filter with centrifugal principle and diaphragm pressure regulator with secondary venting
- For compressed air, neutral gases
- Inlet pressure 1.5 - 12 bar
- Suitable for temperatures from -10 to +50°C
- Semi-automatic condensate drain
- For vertical installation
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-2096402.2
- Innovative LOGIN control with 4.3" touch screen for easy operation and full control of all functions.
- Energy-efficient IE4 motor
- Rotation direction control for the motor, prevents damage during start-up or after a change of stand location
- High cooling effect and low noise level due to thermostatically controlled radial fan
- Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled radial fan, optimum cooling air flow and generously dimensioned heat exchangers
- Aftercooler reduces the effort for drying and filtration of the generated compressed air
- Star-delta switching as standard
- Easy to service: simple removal and installation of all components requiring maintenance
ManufacturerAircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
52-215151025
- Very smooth inner surfaces, better flow
- well proven for years
- pressure and temperature resistant
- vibration and impact resistant
- resistant to corrosion and aging
- low weight
Room amenities:operating temperatur
- with continuous load: -60 ° C to +100 ° C (air)
Physical Properties
- Density, at 20 ° C: 1.04 g / cm
- linear expansion coefficient: 15 · 10-5 l / K
- Melting point: approx. + 160 ° C to + 170 ° C
