51-3770125
- Revolutionary simple, very fast and comfortable operation
- Compact and space-saving
- With practical shelves for all individual segments and bending rails
- Ideal for bending aluminum, copper, steel, stainless steel, etc.
- Precise bend angle adjustment up to 170 °
- Powerful electromagnetic system for optimum bending results
- The clamping across the entire width guarantees a clean bend
- Very high bending capacity
- The main pressure is on the upper cheek, not on the machine
- The unique centerless hinges ensure precise power transmission at the bending point
- Backgauge, segmented upper jaw and foot pedal are standard
With practical shelves for all individual segments and bending rails
Extremely fast and easy operation - in just a few steps you can turn your sheets into the desired shape without great effort
Step 1:
- Place the workpiece on the magnetic conductors and adjust using the bending edge
Step 2:
- Choose the right bending segment, place it on the workpiece and activate the magnet
Step 3:
- At the bend stop you can set the exact bending angle. Perform the bending process
The conversion for further bending operations is done in a few steps.
Note: Do not use the machine with pacemakers
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3772125
- The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
- Different tool variants available E, S2, HS2 and HSG
- The powerful auxiliary cylinder facilitates bending
- Next passage between top and bottom cheek of up to 25 mm
- Self-lubricating plain bearings
- Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
- Adjustment of material thickness by means of knurled screw
- Adjustable stop for bending angle
Equipment details:FSBM 1270-20 E
- With segmented sharp-bending tools, continuous bending strip and continuous bed support
FSBM 1020-20 S2
- With segmented sharpening tools, segmented bending strip and continuous bed support
FSBM 1020-20 HSG
- With segmented gooseneck tools, segmented bending bar and segmented bed support
- Segments have a hardness of HRC24-26
Note on technical data:- Sheet thickness max.: Performance data based on material with tensile strength 400 N/mm²
- Bending capacity VA: factor 0.75
- Bending capacity aluminum: factor 1.2
- Hardened top tools are required to bend VA
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-4001015
- For all repair and assembly work, e.g.: alignment of axles, beams, shafts, etc .; pressing and pressing bearings, bolts and bushings; pressing and squeezing work; load tests and welding sample tests; and much more
- Stable welded construction
- Robust frame with perforation for the adjustment of the press table
- Reliable, very precise hydraulic from European production
- With chrome-plated cylinder pistons
- Pressing pressure readable via manometer
- With automatic return of the piston with safety valve to protect against overload
- For processing flat material, pressing in bearings, bolts and the like, it is essential to use the optional perforated plates
- Quality made in Europe
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3990100
- For machining stainless steel, cast iron, aluminum, non-ferrous metals, plastics, etc.
- Heavy duty motor with soft start and overload protection
- With constant electronics for constant speed even under load
- Optimal adaptation to the workpiece through stepless adjustment of the speed
- Rotational speeds can be conveniently controlled via the thumb wheel on the rubberized handle
- Very robust gearbox
- Fatigue-free working thanks to ergonomic two-hand operation
- As standard with Velcro fleece for reworking already mounted stainless steel railings
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3359030
- Adjustable offset
- Hardened and ground spindle
- Long spindle guide
- High force at the end of stroke
- Honed ram guide and ground rams ensure a long service life and precise guidance
- Quick changeover thanks to simple and safe adjustment of the working height
- Ground press tables allow reproducible positioning of your tools
- Locating holes in the ram and table plate for precise alignment of the tools
- Support table with T-slots for attaching workpiece clamping fixtures
- PD5 with locking function
- PD5 and PD8 with spindle for height adjustment
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
