Mobile piston compressor with petrol engine AIRCAR-BAU 500/20 B PRO

• Protects against premature wear and corrosion
• Miscible with other oils of the same qualification
• Improved viscosity-temperature behavior

Manufacturer
AVIA MINERALÖL AG
Grillparzerstrasse 8, 81675 Munich / GERMANY
www.avia.de

• Protects against premature wear and corrosion
• Miscible with other oils of the same qualification
• Improved viscosity-temperature behavior

Manufacturer
AVIA MINERALÖL AG
Grillparzerstrasse 8, 81675 Munich, Germany
www.avia.de

• Eyebolts on the frame for lifting
• The design, the puncture-proof PU foam tires and the transport handle allow easy transport to the place of use

• With 1-cylinder / 4-stroke Honda engine for off-grid operation
• Due to its independence from the power grid, it is particularly suitable for gardening and landscaping, mobile tire service and breakdown services as well as agriculture and forestry
• With idling and speed control, thereby adapting to the respective load conditions
• The high-performance gray cast iron unit and the low speed warranty maximum smoothness and a long service life.
• The large fan wheel and a cooling air baffle ensure optimum cooling of the compressor.
• Stable belt guard made of metal
• An aftercooler with large cooling fins ensures a low tank inlet temperature and therefore less moisture in the compressed air
• With all safety devices
• Ten-year rust-through warranty on powder-coated compressed air tank

Room amenities:

Freewheel valve for less wear

• The freewheel valve avoids constant switching on and off
• After reaching the set pressure, the valve opens and the compressor runs without pressure
• When the pressure drops, the valve closes and the compressor works again on pressure

Service

• On the filter pressure regulator, you can fix the working pressure infinitely and remove pressure-reduced and filtered compressed air.
• Two pressure gauges show the tank u. Working pressure.
• As standard with quality quick coupling and high quality CONDOR pressure switch

Round protection

• The frame is at the same time a compressed air tank, holder for tool storage as well as all-round protection for all sensitive components
• Optimally protected and transportable with high performance

Eyebolts

• With two lifting eyes on the frame for lifting eg with a crane

Transport handle

• The two-handed grip allows easy transport to the job site

Shock mounts

• Equipped with two large and wide front swinging elements for stable stability

Tool tray

• Practical in everyday use as a storage for tools, plans, etc. and as protection against damage from above

High performance aggregate HOS

• The precisely machined piston is equipped with a high-alloy piston ring, oil scraper ring and oil scraper ring, which seal the piston from the cylinder wall.
• The crankcase is filled with oil, which is sprayed against the cylinder wall with each piston stroke.
• The oil scraper wipes the oil-wetted cylinder wall downwards.

PU foam tires

• The large, stable wheels with puncture-proof PU foam tires ensure easy and comfortable transport even on uneven ground

Control panel
Ergonomically favourably positioned, clearly structured and self-explanatory

1. manometer to display the tank pressure
2. direct compressed air output with one-hand safety coupling from the compressed air tank
3. filter pressure reducer to set the working pressure
4. manometer to display the set working pressure
5. compressed air output one hand Safety coupling for filtered compressed air
6. mist lubricator for metered supply of lubricant to the tools
7. compressed air outlet one hand safety coupling for filtered and lubricated compressed air

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

EV WS / EA hood incl. relief valve
F4x1/4" connection
preset to 7.8 to 9.8bar
adjustable up to max. 16bar
at 400V max. 16Ampere
at 500V max. 9Ampere
Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Innovative LOGIN control with 4.3" touch screen for easy operation and complete control over all functions
• Connection of up to eight compressors possible, no matter if with constant or variable speed
• All information on current operating status at a glance
• Rotation direction control for the motor, prevents damage during start-up or after a change of location
• Low noise emission (only max. 67 dB) during operation, due to extremely low speed of the screw compressor and use of a low-noise radial fan
• Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
• Aftercooler reduces the effort for drying and filtration of the generated compressed air
• Star-delta switching as standard
• Easy to service: simple removal and installation of all components requiring maintenance

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at

• Innovative LOGIN control with 4.3" touch screen for easy operation and complete control over all functions
• Connection of up to eight compressors possible, no matter if with constant or variable speed
• All information on current operating status at a glance
• Rotation direction control for the motor, prevents damage during start-up or after a change of location
• Low noise emission (only max. 67 dB) during operation, due to extremely low speed of the screw compressor and use of a low-noise radial fan
• Optimum operating temperature and low fluctuation of oil temperature due to thermostatically controlled centrifugal fan, optimum cooling air flow and generously dimensioned heat exchangers
• Aftercooler reduces the effort for drying and filtration of the generated compressed air
• Star-delta switching as standard
• Easy to service: simple removal and installation of all components requiring maintenance

Manufacturer
Aircraft Kompressorenbau und Maschinenhandel GmbH
Gewerbestraße Ost 6, 4921 Hohenzell, Austria
info@aircraft.at
