Narre 1/2" 90H 250mm, max 1000Nm

The Holzstar FKS 255‑1300 (400 V) is a precise and robust sliding table saw, designed for professional and semi‑professional woodworking applications. It is ideal for accurate rip and cross cutting of solid wood and sheet materials, offering excellent stability and smooth operating characteristics.

The machine features a heavy grey cast‑iron work table, which ensures low‑vibration operation and clean cutting results. The sliding table with telescopic supports allows easy and accurate handling of large workpieces. The saw unit tilts up to 45° and is conveniently adjusted via a handwheel with scale.

Key features:

• Rated motor power (S1): 2.0 kW
• Power supply: 400 V / 50 Hz
• Blade diameter: 254 mm
• Blade bore: 30 mm
• Blade speed: 4,000 rpm
• Max. cutting height at 90°: 80 mm
• Max. cutting height at 45°: 54 mm
• Max. rip capacity: 610 mm
• Max. cross‑cut width left of blade: 845 mm
• Cutting length with sliding table: up to 1250 mm
• Table size: 790 × 350 mm
• Sliding table: 1320 × 238 mm
• Working height: approx. 835 mm
• Dust extraction outlets: Ø 100 mm / 30 mm
• Net weight: approx. 155 kg

Standard delivery:

• Circular saw blade Ø 254 × 30 × 3.0 mm (Z40)
• Sliding table carriage
• Rip fence with round rod guide and fine adjustment
• Mitre fence (‑45° to +45°)
• Eccentric clamp
• Blade guard with dust extraction outlet
