Pressure regulator 1/4" 12 bar

• Two-cylinder high-performance units made of gray cast iron for a long service life
• Aftercooler with cooling fins ensures a low tank inlet temperature and thus less moisture in the compressed air
• Ten-year guarantee against rusting through on powder-coated compressed air tanks

• Two-cylinder high-performance units made of gray cast iron for a long service life
• Large fan wheel and a cooling air baffle on the cylinder for optimum cooling of the compressor
• Quality electric motor with high starting torque
• Electric motor equipped with motor protection switch
• Aftercooler with cooling fins ensures a low tank inlet temperature and thus less moisture in the compressed air
• Sturdy metal belt guard
• 400 volt models with phase inverter as standard for easy manual reversal of the direction of rotation
• Compressed air tank equipped with safety valve, tank pressure gauge and condensate drain valve
• Including all safety devices
• Completely ready for connection
• Filter pressure regulator with one pressure gauge for regulated compressed air cleaned of condensate, dirt and oil, second pressure gauge for tank pressure
• Ten-year guarantee against rusting through on powder-coated compressed air tanks
• Includes high-quality one composite safety coupling and high-quality CONDOR pressure switch
• Flexible armored hose line with heat protection for long service life without vibration breakage
• Ergonomic handle, rubber handle and transport handle on the compressed air tank for convenient transportation
• Sturdy steering chassis with parking brake in combination with large, puncture-proof wheels for comfortable transportation

• Maintenance-free direct drive
• Low space requirements and energy costs
• Low noise level
• Generously dimensioned cooler
• Easy installation and accessibility of all maintenance positions

Coaxial screw-type compressor with maintenance-free drive and maximum energy efficiency in all pressure ranges. Low compressor speeds and low load on the bearings of the patented direct drive ensure a very long service life.

• Prevents motor overload, reduces wear and makes for a longer service life
• Monitoring of operating hours, temperature and motor overload
• Phase sequence relays control the direction of rotation of the motor, thereby avoiding possible damage during commissioning or after relocation

• Low-noise centrifugal fan guarantees optimal operating temperatures even under unfavourable conditions
• Thermostatically and electronically controlled fan and generously sized heat exchanger result in a longer service life and less fluctuation in oil temperature

• Low noise, suitable for deployment in any work environment
• Small footprint facilitates transport and deployment
• Service-friendly thanks to optimum accessibility and easy removal and installation of all components that require maintenance
• All air and oil lines are made of heat-resistant rubber
• Equipped with a star delta circuitry as factory standard
• Ready to connect with all fittings and safety equipment

• More reliable compressed air system without costly downtimes and production delays while simultaneously ensuring product quality
• Fully integrated into the housing
• Ready for use without installation overhead
• Equipped with control panel and time-controlled condensate drain

Higher efficiency - lower costs
The innovative and highly efficient ASDB series uses a patented 3-circuit heat exchanger system. In combination with the glycol cycle, a significant energy saving is achieved. The glycol mass acts like a cold-storing medium. The ASD dryers are particularly suitable for partial load operation and for irregular compressed air requirements. By using the ASD dryers, you can noticeably save operating costs.

Operation and advantages of the glycol cycle
The water-glycol mixture is cooled when not all the cooling energy is needed to cool the compressed air. When the refrigeration compressor shuts off during partial load operation, the compressed air is cooled down by the cold stored in the glycol mass. Only when the mass is no longer cool enough, the refrigerant compressor turns on again. Therefore, the ASD dryers show their potential for savings, especially during partial load operation and irregular compressed air requirements. When the air compressor starts again after a pause and releases compressed air into the piping system, the ASD dryers immediately cool this compressed air to dew point because the glycol mass immediately provides the temperature required. Many other systems, in which the refrigeration compressor can cool down to operating temperature only after a start-up period, allow humid air to flow into the supply network during this time, with all the adverse effects.

The advantages at a glance

• Improved energy efficiency thanks to patented 3-circuit heat exchanger system
• Energy saving and longer service life by switching off the refrigeration compressor in partial load operation
• Optimal dew point control with additional temperature sensor for the glycol control
• Condensate drainage without pressure loss through integrated electronic, level-regulated condensate separator
• Optimum performance under all load and ambient conditions thanks to variable fan speed control
• By using quality components longevity and reduction of service costs
• Operating cost reduction with active environmental protection

The operation of the patented 3-circuit heat exchanger system

• Warm saturated with compressed air compressed air flows into the heat exchanger.
• Pre-cooling of the inlet air is caused by the countercurrent cold outlet air in the heat exchanger.
• Input air is brought to dew point temperature by the refrigerant circuit, causing condensate.
• Condensate is collected and removed in the integrated electronic, level-regulated condensate separator.
• Glycol circulation stores excess energy and cools the intake air at partial load.
• The refrigeration compressor switches off at partial load, which can double its service life.

• Sintered filter with centrifugal principle and diaphragm pressure regulator with secondary venting
• For compressed air and neutral gases
• Inlet pressure 1.5 - 16 bar
• Suitable for temperatures from -10 to +50°C
• Semi-automatic condensate drain
• Secured by lockable handwheel
• For vertical installation

• Sintered filter with centrifugal principle and diaphragm pressure regulator with secondary venting
• For compressed air and neutral gases
• Inlet pressure 1.5 - 16 bar
• Suitable for temperatures from -10 to +50°C
• Semi-automatic condensate drain
• Safety via lockable handwheel
• For vertical installation
