51-37791341
- Powerful and low-noise drive via LENZE gear motors with brake
- Compact, heavy-duty, stress-free welded steel design
- Acute bending rail made of tool steel C50 at the clamping beam
- Continuous, replaceable bed support made of tool steel C50
- Continuous bending rail made of tool steel C50 at the bending beam
- Clamping beam pressure controlled automatically via motor current absorption
- Clamping beam driven via generously dimensioned trapezoidal thread spindles
- Bending angle adjustment PT 1 via potentiometer on the machine’s front side (right)
- Manual granular adjustment of the bending beam with help of a scale
- Manual crowning via pressure screws in the bending beam
- Remote foot switch with emergency stop function
- All moving parts with low-maintenance bearings
- Electrical components by Schneider or Omron
- SH-models with high, segmented crowbar tools
- Stock equipment as standard with: hardened tools, control PT 1, back gauge 6-760mm with hand wheel, measuring device and stop fingers, quick clamping for top tool
- Quality Made in Europe
- Available on request: Models in DUO design featuring full-width acute bending rail and segmented crowbar tools
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3292386
- Heavy industrial version
- Quiet running
- Manual or semi-automatic operation
- Steplessly adjustable saw blade speed from 20-80 m/min
- High cutting accuracy due to vibration-free running
- Mitration adjustment -45° to 60° by swivelling the entire saw bow
- Standard with high quality bi-metall saw band
- Microswitch for automatic limit switch
- Coolant pump
- Ball bearing saw band guide with carbide plates for optimum cutting results
- Easy adjustment of the lowering speed by means of feed control valve in the control panel
- Large dimensioned, hydraulic quick-clamping vice, self-closing, laterally adjustable
- Manometer for correct saw blade tension
- Clear control panel
Function semi-automatic operation- closing the vice and activating the motor
- lowering the saw bow for cutting
- stopping the motor and returning the saw bow to the starting position
ManufacturerOptimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
51-4421250
- Suitable for wet grinding machines
- Filter area visible through transparent plastic windows
- Suitable for wet grinding machines
- Filter area visible through transparent plastic windows
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3693105
- Two-column guided band saw for sawing solid bars and bar profiles
- Siemens S7-1500 control system with wide range of functions and operation via 7" touch display
- Cutting movement via rotating spindle and servo motor
- With ARP (automatic cutting feed control) -> Automatic saw blade feed depending on the material resistance. Feed speed is constantly adapted to the current cutting load. ARP enables shorter work processes and at the same time longer service life of the saw bands
- Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
- Infinitely variable cutting speed from 15 - 150 m/min
- Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
- Material is clamped in front of and behind the cut using a two-part vice
- Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
- Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
- Front band guide moves automatically parallel to the movable vice jaw
- Electrically driven chip clearing brush
- Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
- More powerful motor optionally available
- Saw blade guides with integrated cooling system
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
51-3692110
- Two-column guided horizontal saw for sawing solid bars and bar profiles
- Mitsubishi FX 5 control system with simple operation via 7" touchscreen
- With 2000 mm material transporter as standard -> frequency-controlled feed via circulating spindle
- Cutting movement via hydraulic cylinder
- With BRP (cutting feed control) -> if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continues
- Automatic positioning after entering the desired angle
- Hydraulic clamping of the turntable enables precise angular cutting
- Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
- Infinitely variable cutting speed from 15 - 150 m/min
- Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
- For straight cuts, the material is clamped in front of and behind the cut using a two-part vice
- Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
- Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
- Front band guide moves automatically parallel to the movable vice jaw
- chip clearing brush driven via belt roller
- Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
- Safety light barrier from LEUZE in front of the machine and the material transporter
- More powerful motor optionally available
- Saw blade guides with integrated cooling system
ManufacturerStürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
