Power tools, machinery

• Versatile range of applications such as drilling, reaming, thread cutting
• Electrically braked motor
• Operating elements with 24V DC electrics and 2-channel safety chain in accordance with DIN EN 12717
• Heavy, solid, high-quality casting
• Wide reach due to horizontally adjustable machine head
• Clearly arranged control panel
• Smooth-running swivel and traversing axles
• Sturdy, torsion-resistant construction of the boom
• Boom height adjustment via powerful motorized drive and lifting spindle
• Gearbox of the drill head runs in an oil bath
• Boom guideways hardened and precision-ground
• Gear wheels made of chrome-nickel steel, hardened and precision-ground for quiet and smooth running
• Drill head and column can be clamped or released together or separately
• Right/left rotation
• Solid, precise drill table, large dimensions
• Hardened and ground clamping table with parallel T-slots
• Machine light
• Overload protection
• Thick-walled cast iron column ensures smooth running and stability
• LED lamp
• Coolant system with coolant tank in the machine base
• Clamping table included in scope of delivery
• Column and headstock mechanically clamped

• Heavy-duty version
• Highly quiet running thanks to new spindle design
• Industrial motor
• Separate emergency-stop pushbutton
• Digital depth gauge
• LED machine light integrated in drill head
• Precisely machined, Stable drilling table with diagonally running T-slots with circulating cooling water channel
• Drilling table inclinable ± 45° and rotatable 360°
• V-belt cover with safety switch
• Precision spindle bore
• Machine operation Safety electrics in 24 V DC voltage
• Guaranteed concentricity ≤ 0.02 mm measured in the drilling spindle
• Thick-walled steel column for high force absorption and stability
• Massive, large dimensioned base plate with T-slots

• With foot control
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp-bending rail
• Seriesßig with manual adjustment of the bending angle
• Especially low-maintenance
• Clamping of the workpiece is motor-driven
• SH models with high, segmented cast base tools
• DUO models with continuous sharp-bending rail and high, segmented goat foot tools

• Standard tools hardened
• Sharp bending bar and bending bar hardened
• Segmented tools and bending bar hardened
• Segmented cast foot tools and bending bar hardened

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

• The clamping of the workpiece is done by hand clamping
• Easy fixing of the set bending angle, which ensures a high repeatability
• Self-lubricating plain bearings
• The basic version can be converted at any time to high upper beam, high-segmented upper beam or high-segmented upper beam with Geißfuß by means of optional mounting kits

Note on abbreviations

• N = with low upper cheek
• H = with high upper cheek
• S = with segment rail
• G = with Geissfuß

• Industrial engine
• Easy to use safety switch according to IP 54
• Digital drilling depth and speed indicator integrated in the housing
• Separate emergency stop impact switch
• Precision Spindle bore
• Safety electronics in 24 V DC
• Guaranteed concentricity measured less than 0.02 mm in the drill quill
• Drill spindle with precision ball bearings
• High quality keyless chuck
• Digital depth gauge
• Precision machined, stable drill table with diagonal T-slots and circumferential cooling water channel
• V-belt cover with safety switch
• One piece cast aluminum die-cast quill lever with softgrip handles
• Large, height-adjustable protective screen with safety switch
• Heavy version of the entire machine

From D 23 Pro

• GATES quality strap

From D 23 Pro / 400 V

• Forward / reverse operation

D 33Pro

• Massive, large base plate with T-slots, strongly ribbed on the back

• Smooth and powerful industrial electric motor
• Separate emergency stop impact switch
• Stable casting column
• depth stop
• Precisely machined drill table with diagonal T-slots and circumferential cooling water channel
• Drilling table 360 ​​° rotatable
• V-belt cover with safety switch
• V-belt quick-clamping device
• Long, ergonomic cast aluminum sleeve lever cast in one piece (B 16H / B 24H with softgrip handles)
• Massive, large base plate with grooves, strongly ribbed on the back
• By swinging away the drilling table, base plate can be used as a work surface for particularly high workpieces
• Guaranteed concentricity measured better than 0.015 mm in the drill quill
• Drill spindle with precision ball bearings
• High-quality OPTIMUM keyless chuck in the standard scope of delivery
• Large, height-adjustable protective screen with safety switch

• machine light

• Forward / reverse operation

• Easy tool change through integrated expeller
• Quillons made of steel

• Digital depth gauge
• Digital speed display

• Powerful and quiet drive via LENZE gear motors with brake
• Compact, heavy and stress-free welded steel construction
• Sharp bending rail made of tool steel C50 at the clamping cheek
• Continuous, exchangeable bed support made of tool steel C50
• Continuous bending rail made of tool steel C50 at the bending beam
• Automatic pressure regulation of the clamping cheek via motor current pick-up
• Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
• Bending angle adjustment PT 1 via potentiometer on the machine front (right)
• Manual fine adjustment of bending beam with scale
• Manual crowning via pressure screws in the bending beam
• Foot remote control with emergency stop function
• All moving parts with low-maintenance bearings
• Electrical components from Schneider or Omron
• SH-models with high, segmented goat's foot tools
• Quality Made in Europe
• Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the rear of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Stopper with reading magnifying glass facilitates reading on the mm scale
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• Quality Made in Germany

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

• Saw head swivelby by 45° to the left and right
• Stable and robust construction
• Precise cut
• Turntable and saw shaft mounted on bearings
• Quick-release screw sticks with plastic-equipped aluminium clamping jaws
• Easy and hassle-free operation
• Saw head for chiverge cut by 45° to the left tiltable
• Two pneumatic vices
• Control handle with safety switch

• Segmented goat foot tool with quick-change system in the upper beam
• Segmented bending bar and bed support
• Backgauge up to 500mm
• Foot quick clamping for workpiece fixation
• Transport rollers with locking brake

• Segmented goat foot tool with quick-change system in the upper beam
• Segmented bending bar and bed support
• Backgauge up to 500mm
• Foot quick clamping for workpiece fixation
• Transport rollers with locking brake

• The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
• Different tool variants available E, S2, HS2 and HSG
• The powerful auxiliary cylinder facilitates bending
• Next passage between top and bottom cheek of up to 25 mm
• Self-lubricating plain bearings
• Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
• Adjustment of material thickness by means of knurled screw
• Adjustable stop for bending angle

• With segmented sharp-bending tools, continuous bending strip and continuous bed support

• With segmented sharpening tools, segmented bending strip and continuous bed support

• With segmented gooseneck tools, segmented bending bar and segmented bed support
• Segments have a hardness of HRC24-26

• Sheet thickness max.: Performance data based on material with tensile strength 400 N/mm²
• Bending capacity VA: factor 0.75
• Bending capacity aluminum: factor 1.2
• Hardened top tools are required to bend VA

• Two-column guided horizontal saw for sawing solid bars and bar profiles
• Mitsubishi FX 5 control system with simple operation via 4.3" touchscreen
• Cutting movement via hydraulic cylinder
• With BRP (cutting feed control) -> if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continues
• Automatic positioning after entering the desired angle
• Hydraulic clamping of the turntable enables precise angular cutting
• Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
• Infinitely variable cutting speed from 15 - 150 m/min
• Saw blade drive via bevel gearbox, asynchronous motor and frequency inverter
• For straight cuts, the material is clamped in front of and behind the cut using a two-part vice
• Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
• Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
• Front band guide moves automatically parallel to the movable vice jaw
• chip clearing brush driven via belt roller
• Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
• More powerful motor optionally available
• Saw blade guides with integrated cooling system

• Safe workpiece support thanks to solid and heavy-duty steel rollers
• Heavy three-legged version for highest load

• For supporting long and heavy workpieces
• Universally applicable for eg metal circular saws, band saws, woodworking machines, etc.
• Roller support infinitely height adjustable and clampable
• Safe workpiece support thanks to solid and heavy-duty steel rollers
• Heavy three-legged version for highest load

• User-friendly and energy-saving thanks to pneumatic drive
• Solid table with recessed scales and T-slots for precise adjustment of the pivoting stops
• Plexiglas finger guard for optimum view of the cutting edge

• Sturdy construction
• User-friendly and energy-saving thanks to pneumatic drive
• Solid table with recessed scales and T-slots for precise adjustment of the pivoting stops
• Plexiglas finger guard for optimum view of the cutting edge
• Operation via foot pedal

• Powerful motor and vibration-free operation for the best sanding results
• Continuous face sanding surface thanks to removable attachments enables sanding of even long workpieces
• With two belt speeds
• Quick-clamping system enables fast sanding belt changes
• One extraction nozzle each directly on the spark box and on the rear belt roller
• Can be used with and without suction
• Easy adjustment of the belt run via adjusting screw on the front contact roller
• Automatic retensioning of the sanding belt thanks to spring-loaded belt tensioning system
• Infinitely tiltable sanding unit
• Fold-away protective screen

• Heavy, durable industrial design with maintenance-free motor
• Long service life and smooth running due to balanced rotor with quality ball bearings
• Li>For deburring tubes, profiles and flat workpieces made of metal
• Surface for safety glasses
• Secure and clean working with the optional GU 5 substructure with cyclone dust extraction

• Two-column guided band saw for sawing solid bar material and bar profilesMitsubishi
• FX 5 control system with simple operation via 4.3" touchscreenCutting movement
• via hydraulic cylindersWith
• BRP (cutting feed control): if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continuesRobust
• machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performanceInfinitely variable
• cutting speed from 15 - 150 m/minSaw blade drive
• via bevel gearbox, Asynchronous motor and frequency converterClamping
• of the material in front of and behind the cut by means of a two-part vicePressure adjustment
• of the hydraulic vice clamping via control valve with pressure gaugeSaw blade inclination
• of 7° and hydraulic saw blade tensioning increase the service life of the saw
• bladeFront
• blade
guide moves automatically parallel to the moving
• saw blade
• Band guide moves automatically parallel to the moving vice jawElectrically
• driven chip clearing brushEmulsion cooling
• with liquid distribution into the saw band guides and directly into the cutting channelMore powerful
• motor optionally availableSaw band guides
• with integrated cooling system/ul>

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Extremely stable construction, entire machine body made of steel
• User-friendly operating concept
• Speed infinitely variable via inverter - Greater ease of operation and no need to replace wearing parts such as V-belts
• Combined micro-spray and blow-off device, for blowing off chips and lubricating the saw blade
• Tiltable working table made of cast iron
• Workplace lighting as standard
• Equipped with motor brake
• Belt tension and speed indicator
• Integrated band welding unit with annealing, cutting and grinding device
• Height adjustment of saw band guide by hand wheel
• VMBS I E models with electric table feed
