• Material roller conveyor with stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 450 mm
• Length measuring device with handwheel adjustment
• Roller and measuring track with digital LED dimension display in mm, electrical connection 230 V, 50 Hz with power supply unit
• Measuring stop adjustable by handwheel from the workplace, with pneumatic brake for measuring fixation
• Sturdy material stop trolley, 12 ball bearings, movable on large dimensioned guide profile. The stop arm is adjustable and hinged.
• For roller conveyors with a length of more than 5 m, a cable drag chain is used
• Mounting side as desired right or left

Equipment details

position indicator

• 5-digit LED measurement display for constant, millimeter-accurate control of the current position of the stop car
• Position indicator with hollow shaft encoder mounted directly on the drive shaft
• Measuring accuracy / m: ± 0.5 mm

stop arm

• 900 mm long stop arm
• Stop plate adjustable to zero point and manually hinged backwards
• Multiple ball bearings, thus free of play
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

For stable mounting of roller conveyors of the series MRB LC to Metallkraft circular saws. The adapters are specially designed for mounting to the right or left of the saws. Please indicate the machine type of your saw when ordering.
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Powerful and quiet drive via LENZE gear motors with brake
• Compact, heavy and stress-free welded steel construction
• Sharp bending rail made of tool steel C50 at the clamping cheek
• Continuous, exchangeable bed support made of tool steel C50
• Continuous bending rail made of tool steel C50 at the bending beam
• Automatic pressure regulation of the clamping cheek via motor current pick-up
• Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
• Bending angle adjustment PT 1 via potentiometer on the machine front (right)
• Manual fine adjustment of bending beam with scale
• Manual crowning via pressure screws in the bending beam
• Foot remote control with emergency stop function
• All moving parts with low-maintenance bearings
• Electrical components from Schneider or Omron
• SH-models with high, segmented goat's foot tools
• Quality Made in Europe
• Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Feed roller conveyor without length stop and without measuring system
• Roller and guideway system on which lighter wood, metal or plastic profiles can be precisely sawed, drilled or milled
• Substructure made of solid 3 mm steel profiles, painted and with adjustable feet
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• standard design
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Smooth and powerful brushless drive
• Separate emergency stop impact switch
• Large, height-adjustable protective screen with safety switch for the utmost protection of the user
• Long, ergonomic aluminum die-cast quill lever
  One piece cast (B 24HV with softgrip handles)
• Measurement scale for drilling depth
• Belt cover with safety switch
• Forward / reverse operation
• Machine light

From OPTIdrill B 28HV

• Quillons made of steel
• Coolant system
• Chip filter according to the Machinery Directive
• Easy tool change through integrated expeller

OPTIdrill B 34HV

• Quill stroke 160 mm
• Tapping function
• Digital depth gauge

Special feature of the OPTIdrill B 34 HV

• Operating mode "auto"
  • Engine starts automatically after lever movement
  • Stops again in the starting position
  • Pushbutton Start and Stop does not have to be pressed during repetitive drilling tasks
• Operating mode "tapping"
  • Engine is activated by moving the handle down
  • The direction of rotation is changed by limit switches on the adjustable drilling depth stop

Equipmentdetails
Powerful brushless drive

• Especially quiet running
• High performance
• Approximately constant torque over the entire speed range

Belt drive

• Best power transmission through aluminum pulleys in conjunction with toothed GATES quality V-belt
• Smooth running thanks to ground multi-tooth driver

Digital speed display

• integrated in the housing

Speed control

• by means of potentiometer

Concentricity

• Guaranteed ; 0.015 mm measured in the quill

Spindle

• Precision ball bearings
• High quality OPTIMUM keyless chuck as standard

V-belt tensioning device
Machine light

• Integrated in the drill head
• Halogen lamp

Drilling

• Precisely worked
• Diagonal T-slots
• 360° rotatable
• Circulating cooling water channel

baseplate

• Solid
• Large dimensions
• Heavily ribbed on the reverse side

cast column

• Thick-walled
• High power and stability

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Maintenance-free motor for reliable operation
• Robust cast iron housing
• Balanced rotor with high-quality ball bearings for a long service life and smooth running
• LED lighting above the grinding wheels for optimum visibility in the work area
• Stable and flexibly adjustable workpiece supports for precise work

• Maintenance-free motor for reliable operation
• Robust cast iron housing
• Balanced rotor with high-quality ball bearings for a long service life and smooth running
• Integrated spark guard on the grinding wheels reduces flying sparks
• Protective discs made of shatterproof material for additional safety
• Non-slip and vibration-damping rubber feet for a stable stand
• Standard equipment with coarse and fine sanding discs (grit 36 and 80)
• LED lighting above the sanding discs for optimum visibility in the work area
• Stable and flexibly adjustable workpiece supports for precise work

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Very heavy and robust welded construction
• Dynamic drive of the bending beam by means of two frequency-controlled motors with gears
• Over cheek clamping via trapezoidal thread
• High-quality Lenze motors
• Continuous sharp bending rail
• Tools suitable for bending stainless steel
• Bending angle adjustment via touchscreen NC control system
• Sheet thickness adjustment manually at the bending beam
• Manual crowning device of the bending beam
• Operation via double foot pedal with emergency stop function
• Clean motor-driven machine without hydraulics
• SH models with segmented, high goat foot tools
• DUO models with continuous sharp-bending rail and high, segmented goat foot tools

Quality made in Germany
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

Available on request

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

Quality Made in Europe

Note on technical data
For bending stainless steel, optional hardening of the tools is required
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the back of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• With length measuring device and digital dimensioning system
• Roller and measuring track with battery-operated LCD display and magnetic tape measuring system
• Quality Made in Germany

Please specify when ordering mounting side and height!

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Best power transmission thanks to aluminum pulleys in conjunction with toothed GATES quality V-belt
• Smooth running thanks to ground multi-tooth driver
• Guaranteed concentricity of less than 0.015 mm measured in the drill sleeve
• High-quality OPTIMUM quick-action drill chuck as standard
• Drilling depth stop
• V-belt tensioning device
• Right/left rotation

• Powerful brushless drive with particularly smooth running and high performance with almost constant torque over the entire speed range
• Best power transmission thanks to aluminum pulleys in conjunction with toothed GATES quality V-belt
• Very smooth running thanks to ground multi-tooth driver
• Guaranteed concentricity of less than 0.015 mm measured in the drill sleeve
• Separate emergency stop switch
• High-quality OPTIMUM quick-action drill chuck as standard
• Large, height-adjustable protective screen with safety switch for maximum user protection
• Drilling depth stop
• V-belt cover with safety switch
• V-belt tensioning device
• Right/left rotation
• Machine light integrated in the drill head
• Precisely machined, stable drill table with 2 diagonal T-slots, 360° rotatable and all-round cooling water channel
• Thick-walled cast column for high force absorption and stability
• Solid base plate, large dimensions and heavily ribbed on the back

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• High quality steel knives with a hardness of HRC52-HRC58
• Equipped with two control handles
• Front bearing surface with scale
• Up to 500 mm adjustable backgauge

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Linear guides on both columns ensure a perfect cutting result
• Robust three-phase motor with overload protection
• The vice is equipped with a long-stroke cylinder to compensate for larger cross-section differences
• Belt guide with adjustable carbide plates
• Hydraulic regulation of the vice pressure
• Operation on modern and powerful Siemens HMI multi-touch panel

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

Available on request

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

Quality Made in Europe

Note on technical data
For bending stainless steel, optional hardening of the tools is required
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

Available on request

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Very heavy and robust welded construction
• Dynamic drive of the bending beam by means of two frequency-controlled motors with gears
• Over cheek clamping via trapezoidal thread
• High-quality Lenze motors
• Continuous sharp bending rail
• Tools suitable for bending stainless steel
• Bending angle adjustment via touchscreen NC control system
• Sheet thickness adjustment manually at the bending beam
• Manual crowning device of the bending beam
• Operation via double foot pedal with emergency stop function
• Clean motor-driven machine without hydraulics
• SH models with segmented, high goat foot tools
• DUO models with continuous sharp-bending rail and high, segmented goat foot tools

Quality made in Germany
Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• heavy and stable cast iron construction
• asymmetric 3-roller system for easy pre-bending
• swing-out top roller
• Roller drive via hand crank
• suitable for bending wires with the diameters 3, 5 and 8 mm
• quick clamping of the sheet metal by means of a lever

• Note: Please specify when ordering material to be processed!

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the back of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• With length measuring device and digital dimensioning system
• Roller and measuring track with battery-operated LCD display and magnetic tape measuring system
• Quality Made in Germany

Please specify when ordering mounting side and height!

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Heavy, one-piece, heavily ribbed and wide machine bed
• Induction-hardened and ground guideways
• Solid headstock with high-precision, tapered roller bearing main spindle impresses with outstanding stability under load
• Very smooth running at maximum spindle speed
• All gears are large, hardened and ground
• Joystick control for X and Z feed directly on the support
• Manually shifted 4-step countershaft gearbox, high-quality frequency control technology
• Rapid traverse for X- and Z-axis enables fast positioning of the support and reduces non-productive time
• Adjustable overload clutch in the lock box protects the feed mechanism from damage and failure
• The table can be tilted for conical sanding processes - the scale enables precise adjustment to the desired position
• The spindle head tilts from 0 to 90° for conical sanding operations
• The longitudinal guide of the table and the cross guide of the sanding spindle material are each equipped with V and flat guides
• The sanding spindle has bearings on both sides and adjustable flat grids
• Swivel spindle shaft (up to 180°) for internal sanding work

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• For use in the metalworking industry for grinding, structuring and polishing tasks, especially in the stainless steel sector
• 225 mm balanced belt rollers ensure optimum and low-vibration drive
• Infinitely variable belt speed of 4.5 - 27 m/s thanks to frequency shaper
• With electric table height adjustment
• With split table that can be opened, drawer sanding unit and integrated work table lighting
• Smooth-running sanding table even under load
• Easy adjustment of the sanding belt
• Profile roller sanding pad, resulting in less tarnishing during the sanding process
• Right/left rotation as standard

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Modern design in stable steel construction
• High design flexibility thanks to segmented edging rail with removable segment pieces
• Operation via two laterally arranged, large, adjustable and easy-to-operate lever arms
• Scissor table with inserted measuring tapes and right-angled stop on both sides
• Easily adjustable top, rear and bottom roller
• Long contact surface
• Adjustable backgauge and extendable front material support for the safe placement of even large format sheets

Turn around

• Adjustment screws for the material thickness with scaling
• Ground bending rolls with wire-laying grooves on the lower and front rolls

folding

• High quality folding cheeks
• Feather-down device
• Segment split edge rail 40/50/65/100/180/255/380 mm for cassette bending

To cut

• Clean and burr-free cutting by upper and lower blades made of quality steel

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de
