Acute bending rail made of tool steel C50 at the clamping beam
Continuous, replaceable bed support made of tool steel C50
Continuous bending rail made of tool steel C50 at the bending beam
Clamping beam pressure controlled automatically via motor current absorption
Clamping beam driven via generously dimensioned trapezoidal thread spindles
Bending angle adjustment PT 1 via potentiometer on the machine’s front side (right)
Manual granular adjustment of the bending beam with help of a scale
Manual crowning via pressure screws in the bending beam
Remote foot switch with emergency stop function
All moving parts with low-maintenance bearings
Electrical components by Schneider or Omron
SH-models with high, segmented crowbar tools
Stock equipment as standard with: hardened tools, control PT 1, back gauge 6-760mm with hand wheel, measuring device and stop fingers, quick clamping for top tool
Quality Made in Europe
Available on request: Models in DUO design featuring full-width acute bending rail and segmented crowbar tools
In series with manual adjustment of the bending angle
Especially low-maintenance
The workpiece is clamped by a motorized mechanism
S-models with segmented upper tools
SH-models with high, segmented casting foot tools
Available on request
Other models
Standard tools hardened
Hardened sharp bending bar and bending bar
Segmented tools and hardened bending bar
Segmented casting foot tools and bending bar hardened
Quality Made in Europe
Note on technical data For bending stainless steel, optional hardening of the tools is required Manufacturer Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany info@stuermer-maschinen.de
Two-column guided band saw for sawing solid bars and bar profiles
Siemens S7-1500 control system with a wide range of functions and operation via a large 7" touch display
With 2000 mm material feed as standard
Cutting movement via rotating spindle and servo motor
With ARP (automatic cutting feed control) -> Automatic saw blade feed depending on the material resistance. Feed speed is constantly adapted to the current cutting load. ARP enables shorter work processes and a longer service life for the saw bands.
Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
Infinitely variable cutting speed from 15 - 150 m/min
Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
Material is clamped in front of and behind the cut using a two-part vice
Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
front band guide moves automatically parallel to the movable vice jaw
Electrically driven chip clearing brush
Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
With automatic material feed: frequency-controlled feed via circulating spindle and servomotor; optical sensor detects when no more material is inserted and pauses the material feed
Powerful and quiet drive via LENZE gear motors with brake
Compact, heavy and stress-free welded steel construction
Sharp bending rail made of tool steel C50 at the clamping cheek
Continuous, exchangeable bed support made of tool steel C50
Continuous bending rail made of tool steel C50 at the bending beam
Automatic pressure regulation of the clamping cheek via motor current pick-up
Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
Bending angle adjustment PT 1 via potentiometer on the machine front (right)
Manual fine adjustment of bending beam with scale
Manual crowning via pressure screws in the bending beam
Foot remote control with emergency stop function
All moving parts with low-maintenance bearings
Electrical components from Schneider or Omron
SH-models with high, segmented goat's foot tools
Quality Made in Europe
Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened
Control with 49 programs with each 99 possible individual steps
Two cutting speeds
Machine head guided vertically, with dovetail guide and adjustable wedge strip
Machine head can be swiveled 45° to the left and 60° to the right, with locking at 45°, 0°, -45°, -60°
Stable and robust construction
Simple and intuitive operation
Adjustable depth stop for the vertical stroke of the saw head
Reduction gear, silent in oil bath running
Coolant pump with coolant filter
Coolant distribution for better lubrication
Transversely movable hydraulic quick-action vice with anti-jaw device
Chip breaker T6 for blade cleaning
Electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector switch, undervoltage release and overload protection
Quality Made in Europe
Mode of operation automat
Material feed
Closing the vice and activating the motor
Activation of the coolant pump and lowering of the saw head for cutting
Return of the feed carriage to the specified dimension
only available when ordering a roller conveyor ex works Manufacturer Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany info@stuermer-maschinen.de
