• Ideal for roofers and tinsmiths in assembly use, e.g. for making bay and valley flashings or chimney claddings
• Equipped with transport rollers with locking brake

• Versatile and mobile
• Ideal for roofers and tinsmiths in installation work, e.g. for making bay and valley flashings or chimney cladding
• Simple design enables precise work
• Equipped with transport rollers with parking brake
• Safe, material-friendly operation
• Secure fixing of the workpiece via lever
• Swivel bending process via bow handle

• For mechanical workshops and repair shops
• For pressing in and out of bearings, thorns, bushings, spindles, pins
• Stable construction
• Body made of high quality gray cast iron
• Variable adjustable lever rod
• Quadruple positionable base plate
• For mounting on a workbench

• Increased stability due to improved design of the machine base, cylinder adjustment via handle and hand wheel, manometer on the machine side
• Suitable for assembly and straightening work as well as for workpiece checks or the pressing and pressing of bearings and other components
• Ideal for technical workshops, repair shops and technical training facilities
• With two piston speeds and pressure regulation by throttle screw
• Pressure gauge for pressure gauge
• Heavy machine frame welded from steel profiles to absorb the resulting compressive force of the cylinder
• The hydraulics work extremely precisely in both electrical and manual mode
• Adjustment of the cylinder via rack to handwheel
• Heavy and robust welded construction
• More extensive accessories
• Quality made in Europe

• Heavy, robust welded construction
• Splitter-guided upper beam with adjustable flat guides
• Manual cutting gap adjustment at the front of the machine
• LED cutting line illumination and elongated holes in the top cover for an optimal view of the cutting edge and for cutting on tear-off
• Solid 90° side stop with 1000 mm length, T-slot, tilting cam and scale
• Two solid sheet support arms with T-slots and tilting cams
• Motorized, NC-controlled backgauge with 750 mm travel range
• Backgauge drive with frequency converter, motor with brake and recirculating ball screws
• High-quality, rotatable knives suitable for cutting stainless steel
• Heavy hold-down beam with gentle rubber inserts
• Rear area protected by light curtain
• Operation via mobile foot pedal console with emergency stop

• Precisely processed
• High concentricity due to tapered roller bearings ≤ 0.015 mm measured in the sleeve
• Motor with two-stage gear ratio for powerful transmission of motor power
• Powerful DC motor with permanent current monitoring
• Safety electrics in 24 volt version
• Control electronics with integrated relay control
• Massive and generously dimensioned cross table, precisely surface-machined with T-slots and adjustable gibs
• Adjustable end stops
• Stable dovetail guide with adjustable gibs
• Fine feed
• Emergency stop switch
• Drilling/milling head can be tilted by ±60
• Right/left rotation
• Machine lamp
• Hole for easy oiling of the trapezoidal spindle
• Double-row angular contact ball bearings in the axes, adjustable without play
• Adjustable and readjustable feed spindle play
• Height-adjustable protective screen with microswitch to prevent flying chips and parts, for maximum user protection
• X-, Y- and Z-axis with prepared groove for subsequent installation of magnetic tapes
• Bellows as guide protection
• With digital position indicator DRO 5

• Control with 49 programs with each 99 possible individual steps
• Two cutting speeds
• Machine head guided vertically, with dovetail guide and adjustable wedge strip
• Machine head can be swiveled 45° to the left and 45° to the right, with locking at 45°, 0°, -45°
• Stable and robust construction
• Simple and intuitive operation
• Adjustable depth stop for the vertical stroke of the saw head
• Reduction gear, silent in oil bath running
• Coolant pump with coolant filter
• Coolant distribution for better lubrication
• Transversely movable hydraulic quick-action vice with anti-jaw device
• Chip breaker T6 for blade cleaning
• Electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector switch, undervoltage release and overload protection
• Quality Made in Europe

• Material feed
• Closing the vice and activating the motor
• Activation of the coolant pump and lowering of the saw head for cutting
• Return of the feed carriage to the specified dimension
• Return of the saw head to starting position
• Opening the vise
• Repeat cycle

• Frequency converter
• User-friendly membrane keyboard
• Digital speed display
• Tapping function
• Smooth running thanks to ground multi-tooth driver
• High concentricity due to hardened and ground main spindle
• Low-maintenance gearbox with grease lubrication
• Gearbox with PA6 gears
• Large speed range
• User-friendly membrane keyboard
• Heavy, solid cast construction
• Large, height-adjustable protective screen with safety switch for the utmost protection of the user
• Drilling depth stop adjustable with millimeter scale
• Forward / reverse operation
• Machine light integrated in the drill head
• Integrated expeller for easy tool change
• Precision machined drilling table with diagonal T-slots with all-round cooling water channel
• Thick-walled cast-iron column for high power absorption and stability
• Massive base plate, large dimensions and strongly ribbed on the back

• Automatic quill feed
• Coolant device and chip filter according to Machinery Directive

• Sliding upper beam with adjustable flat guides
• Manual backgauge with 550 mm travel range
• Solid 90° side fence with 1000 mm length, T-slot, tilting cam and scale
• LED cutting line lighting and slotted holes in the top cover for an optimum view of the cutting edge for cutting on tear
• High-quality, rotatable knives suitable for cutting stainless steel Heavy-duty hold-down beam with material-friendly polyurethane inserts suitable for cutting stainless steel
• Heavy-duty hold-down bar with material-friendly polyurethane inserts
• Rear area protected by light barrier
• Operation via mobile foot pedal console with emergency stop

• Roller and guideway system on which lighter wood, metal or plastic profiles can be precisely sawed, drilled or milled
• Substructure made of solid 3 mm steel profiles, painted and with adjustable feet
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• With length stop, magnetic tape measuring system with digital display, measuring accuracy +/- 0.2 mm per meter
• Stop car is 4-roller bearings, thus manually easily displaced
• Adjustable stop arm and can be folded away to the rear
• The maximum measuring length is the length of the web minus the stop length of 250 mm
• Quality Made in Germany

• For all repair and assembly work, eg: straightening axles, girders, shafts, etc .; Pressing and pressing bearings, bolts and bushings; Pressing and squeezing work; Load tests and welding sample tests; and much more.
• Stable welded construction
• Robust frame with perforation for the adjustment of the work table
• Reliable, particularly precise hydraulic from European production
• Pressure build-up by hand or foot operation of the pump lever
• By foot pump both hands free for fixation of the workpiece
• Pressing pressure readable via manometer
• With automatic return of the piston
• With safety valve to protect against overload
• Quality Made in Europe

• For processing flat material, pressing in bearings, bolts and the like, be sure to use the optional perforated plates.

• Foot operated
• Heavy, compact welded construction
• Powerful drive by Lenzemotors
• With continuous sharp bending bar
• In series with manual adjustment of the bending angle
• Especially low-maintenance
• The workpiece is clamped by a motorized mechanism
• S-models with segmented upper tools
• SH-models with high, segmented casting foot tools

• Other models
• Standard tools hardened
• Hardened sharp bending bar and bending bar
• Segmented tools and hardened bending bar
• Segmented casting foot tools and bending bar hardened

• Simple operation
• Heavy, compact welded construction
• Particularly low maintenance
• For easy bending with precise adjustment of the bending angle using a stop with scale
• Sheet thickness adjustable via bending beam
• Tools for VA on request: sharp bending rail and bending bar made of Toolox 33, segmented tools and bending bar made of Toolox 33 and segmented goat foot tools made of Toolox 33
• Quality Made in Europe

• Low noise running
• Stable cast iron design
• High cutting accuracy due to vibration-free running
• Lowering of saw bow infinitely adjustable via hydraulic cylinder with throttle valve
• Microswitch for automatic limit switch
• Coolant device
• High-quality bi-metal saw band as standard equipment
• Adjustable material stop for serial work
• Robust machine base
• Ball bearing saw band guide
• Well readable scale for angle adjustment
• Overload protection

• Suitable for cutting steel and non-ferrous metals
• Heavy, stress-free welded steel construction
• High quality knife
• Sheet metal support arms for large workpieces
• Cut line illumination and long holes in the upper cover plate for an optimal view of the cutting edge for cutting on scratches
• Manual back gauge 630 mm with millimeter precision adjustment
• Photocell for the backgauge area
• The foot control leaves both hands free for the material supply

• Increased stability due to improved design of the machine base, cylinder adjustment via handle and hand wheel, manometer on the machine side
• Suitable for assembly and straightening work as well as for workpiece checks or the pressing and pressing of bearings and other components
• Ideal for technical workshops, repair shops and technical training facilities
• With two piston speeds and pressure regulation by throttle screw
• Pressure gauge for pressure gauge
• Heavy machine frame welded from steel profiles to absorb the resulting compressive force of the cylinder
• The hydraulics work extremely precisely in both electrical and manual mode
• Adjustment of the cylinder via rack to handwheel
• Heavy and robust welded construction
• More extensive accessories
• Quality made in Europe

• The clamping of the workpiece is done by hand clamping
• Easy fixing of the set bending angle, which ensures a high repeatability
• Self-lubricating plain bearings
• The basic version can be converted at any time to high upper beam, high-segmented upper beam or high-segmented upper beam with Geißfuß by means of optional mounting kits

Note on abbreviations

• N = with low upper cheek
• H = with high upper cheek
• S = with segment rail
• G = with Geissfuß

• Industrial motor
• Quiet running spindle thanks to new spindle design
• Machine operation with safety electrics in 24 V DC voltage
• Guaranteed concentricity ≤ 0.02 mm measured in the drilling spindle
• Right/left rotation
• Precision spindle bore
• Control panel with user-friendly, dirt and water resistant membrane keypad
• Speed display
• Separate emergency stop impact switch
• Thread cutting function
• Precisely machined, stable drilling table with diagonally running T-slots with circumferential cooling water channel, laterally tiltable by ±45° and 360° rotatable
• Digital depth gauge
• LED machine light integrated in drill head
• V-belt cover with safety switch
• Thick-walled steel column for high force absorption and stability
• Solid, large-dimensioned base plate with T-slots
• Heavy-duty design of the entire machine

• Handy and flexible pipe grinder for locksmiths, metalworking and railing construction
• Designed for grinding and polishing pipe constructions
• Especially suitable for sanding, satin finishing and mirror polishing of already mounted railings
• Ideal for working in confined spaces, as the handle can be turned through 180 °
• Heavy duty motor with soft start and overload protection
• With constant electronics for consistent belt speed even under load
• With stepless adjustment of the belt speed for an optimal adaptation to the different applications
• Speed ​​can be adjusted comfortably via the thumb wheel on the handle
• Simple, tool-free grinding belt change
• 360 ° circumferential grinding takes only two working steps
• High-quality 270 ° light metal arm with 2 pulleys
• Handle can be screwed in at three different positions for optimal handling

• Material roller conveyor with stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 450 mm
• Length measuring device with handwheel adjustment
• Roller and measuring track with digital LED dimension display in mm, electrical connection 230 V, 50 Hz with power supply unit
• Measuring stop adjustable by handwheel from the workplace, with pneumatic brake for measuring fixation
• Sturdy material stop trolley, 12 ball bearings, movable on large dimensioned guide profile. The stop arm is adjustable and hinged.
• For roller conveyors with a length of more than 5 m, a cable drag chain is used
• Mounting side as desired right or left

Equipment details

position indicator

• 5-digit LED measurement display for constant, millimeter-accurate control of the current position of the stop car
• Position indicator with hollow shaft encoder mounted directly on the drive shaft
• Measuring accuracy / m: ± 0.5 mm

stop arm

• 900 mm long stop arm
• Stop plate adjustable to zero point and manually hinged backwards
• Multiple ball bearings, thus free of play
• Quality Made in Germany

• Sturdy and robust welded construction
• Due to the foot control both hands remain free for the material supply
• High quality cutting blades
• Angle adjustable side stop with millimeter scale
• Easy adjustment of the knife bar
• Highest possible safety through hold-down, which protects the fingers at the same time.
• Up to 500 mm adjustable backgauge
