• Punching station, flat steel shears, angle steel shears, sectional steel shears, available with notching station starting from HPS 45S
• DS series with two working cylinders and two foot pedals for simultaneous use with punching station and sectional steel shears
• Stepless adjustment of the stroke
• Larger reach for punching station with 620 mm optional, available from HPS 55DS
• Heavy and rigid welded construction
• Standard with notching knife starting from HPS 45S
• With powerful 400 Volt motor
• V-notching knife, oversized punching device and larger throat depth for punching station available on request
• Two-stage foot pedal for inching operation
• Stamps and dies No. 1, No. 2, No. 3, No. 30, No. 45, No. 60 can be used with the standard delivery scope of the machine. Use of punch and die No. 4 and No. 80 optional (except HPS 40S)

Advantages of punching over drilling:

• High time savings - cycle times
• No chips
• No cooling

Note:

• All hydraulic sectional shears are delivered with oil

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the rear of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Stopper with reading magnifying glass facilitates reading on the mm scale
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• Quality Made in Germany

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• Feed / discharge roller conveyor
• Roller conveyor without scale and stop with side guide
• Quality Made in Germany

• Machine head guided vertically, with dovetail guide and adjustable wedge bar
• Swivelling 45° to the left and 60° to the right, with locking at -45°, 0°, -45°, 60°
• Two cutting speeds
• Adjustable depth stop for the vertical stroke of the saw head
• Cross-movable vice with anti-burr device
• Stable and robust construction
• Easy and hassle-free operation
• Reduction gearbox quietly running in the oil bath
• Coolant pump with coolant filter
• Coolant jet distribution, for better lubrication of the saw blade
• Chip crusher for leaf cleaning
• Electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector switch and overload protection
• Control handle with safety switch

• For steel
• two cutting speeds
• Reduction gear, silent in oil bath running
• automatic membrane coolant pump with standard coolant filter
• movable protection device ensures optimum safety when cutting
• Control handle with safety switch
• electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector and overload protection
• Machine head rotatable by 45 ° on both sides
• 45 ° swiveling quick-action vice on both sides
• Quick-action vise with double clamping device guarantees a precise and low-profile cut
• Quality Made in Europe

• 45 ° swiveling quick-action vice on both sides

• The workpiece clamping by means of foot pedal thereby both hands remain free for the material supply
• Different tool variants available E, S2, HS2 and HSG
• The powerful auxiliary cylinder facilitates bending
• Next passage between top and bottom cheek of up to 25 mm
• Self-lubricating plain bearings
• Clamping pressure of the upper beam via non-slip thumbscrews easily adjustable
• Adjustment of material thickness by means of knurled screw
• Adjustable stop for bending angle

• With segmented sharp-bending tools, continuous bending strip and continuous bed support

• With segmented sharpening tools, segmented bending strip and continuous bed support

• With segmented gooseneck tools, segmented bending bar and segmented bed support
• Segments have a hardness of HRC24-26

• Sheet thickness max.: Performance data based on material with tensile strength 400 N/mm²
• Bending capacity VA: factor 0.75
• Bending capacity aluminum: factor 1.2
• Hardened top tools are required to bend VA

• Suitable for cutting metals, cardboard and other materials.
• Extremely stable and robust construction made of cast iron
• Bronze bearing blades made of cold work steel K2379
• Hardened, resharpenable and adjustable knives

• Suitable for cutting metals, cardboard and other materials
• Extremely stable and robust construction made of cast iron
• Bronze-plated knives made of cold-work steel K2379
• Hardened, regrindable and adjustable knives

• Heavy industrial combination grinding machine absorbs the low vibrations due to its high weight
• Also suitable for very strong pushing forces on the grinding wheel and brush
• Maintenance-free, durable induction motor with smooth running
• Housing made of cast iron
• Stable, adjustable workpiece support
• Grinding wheel and brush not included in the standard delivery

Multipurpose wire brush

• High strength steel wire available in accessories in various thicknesses

Brush Housing

• Swiveling
• Extraction nozzle for connecting a suction device

• Material roller conveyor with stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 450 mm
• Length measuring device with handwheel adjustment
• Roller and measuring track with digital LED dimension display in mm, electrical connection 230 V, 50 Hz with power supply unit
• Measuring stop adjustable by handwheel from the workplace, with pneumatic brake for measuring fixation
• Sturdy material stop trolley, 12 ball bearings, movable on large dimensioned guide profile. The stop arm is adjustable and hinged.
• For roller conveyors with a length of more than 5 m, a cable drag chain is used
• Mounting side as desired right or left

Equipment details

position indicator

• 5-digit LED measurement display for constant, millimeter-accurate control of the current position of the stop car
• Position indicator with hollow shaft encoder mounted directly on the drive shaft
• Measuring accuracy / m: ± 0.5 mm

stop arm

• 900 mm long stop arm
• Stop plate adjustable to zero point and manually hinged backwards
• Multiple ball bearings, thus free of play
• Quality Made in Germany

• Powerful motors with vibration-free running to achieve the best sanding results
• Working height can be adjusted thanks to the infinitely variable inclination of the sanding unit
• Continuous flat sanding surface enables sanding of even long workpieces
• Suction nozzle on the rear belt roller
• Sanding belt can be changed in seconds thanks to quick-release system

• Powerful motors with vibration-free running to achieve the best sanding results
• Working height can be adjusted by infinitely variable inclination of the sanding unit
• Angle-adjustable workpiece support
• Continuous flat sanding surface enables sanding even of long workpieces
• One extraction nozzle on the spark box and one on the rear belt roller
• Protective screen can be folded away
• Sanding belt can be changed in seconds thanks to quick-release system
• Easy adjustment of the belt run via adjusting screw on the front contact roller
• Motor with brake and circuit breaker

• Stepless adjustment of belt speed
• No need to set the upper end point with the cut-off button
• Efficient coolant application on the saw band guides
• Monitoring of the saw blade run by BRP system
• Monitoring the saw blade tension
• Longer service life of saw blade due to saw arm inclination of 25 °

• For sawing pipes and solid materials made of steel, stainless steel, tool steel, non-ferrous metals and plastic
• Mitre adjustment from -45° to +60°, user-friendly adjustment from the front for better handling, especially with attached roller conveyor
• Bearing-mounted turntable
• Infinitely variable adjustment of the belt speed
• Robust belt guides with adjustable carbide plates for a precise cut
• Longer service life of the saw blade thanks to 25° saw arm inclination
• Saw blade guides with integrated cooling system
• BRP saw blade monitoring stops the feed of the saw frame if the saw blade motor is overloaded by chips in the cutting channel; once the chips have been removed by the running saw blade, the feed continues automatically
• Electromechanical monitoring of the saw blade tension, a microswitch switches the machine off in the event of deviations
• Chip clearing brush for optimum cleaning and maintenance of the saw blade
• Hydraulic clamping vice
• Saw frame can be lowered hydraulically
• With swivel-mounted control panel
• Cut sensing function with integrated button

• Automatic workpiece clamping after the start of the cutting cycle
• Execution of the saw cut at the selected belt speed
• Automatic stop of the lowering movement and the saw blade in the lower end position
• Automatic return of the saw arm to its upper end position
• Vice opens automatically
• Operator only has to move the material

• For steel
• two cutting speeds
• Reduction gear, silent in oil bath running
• automatic membrane coolant pump with standard coolant filter
• movable protection device ensures optimum safety when cutting
• Control handle with safety switch
• electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector and overload protection
• Machine head rotatable by 45 ° on both sides
• 45 ° swiveling quick-action vice on both sides
• Quick-action vise with double clamping device guarantees a precise and low-profile cut
• Quality Made in Europe

• 45 ° swiveling quick-action vice on both sides

• Stable and robust construction
• Two cutting speeds as standard
• Pivoting machine head at 45 ° to the left and 90 ° to the right
• Reduction gear running in oil bath
• With membrane coolant pump with filter
• Double vice with counter vise and Antigratspannbacken guarantees a precise and burr-free cut
• Vise longitudinally displaceable and thus suitable for Längsschnitteund slitting
• Quick-action vise swivels 45 ° to the left and 45 ° to the right
• Movable guard ensures optimum safety when cutting
• Electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector switch and overload protection
• Control handle with safety switch
• Quality Made in Europe

• Activation of the engine and closing of the vice
• Lowering the saw head to cut
• Return the saw head to home position and stop the motor
• Opening the vise

• Semi-motor version - manual operation of the upper cheek, bending process motorised
• Designed for professional use
• With foot operation
• heavy, compact weldment
• With continuous sharp bending rail
• Standard with manual adjustment of the bending angle by means of nonius ring
• Particularly low-maintenance
• S-models with segmented top tools
• SH models with high, segmented goat foot tools
• Hardening of standard tools available on request: sharp bending rail and bending strip hardened, segmented tools and bending strip hardened, segmented goat foot tools and bending strip hardened
• Further swivel bending machines available on request

• For steel
• two cutting speeds
• Reduction gear, silent in oil bath running
• automatic membrane coolant pump with standard coolant filter
• movable protection device ensures optimum safety when cutting
• Control handle with safety switch
• electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector and overload protection
• Machine head rotatable by 45 ° on both sides
• 45 ° swiveling quick-action vice on both sides
• Quick-action vise with double clamping device guarantees a precise and low-profile cut
• Quality Made in Europe

• 45 ° swiveling quick-action vice on both sides

• Powerful and quiet drive via LENZE gear motors with brake
• Compact, heavy and stress-free welded steel construction
• Sharp bending rail made of tool steel C50 at the clamping cheek
• Continuous, exchangeable bed support made of tool steel C50
• Continuous bending rail made of tool steel C50 at the bending beam
• Automatic pressure regulation of the clamping cheek via motor current pick-up
• Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
• Bending angle adjustment PT 1 via potentiometer on the machine front (right)
• Manual fine adjustment of bending beam with scale
• Manual crowning via pressure screws in the bending beam
• Foot remote control with emergency stop function
• All moving parts with low-maintenance bearings
• Electrical components from Schneider or Omron
• SH-models with high, segmented goat's foot tools
• Quality Made in Europe
• Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened

• Extremely stable construction, entire machine body made of steel
• User-friendly operating concept
• Speed infinitely variable via inverter - Greater ease of operation and no need to replace wearing parts such as V-belts
• Combined micro-spray and blow-off device, for blowing off chips and lubricating the saw blade
• Tiltable working table made of cast iron
• Workplace lighting as standard
• Equipped with motor brake
• Belt tension and speed indicator
• Integrated band welding unit with annealing, cutting and grinding device
• Height adjustment of saw band guide by hand wheel
• VMBS I E models with electric table feed

• Two-column guided band saw for sawing solid bar material and bar profilesMitsubishi
• FX 5 control system with simple operation via 4.3" touchscreenCutting movement
• via hydraulic cylindersWith
• BRP (cutting feed control): if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continuesRobust
• machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performanceInfinitely variable
• cutting speed from 15 - 150 m/minSaw blade drive
• via bevel gearbox, Asynchronous motor and frequency converterClamping
• of the material in front of and behind the cut by means of a two-part vicePressure adjustment
• of the hydraulic vice clamping via control valve with pressure gaugeSaw blade inclination
• of 7° and hydraulic saw blade tensioning increase the service life of the saw
• bladeFront
• blade
guide moves automatically parallel to the moving
• saw blade
• Band guide moves automatically parallel to the moving vice jawElectrically
• driven chip clearing brushEmulsion cooling
• with liquid distribution into the saw band guides and directly into the cutting channelMore powerful
• motor optionally availableSaw band guides
• with integrated cooling system/ul>

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Heavy, durable industrial design with maintenance-free motor
• Long service life and smooth running due to balanced rotor with quality ball bearings
• Li>For deburring tubes, profiles and flat workpieces made of metal
• Surface for safety glasses
• Secure and clean working with the optional GU 5 substructure with cyclone dust extraction

• Powerful motor and vibration-free operation for the best sanding results
• Continuous face sanding surface thanks to removable attachments enables sanding of even long workpieces
• With two belt speeds
• Quick-clamping system enables fast sanding belt changes
• One extraction nozzle each directly on the spark box and on the rear belt roller
• Can be used with and without suction
• Easy adjustment of the belt run via adjusting screw on the front contact roller
• Automatic retensioning of the sanding belt thanks to spring-loaded belt tensioning system
• Infinitely tiltable sanding unit
• Fold-away protective screen
