Electromagnetic clamping plate for fixing the workpiece including automatic demagnetization function
Automatic central lubrication for all slides and spindles
Hand scraped and Turcite-B-coated V-flat guides guarantee extremely uniform, low-friction movement and highest precision
Halogen working light dustproof, completely contact-proof and protected against jet water according to IP65
Second grinding wheel flange included in delivery
Automatic feed control AD 5 The fsM series models are equipped with automatic feed control (AD 5). Different grinding cycles are available: surface loops with delivery at the starting point, groove loops with delivery at the starting point, groove loops with delivery at the start and end points. The delivery of the grinding wheel can be individually designed depending on the workpiece. The total grinding size is divided into coarse and fine delivery, the delivery steps can be freely entered, depending on the application, with a minimum resolution of up to 0.001mm. The possibility to program dead runs after a certain number of delivery steps as well as passages for firing after reaching the grinding measure provides the best grinding results. Manufacturer Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany info@stuermer-maschinen.de
Maximum rigidity and stability due to stress-free annealed and hardened cast iron construction
User-friendly touchscreen control: HMI graphic interface; all functions and grinding feed controllable; five program memories; function and error display; 7" screen size
Automatic feed control AD5: Various sanding cycles are available: Surface grinding with infeed at the start point, flute grinding with infeed at the start point, flute grinding with infeed at the start and end point. The infeed of the grinding wheel can be customized depending on the workpiece. The overall grinding dimension is divided into coarse and fine infeed, the infeed steps can be freely entered with a minimum resolution of up to 0.001 mm, depending on the application. The option of programming dead cycles after a certain number of infeed steps as well as passes for burn-out after reaching the sanding dimension ensures the best sanding results
Electromagnetic clamping plate
Automatic demagnetization device
Automatic adjustment of the cross feed
Cross sanding device
Recirculating ball screw and manual fine feed in the transverse axis
Longitudinal stroke adjustment via solenoid valve
Signal light to indicate the current operating mode
Two-column guided bandsaw for sawing solid bars and bar profiles
Mitsubishi FX 5 control system with simple operation via 7" touchscreen
With 700 mm material feed as standard
Cutting movement via hydraulic cylinder
With BRP (cutting feed control) -> if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continues
Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
Infinitely variable cutting speed from 15 - 150 m/min
Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
Material is clamped in front of and behind the cut using a two-part vice
Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
front band guide moves automatically parallel to the movable vice jaw
Electrically driven chip clearing brush
Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
With automatic material feed: frequency-controlled feed via circulation spindle; optical sensor recognizes when no more material is inserted and pauses the material feed
Spindle bearing class P4 from NSK guaranteed concentricity of 0.002 mm
Robust V flat guide with Turcite-B coating in the X and Z axes for grinding heavy workpieces
Backlash-free ball screws in the Y and Z axes
Optional extras: NC-controlled parallel puller and compensator on the grinding head, semi or fully automatic balancing device, full encapsulation of the grinding area, and much more
Two-column guided bandsaw for sawing solid bars and bar profiles
Mitsubishi FX 5 control system with simple operation via 7" touchscreen
With 700 mm material feed as standard
Cutting movement via hydraulic cylinder
With BRP (cutting feed control) -> if a set ampere limit is exceeded, the feed movement is stopped while the saw blade continues to run in order to convey chips out of the cutting channel. Once the normal load is reached, the sawing process continues
Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
Infinitely variable cutting speed from 15 - 150 m/min
Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
Material is clamped in front of and behind the cut using a two-part vice
Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
front band guide moves automatically parallel to the movable vice jaw
Electrically driven chip clearing brush
Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
With automatic material feed: frequency-controlled feed via circulation spindle; optical sensor recognizes when no more material is inserted and pauses the material feed
In series with manual adjustment of the bending angle
Especially low-maintenance
The workpiece is clamped by a motorized mechanism
S-models with segmented upper tools
SH-models with high, segmented casting foot tools
Available on request
Other models
Standard tools hardened
Hardened sharp bending bar and bending bar
Segmented tools and hardened bending bar
Segmented casting foot tools and bending bar hardened
Quality Made in Europe
Note on technical data For bending stainless steel, optional hardening of the tools is required Manufacturer Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany info@stuermer-maschinen.de
Powerful and quiet drive via LENZE gear motors with brake
Compact, heavy and stress-free welded steel construction
Sharp bending rail made of tool steel C50 at the clamping cheek
Continuous, exchangeable bed support made of tool steel C50
Continuous bending rail made of tool steel C50 at the bending beam
Automatic pressure regulation of the clamping cheek via motor current pick-up
Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
Bending angle adjustment PT 1 via potentiometer on the machine front (right)
Manual fine adjustment of bending beam with scale
Manual crowning via pressure screws in the bending beam
Foot remote control with emergency stop function
All moving parts with low-maintenance bearings
Electrical components from Schneider or Omron
SH-models with high, segmented goat's foot tools
Quality Made in Europe
Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened
Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function
High-quality spindle with precision taper roller bearings
Hardened and ground table guideways
Turcite-B-coated counter-guides for high wear resistance and low friction
Grinding spindle with high-quality precision bearings
Grinding wheel can be resharpened directly on the machine using a puller device
Digital position indicator
Machine base made of stable, torsion-resistant cast iron for maximum rigidity and stability
Guideways of the longitudinal and transverse grinding wheels, Lateral and vertical movements are backlash-free and self-centering as V- and flat track design
Precision ball screws
Guideways and transport spindle with central lubrication
All flat tracks are finely scraped and thus guarantee highest precision of all manual movements
Safety electrical system in 24 V direct voltage
Largely dimensioned decoupled handwheels in all three axes
Hydraulic lines according to DIN EN 853
Grinding accuracy: 0.005 mm
Corundum grinding wheel grain 46 for all common steels
Swivelling control panel makes work considerably easier
Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress
Twin-channel safety electronics
Sliding table splash protection
EMV filter class
With IE3 motor - consumes considerably less energy and thus significant cost savings
