• For use in the metalworking industry for grinding, structuring and polishing tasks, especially in the stainless steel sector
• 225 mm balanced belt rollers ensure optimum and low-vibration drive
• Infinitely variable belt speed of 4.5 - 27 m/s thanks to frequency shaper
• With electric table height adjustment
• With split table that can be opened, drawer sanding unit and integrated work table lighting
• Smooth-running sanding table even under load
• Easy adjustment of the sanding belt
• Profile roller sanding pad, resulting in less tarnishing during the sanding process
• Right/left rotation as standard

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Modern design in stable steel construction
• High design flexibility thanks to segmented edging rail with removable segment pieces
• Operation via two laterally arranged, large, adjustable and easy-to-operate lever arms
• Scissor table with inserted measuring tapes and right-angled stop on both sides
• Easily adjustable top, rear and bottom roller
• Long contact surface
• Adjustable backgauge and extendable front material support for the safe placement of even large format sheets

Turn around

• Adjustment screws for the material thickness with scaling
• Ground bending rolls with wire-laying grooves on the lower and front rolls

folding

• High quality folding cheeks
• Feather-down device
• Segment split edge rail 40/50/65/100/180/255/380 mm for cassette bending

To cut

• Clean and burr-free cutting by upper and lower blades made of quality steel

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Separate emergency stop stop switch
• Measurement scale for drilling depth
• Precisely machined, stable drilling table with diagonally running T-slots and circumferential cooling water trough
• Drilling table ± 45° inclinable and 360° rotatable
• One-piece die-cast aluminium quill lever with soft-grip handles
• Prezision spindle drilling
• Safety electrics in 24 V DC voltage
• Guaranteed concentricity accuracy of less than 0.03 mm measured in the drilling sleeve
• Drilling spindle with preprecision ball bearings
• High-quality quick-action drill chuck
• GATES quality belt
• Largely dimensioned base plate with T-slots, heavily ribbed on the rear side
• Largely dimensioned, height-adjustable protective screen with
• Right/left rotation

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Powerful induction motor for quiet and low-vibration work
• Adjustable workpiece support
• Sturdy steel housing

• Powerful induction motor for quiet and low-vibration work
• Adjustable workpiece support
• Sturdy steel housing
• Adjustable spark guard protects against flying parts without impairing visibility
• Equipped with K 36 and K60 sanding discs

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the back of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• With length measuring device and digital dimensioning system
• Roller and measuring track with battery-operated LCD display and magnetic tape measuring system
• Quality Made in Germany

Please specify when ordering mounting side and height!

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Thin sheets are supported in order to be able to apply dimensionally to the backgauge
• pneumatic sheet holding device with selector lever for the direction of the sheet metal chute
• Operator can choose if the section falls into the back room or the operator side

• Pneumatic sheet support, sheet ejection to the front or rear controllable via toggle switch
• Backgauge 750 mm guided on round shafts and driven via ball screw
• Stainless steel table supports with transfer balls for comfortable material handling
• Positioning control of the backgauge Maper HT071 with digital dimension display
• Heavy and robust steel construction in welded design
• Constant, low cutting angle for optimum cutting results
• Side fence 1000 mm with scale and T-slot
• Two material support arms 500 mm with T-slot
• Balls in the support table for easier material transport
• Cutting gap adjustment by means of vernier rings
• High quality blade suitable for stainless steel
• LED illumination of the cutting area
• Continuous finger protection device
• Mobile foot pedal with emergency stop switch
• All moving parts with low-maintenance bearings
• Electrical system from Siemens and Schneider

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• No running of the drawing knife during cutting due to three-sided ball bearing guide on the upper side of the knife
• Table feed is manual via large hand lever
• Convenient workpiece change due to backward tiltable tool arm
• Perpendicular angle of the drawing knife to the workpiece can be finely readjusted via rotary wheel

• Grooves are drawn in vertical direction. This has advantages over grooving: Higher accuracy, better surface finish and higher cutting speed
• Quicker and easier tool change
• No running of the drawing knife during cutting due to three-sided ball bearing guide on the upper side of the knife
• Perpendicular angle of the drawing knife to the workpiece can be finely readjusted via rotary wheel
• Table feed is manual via large hand lever
• Extremely robust and low-maintenance construction
• Convenient workpiece change due to backward tiltable tool arm
• Dividing plate with different angular pitches (available as accessory) enables precise and fast clamping and reclamping of the workpieces

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Ideal for sawing steel, sandwich panels, trapezoidal sheets, cable ducts, steel pipes and profiles, ferrous and non-ferrous metals, composite materials, etc.
• Lightweight magnesium construction: only 8.4 kg without saw blade
• Closed construction prevents flying chips
• Connection for external suction device

• Ideal for sawing steel, sandwich panels, trapezoidal sheets, cable ducts, steel pipes and profiles, ferrous and non-ferrous metals, composite materials, etc.
• Lightweight magnesium construction: only 8.4 kg without saw blade
• Ideal for use where cut-off machines are not strong enough or work uncleanly
• Cuts stainless steel with little burr
• Closed construction prevents the flying of chips
• Integrated chip tilting compartment
• Heavy-duty motor with soft start and overload protection
• LED load indicator for maximum cutting efficiency and control
• Sturdy and robust construction
• Easy operation
• Connection for external suction device

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• Feed / discharge roller conveyor
• Roller conveyor without scale and stop with side guide
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• The clamping of the workpiece is done by hand clamping
• Easy fixing of the set bending angle, which ensures a high repeatability
• Self-lubricating plain bearings
• The basic version can be converted at any time to high upper beam, high-segmented upper beam or high-segmented upper beam with Geißfuß by means of optional mounting kits

Note on abbreviations

• N = with low upper cheek
• H = with high upper cheek
• S = with segment rail
• G = with Geissfuß

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Robust and stable universal grinding machines with abrasive belt and grinding wheel for a wide range of materials
• Heavy, durable industrial design with maintenance-free motor
• Universal corundum grinding wheel and sanding belt in the standard scope of delivery

• Robust and stable universal grinding machines with abrasive belt and grinding wheel for a wide range of materials
• Heavy, durable industrial design with maintenance-free motor
• Housing made of extruded aluminum
• Large, heavy mounting flanges and thus high disc concentricity
• Sanding attachment with graphite coating; prevents friction and heat
• Stop allows quick and easy sanding of workpieces
• Tape adjustment without tools - only adjustable with a handle screw
• Universal corundum grinding wheel and sanding belt in the standard scope of delivery

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

Arguments convincing in quality, performance and price

• Time-saving deburring of edges and polishing of weld seams
• Stable and vibration-free construction
• Powerful engine
• Grinding table can be tilted by 22° - 50°
• Continuously adjustable stop at the top enables quick and easy grinding of the workpieces
• Large surface grinding area
• Additional safety device
• Extraction nozzle at the front for connecting a suction device
• Spark protection
• Workpiece support enables grinding at the right angle
• One sanding belt in the standard scope of delivery

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• High working capacity due to processing with two sanding belts and a further sanding unit for selective processing
• Infinitely variable speed control
• Motorized table height adjustment

• High working capacity due to processing with two sanding belts and an additional disc sanding unit with a diameter of 150 mm for spot processing e.g. polishing of weld seams
• One sanding shoe with large grooved pressure roller, thus less heat development and less tarnishing
• Optionally available: Contact roller device with large grooved pressure roller for less heat generation and less tarnish
• Infinitely variable speed control
• Motorized table height adjustment
• The special design with raised deflector (triangular shape) results in a large free working area in which work can be carried out without danger
• Optionally available with pneumatic workpiece clamping for thick or thin workpieces

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function
• High-quality spindle with precision taper roller bearings
• Hardened and ground table guideways
• Turcite-B-coated counter-guides for high wear resistance and low friction
• Grinding spindle with high-quality precision bearings
• Grinding wheel can be resharpened directly on the machine using a puller device
• Digital position indicator
• Machine base made of stable, torsion-resistant cast iron for maximum rigidity and stability
• Guideways of the longitudinal and transverse grinding wheels, Lateral and vertical movements are backlash-free and self-centering as V- and flat track design
• Precision ball screws
• Guideways and transport spindle with central lubrication
• All flat tracks are finely scraped and thus guarantee highest precision of all manual movements
• Safety electrical system in 24 V direct voltage
• Largely dimensioned decoupled handwheels in all three axes
• Hydraulic lines according to DIN EN 853
• Grinding accuracy: 0.005 mm
• Corundum grinding wheel grain 46 for all common steels
• Swivelling control panel, that makes work considerably easier
• Twin-channel safety electronics
• Sanding table splash guard
• Coolant tank capacity 100 liters
• Digitally controlled automatic vertical feed with servo motor
• Complex hydraulic system with heat exchanger ensures smooth table reversal even with high table loads
• EMV-Filter class
• With IE3 motor - consumes considerably less energy and therefore significant cost savings

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• Feed / discharge roller conveyor
• Roller conveyor without scale and stop with side guide
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 260 mm
• With length measuring device
• Roller and measuring track with mm-scale, manual measuring system with C-guide profile and sliding flap stop
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Roller and guideway system on which lighter wood, metal or plastic profiles can be precisely sawed, drilled or milled
• Substructure made of solid 3 mm steel profiles, painted and with adjustable feet
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• Stop track with length stop, manual measuring system with mm scale and reading magnifier
• Stop car is 4-roller bearings, thus manually easily displaced
• Adjustable stop arm and can be folded away to the rear
• Maximum measuring length is the length of the web minus the stop length of 250 mm
• Quality Made in Germany

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Control with 49 programs with each 99 possible individual steps
• Two cutting speeds
• Machine head guided vertically, with dovetail guide and adjustable wedge strip
• Machine head can be swiveled 45° to the left and 60° to the right, with locking at 45°, 0°, -45°, -60°
• Stable and robust construction
• Simple and intuitive operation
• Adjustable depth stop for the vertical stroke of the saw head
• Reduction gear, silent in oil bath running
• Coolant pump with coolant filter
• Coolant distribution for better lubrication
• Transversely movable hydraulic quick-action vice with anti-jaw device
• Chip breaker T6 for blade cleaning
• Electrical system in low voltage 24 volts, with emergency stop switch, main switch, speed selector switch, undervoltage release and overload protection
• Quality Made in Europe

Mode of operation automat

• Material feed
• Closing the vice and activating the motor
• Activation of the coolant pump and lowering of the saw head for cutting
• Return of the feed carriage to the specified dimension
• Return of the saw head to starting position
• Opening the vise
• Repeat cycle

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Square size depends on the shank diameter of the hand tap (DIN 376)

• 7 inserts M3 - M12
• Shank Ø M3 (2.5 mm), M4 (2.8 mm), M5 (3.5 mm), M6 (4.5 mm), M8 (6 mm), M10 (7 mm), M12 (9 mm)

Manufacturer
Optimum Maschinen Germany GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@optimum-maschinen.de

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the back of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• With length measuring device and digital dimensioning system
• Roller and measuring track with battery-operated LCD display and magnetic tape measuring system
• Quality Made in Germany

Please specify when ordering mounting side and height!

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de
