UUTUUDET

• High quality steel knives with a hardness of HRC55-60
• Equipped with two control handles
• Front bearing surface with scale
• Up to 500 mm adjustable backgauge

• NC control for setting the bending angle and the correction
• counter for high repeatability
• Mobile control panel with controls and pedals
• Fast tool change

• Powerful motor with inverter and reduction gear produces high torque
• NC control for setting the bending angle and the correction
• counter for high repeatability
• Mobile control panel with controls and pedals
• Fast tool change
• All shafts hardened and ground
• Material clamping is done manually
• Very good price / performance ratio

Manufacturer
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26, 96103 Hallstadt, Germany
info@stuermer-maschinen.de

• Ideal for roofers and tinsmiths in assembly use, e.g. for making bay and valley flashings or chimney claddings
• Equipped with transport rollers with locking brake

• Versatile and mobile
• Ideal for roofers and tinsmiths in installation work, e.g. for making bay and valley flashings or chimney cladding
• Simple design enables precise work
• Equipped with transport rollers with parking brake
• Safe, material-friendly operation
• Secure fixing of the workpiece via lever
• Swivel bending process via bow handle

• Maintenance-free motor for reliable operation
• Robust cast iron housing
• Balanced rotor with high-quality ball bearings for a long service life and smooth running
• LED lighting above the grinding wheels for optimum visibility in the work area
• Stable and flexibly adjustable workpiece supports for precise work

• Maintenance-free motor for reliable operation
• Robust cast iron housing
• Balanced rotor with high-quality ball bearings for a long service life and smooth running
• Integrated spark guard on the grinding wheels reduces flying sparks
• Protective discs made of shatterproof material for additional safety
• Non-slip and vibration-damping rubber feet for a stable stand
• Standard equipment with coarse and fine sanding discs (grit 36 and 80)
• LED lighting above the sanding discs for optimum visibility in the work area
• Stable and flexibly adjustable workpiece supports for precise work

• For producing all round shaped parts such as pipes, cylinders, etc.
• Roller drive via hand crank or motorized on E models
• Heavy and stable cast iron construction
• Asymmetric 3-roll system for easy pre-bending
• The upper roller is adjustable, thus easy removal of the finished workpiece
• Swiveling top roller
• Easily adjustable upper and lower roller
• Possibility of conical bending
• With safety devices
• Standard wire insert groove on bottom and back roller
• The foot control leaves both hands free for the material supply

• For deburring flat components e.g. after laser cutting or punching
• Large working width with up to 1350 mm
• Conveyor table with profile conveyor belt for optimum hold during processing

• For deburring flat components e.g. after laser cutting or punching
• Large working width with up to 1350 mm
• Conveyor table with profile foconveyor belt for optimum hold during processing
• NC control with 8" touch screen

• Suitable for wet grinding machines
• Filter area visible through transparent plastic windows

• Suitable for wet grinding machines
• Filter area visible through transparent plastic windows

• Standard with corrugated round brush (250 x 40 x 24 mm with wire Ø 0.5 mm) for steel processing
• with adjustable prism workpiece support
• large screen to protect against
• Sparks and flying chips
• S version with suction unit with separate motor and filter bag

• Feed and sanding belt speed infinitely adjustable
• Even deburring, cleaning or polishing of pipes
• Two oppositely running sanding belts on a rotating head, the rotation of the workpiece is eliminated
• Feed unit with rubber rollers ensures safe transport of the workpiece
• Profile is simply tensioned by handwheel in feed unit
• Connecting piece for suction
• Easy sanding belt change
• Foot pedal for controlling the rotary head

• Powerful and quiet drive via LENZE gear motors with brake
• Compact, heavy and stress-free welded steel construction
• Sharp bending rail made of tool steel C50 at the clamping cheek
• Continuous, exchangeable bed support made of tool steel C50
• Continuous bending rail made of tool steel C50 at the bending beam
• Automatic pressure regulation of the clamping cheek via motor current pick-up
• Drive of the clamping cheek via generously dimensioned trapezoidal thread spindles
• Bending angle adjustment PT 1 via potentiometer on the machine front (right)
• Manual fine adjustment of bending beam with scale
• Manual crowning via pressure screws in the bending beam
• Foot remote control with emergency stop function
• All moving parts with low-maintenance bearings
• Electrical components from Schneider or Omron
• SH-models with high, segmented goat's foot tools
• Quality Made in Europe
• Available on request: Models in DUO design with continuous sharp bending rail and segmented goad foot tools, standard tools hardened, sharp bending rail and bending bar hardened, segmented tools and bending bar hardened, segmented goad foot tools and bending bar hardened

• Robust machine design
• Manual and automatic mode selectable
• Easy tool change through quick change adapter

• Durable construction of tools and tool guides made of high-quality, hardened steel
• Manual operation via two foot pedals for flow and return
• Automatic mode by programming the front and rear travel end points
• Easy to change the die by quick change recording
• Foot pedal with digital display and emergency stop switch

Hydraulic oil not included

• Material roller conveyor with stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel (optionally also available with plastic rollers)
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 450 mm
• Length measuring device with handwheel adjustment
• Roller and measuring track with digital LED dimension display in mm, electrical connection 230 V, 50 Hz with power supply unit
• Measuring stop adjustable by handwheel from the workplace, with pneumatic brake for measuring fixation
• Sturdy material stop trolley, 12 ball bearings, movable on large dimensioned guide profile. The stop arm is adjustable and hinged.
• For roller conveyors with a length of more than 5 m, a cable drag chain is used
• Mounting side as desired right or left

Equipment details

position indicator

• 5-digit LED measurement display for constant, millimeter-accurate control of the current position of the stop car
• Position indicator with hollow shaft encoder mounted directly on the drive shaft
• Measuring accuracy / m: ± 0.5 mm

stop arm

• 900 mm long stop arm
• Stop plate adjustable to zero point and manually hinged backwards
• Multiple ball bearings, thus free of play
• Quality Made in Germany

• Best power transmission through aluminium pulleys in combination with toothed GATES quality wedge belt
• High smoothness thanks to ground multi-tooth handle
• Concentricity guaranteed to be less than 0.015 mm measured in the drill
• Separate emergency stop switch
• High-quality OPTIMUM quick-release drill chuck as standard
• Large-sized, height-adjustable protective screen with safety switch for maximum protection of the user
• Drilling depth stop
• V-belt cover with safety switch
• V-belt clamping device
• Right/Left Run
• Machine light in the drill head Integrated
• Precisely worked, stable drilling table with 2 diagonally running T-slots, 360° rotatable and circumferential cooling water channel
• Thick-walled casting column for high force absorption and stability
• Massive base plate, large sized and heavily ribbed on the back

• Excellent for producing clean visible edges and weld preparation
• For machining steel and aluminum
• Due to adjustable guide rollers on the support table also suitable for deburring of tubes with Ø 150 - 350 mm (optional 300 - 600 mm)
• Setting the chamfer height without tools
• Stepless angle adjustment from 0 - 60 °
• Handy and powerful device
• With two 6-way insert holders
• Feed is done manually
• Included carbide indexable inserts are also suitable for machining stainless steel at reduced speeds - tool life depends on specific operating conditions

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• Feed / discharge roller conveyor
• Roller conveyor without scale and stop with side guide
• Quality Made in Germany

• Heavy steel welded construction
• Upper and pinch roller driven
• Motorized delivery of the side roller
• Swing-out top roller
• Roller drive via powerful electric motor and gearbox
• Safety device Emergency line
• Mobile control panel

• Swiveling top roller

• Please specify when ordering material to be processed!
• Other models on request

• Stable drill guide due to long and low-mounted quill holder
• The devices are ideal for the construction site as they are earthed and double insulated
• Internal self-lubrication function ensures a longer service life of the gearbox
• Soft start protects the motor and extends the service life
• Powerful motor with high torque and low maintenance
• High-quality construction
• Conversion from core drilling to solid drilling in a few simple steps
• Automatic return to the starting position
• Protection class IP42

• Infinitely variable speed
• Quick-change chuck
• Low-wear brass guide

• Two-column guided horizontal saw for sawing solid bars and bar profiles
• Siemens S7-1500 control system with wide range of functions and operation via large 7" touch display
• With 2000 mm material transporter as standard -> frequency-controlled feed via circulating spindle and servomotor
• Material library with preset sawing parameters and characteristic curves
• Cutting movement via rotating spindle and servo motor
• With ARP (automatic cutting feed control) -> Automatic saw blade feed depending on the material resistance. Feed speed is constantly adapted to the current cutting load. ARP enables shorter work processes and a longer service life for the saw bands.
• Automatic positioning after entering the desired angle
• Hydraulic clamping of the turntable enables precise angular cutting
• Robust machine body and the smallest possible distances between the saw blade, machine guide and workpiece minimize vibrations for maximum sawing performance
• Infinitely variable cutting speed from 15 - 150 m/min
• Saw blade drive via bevel gearbox, asynchronous motor and frequency converter
• For straight cuts, the material is clamped in front of and behind the cut using a two-part vice
• Pressure adjustment of the hydraulic vice clamping via control valve with pressure gauge
• Saw blade inclination of 7° and hydraulic saw blade tension increase the service life of the saw blade
• Front band guide moves automatically parallel to the movable vice jaw
• chip clearing brush driven via belt roller
• Emulsion cooling with liquid distribution into the saw blade guides and directly into the cutting channel
• Safety light barrier from LEUZE in front of the machine and the material transporter
• More powerful motor optionally available
• Saw blade guides with integrated cooling system

• P version with two pneumatic auxiliary cylinders and foot switch
• Sturdy and robust welded construction
• Suitable for cutting steel and non-ferrous metals
• Foot operation leaves both hands free for material feed
• Large viewing window made of Plexiglas
• High-quality steel blade
• Baffle guide
• Simple adjustment of the cutting blade via eight screws
• Angle-adjustable side stop
• Maximum distance from finger guard to work table is 5 mm, ensuring maximum safety
• Cutting line lighting as standard

• Stable U-shaped closed construction made of 3 mm sheet steel profile
• Support rollers made of galvanized steel
• All roller conveyors of the MRB standard series also available with plastic rollers
• Supported rollers ball-bearing
• The maximum measuring length is the length of the track minus the stop length 400 mm
• Precision flat steel guide attached to the rear of the roller conveyor
• Sturdy, 6-way ball-bearing material stop trolley, easy-moving, manually movable and lockable
• Stopper with reading magnifying glass facilitates reading on the mm scale
• Robust stop arm attached to the stop truck, adjustable to the tool (0 point)
• Quality Made in Germany

Working height up to 1020 mm possible with optional foot plates.

By request:

• Working height from 1020 mm can be extended from the factory
• Also with 500 mm web width
